This is the original instruction, please read all manual instructions carefully before operating.
VEVOR reserves clear interpretation of our user manual. The appearance of the product shall
be subject to the product you received. Please forgive us that we won't inform you again if
there is any technology or software updates on our product.
F-CLAMP
030201
TOUGH TOOLS, HALF PRICE
WORK AREA
1.Operate in a safe work environment. Keep your work
area clean, well-lit and free of distractions.
PERSONAL SAFETY
WARNING! Always Wear personal protective equip-
ment.
PERSONAL PRECAUTIONS
Control the F-clamp, personal movement and the work
environment to avoid personal injury or damage to
F-clamp.
1. Do not operate any F-clamp when tired or under the
influence of drugs, alcohol or medications.
2. Avoid wearing clothes or jewelry that can become
entangled with the moving parts of a tool. Keep long
hair covered or bound.
SPECIFIC SAFETY PRECAUTIONS
1. Use the correct F-clamp for the job. This F-clamp
was designed for a specific function. Do not modify or
alter this F-clamp or use it for an unintended purpose.
2. Keep body parts away from pinch areas while using.
3. Children are not allowed to operate this product
unless accompanied by an adult
4. Pay attention to safety during use to avoid crushing
fingers.
WARNING!
DO NOT let comfort or familiarity with product (gained
from repeated use) replace strict adherence to the tool
safety rules. If you use this tool unsafely or incorrectly,
you can suffer serious personal.
Thank you very much for choosing this F-clamp. Please
read all of the instructions before using it.The informa-
tion will help you achieve the best possible results.
The products carried in this catalog may be different in
color than the actual item.
①Handgrip ②Slide Bar ③Braking Lever
④Movable Jaw Assembly
⑤ Fixed Jaw Assembly L1:Clamping Size
L2:Throat Depth
①Handgrip ②Slide Bar ④Movable Jaw Assembly
⑤ Fixed Jaw Assembly L1:Clamping Size
L2:Throat Depth
By squeezing the Braking Lever thoroughly , the
movable jaw assembly can be moved in the direc-
tion of the arrow by hand, lock the screws last.
（Fig.1）
Model:F600-36
Model:F600-36
Model:F1100-50
Model:F1100-50
INSTRUCTIONS
Assembly and Use
Structure Diagram
Model and Parameters
Model F600-36 F1100-50
1100lbs
50inch（127cm)
3-7/8"（98.4.cm)
600lbs
36inch（91.4cm)
2-1/2"(63.5cm)
Maximum
Clamping Size
Throat Depth
Flamping Force
Warning-To reduce the risk of injury, user
must read instructions manual carefully.
