Table of Contents Rev. 8/9/2019 PRAIL MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Corp. Page 2 of 4
Signal Words
This manual uses SIGNAL WORDS to direct the reader’s attention to important safety-related messages. These
messages describe uses of the product that could result in personal injury or property damage. Each signal word
corresponds to a specific hazard level. The following are definitions of signal words that might appear in this
manual.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or SERIOUS
INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or SERIOUS
INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or MODERATE
injury.
Identifies practices likely to result in product/property damage, such as operation that might
damage the product.
Hazards
Vestil strives to identify all foreseeable hazards associated with the use of its products. However, material handling is
dangerous and no manual can address every risk. Ultimately the most effective way to prevent injury is for the operator
to apply sound judgment whenever using this device.
Serious personal injuries or death could result if this product is used improperly.
• Read and understand the entire manual before assembling and using this barrier.
• This barrier does NOT anchor to the ground and can fall over if pushed or leaned against. DO NOT use it as a
guardrail! These barriers do not provide fall protection. They should only be used to define boundaries.
• DO NOT modify the barrier in any way. Modifications automatically void the Limited Warranty on p. 4 and might make
the product unsafe to use.
• Inspect the product before each use. Confirm that there are no breaks or severely rusted/corroded regions, especially
along the top rail.
• DO NOT use this device UNLESS all labeling is readable and undamaged.
(standard
“curved”
foot
shown)
PRAIL-102-HD-Y
(Heavy duty)
23-001-368-B
PRAIL-102-HD-G
(Heavy duty)
23-001-358-B
PRAIL-102-HD-SS
(Heavy duty)
23-001-374-B
(standard
Galvanized
23-014-306
Flat
Yellow
23-014-311
Wheels
Yellow
galvanized
23-014-310
23-014-307
Unless wheels or flat feet are ordered, barriers include
(standard) curved feet. Hardware included.
Barrier Models
Barriers are available in 3 finishes: yellow powder coat,
galvanized, and stainless steel. Heavy duty
barriers are
also available in all 3 finishes.
Yellow powder coat finish (-Y suffix)
Galvanized finish (-G suffix)
Stainless steel (-SS suffix)
Foot installation: Insert the feet into the
legs of the barrier frame. Align the bolt
holes in the foot with the holes in the frame.
Insert
1
/
4
”-20 x 2” bolts through the holes.
Secure each bolt with a
1
/
4
” flat washer and
1
/
4
”-20 hex nut.
