0813 Rev. 12/6/2017 TRI, MANUAL

TRI-Series Tripods

Instruction Manual

Receiving instructions:

After delivery, inspect the product closely to determine whether it sustained damage during transport.

If damage is discovered, record a complete description of it on the bill of lading. If the product is

undamaged, discard the packaging.

NOTE: The end-user is solely responsible for confirming that product design, installation, use, and

maintenance comply with laws, regulations, codes, and mandatory standards applied where the product

is used.

Table of Contents

Signal words……………………………………………….……………………………………………………... 2

Safe use recommendations…………………...……….………………………..…………………….……….. 2

Exploded parts diagrams and bills of materials……………………………………………….……………… 3 – 6

Product specifications…………….……………………………………………………………………….…….. 7

Installation instructions………….……………………………………………………………………….…….... 7

Assembly instructions………….……………………………………………………………………….……….. 7 – 8

Using the tripod……………….……………………………………………………………………….…………. 9

Inspections & Maintenance….…………………..…………………………………………………..………….. 9

Labeling diagram………..…………..

…………………………………………………………........................ 9

Limited warranty………………………………………………………………………………………………..… 10

Vestil Manufacturing Corp.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868

Fax: (260) 665-1339

Web: www.vestilmfg.com e-mail: info@vestil.com

0813 Rev. 12/6/2017 TRI, MANUAL

Signal Words

This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the

probable seriousness of those injuries, if the product is misused in the ways described. Other signal

words call attention to uses of the product likely cause property damage.

The signal words used appear below along with the meaning of each word:

Identifies a hazardous situation which, if not avoided, WILL result in DEATH or

SERIOUS INJURY. Use of this signal word is limited to the most extreme

situations.

Identifies a hazardous situation which, if not avoided, COULD result in DEATH or

SERIOUS INJURY.

Indicates a hazardous situation which, if not avoided, COULD result in MINOR or

MODERATE injury.

Identifies practices likely to result in product/property damage, such as operation that

might damage the product.

Safe use recommendations

Vestil strives to identify all foreseeable hazards associated with the use of its products. However, no manual can

address every possible risk. The most effective means for avoiding injury is to read all of the instructions prior to

putting the steps into service and to apply sound judgment whenever using them.

If this product is used improperly or carelessly, the user and/or bystanders might sustain

serious personal injuries or even be killed. Each person who assembles uses or maintains this tripod

should read and understand the entire manual before installing, using or servicing the product for

the first time.

 Read the manual to refresh your understanding of proper use and maintenance procedures when

necessary.

 DO NOT attempt to resolve any problem with the product unless you are both authorized to do so and

certain that it will be safe to use afterwards.

 Inspect the product before each use, as described in “Inspections & Maintenance” on p. 9, to confirm

normal condition. DO NOT use the product if any unusual noise or movement is observed. If a malfunction

occurs, remove the unit from service and notify your supervisor & maintenance personnel about the issue.

 DO NOT exceed the capacity of the tripod (see “Specifications” table, p. 7, and “Labeling diagram”, p. 9).

 DO NOT stand, or allow other persons to stand, reach, or crawl beneath any elevated part of the tilter.

 DO NOT modify the tripod or any component of the lifter in any way UNLESS you first obtain written

approval from Vestil. Unauthorized modifications automatically void the Limited Warranty (p. 10) and might

make the device unsafe to use.

 DO NOT use the tripod UNLESS all product labels (see “Labeling diagram” on p. 9) are readable and

undamaged.

Proper use, maintenance, and storage are essential for this product to function properly.

o Always use this product in accordance with the instructions in this manual and consistent with any training

relevant to hoists and rigging used in conjunction with this product.

o Keep the product clean & dry. Periodically lubricate moving parts.
