Vollrath FC-4C-05120-N Manual

Vollrath Køleskab FC-4C-05120-N

Læs gratis den danske manual til Vollrath FC-4C-05120-N (12 sider) i kategorien Køleskab. Denne vejledning er vurderet som hjælpsom af 3 personer og har en gennemsnitlig bedømmelse på 3.7 stjerner ud af 2 anmeldelser. Har du et spørgsmål om Vollrath FC-4C-05120-N, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/12
Operator’s Manual
Refrigerated and Non-Refrigerated Cold Pan and Frost Top Drop-ins
©
2019 The Vollrath Company L.L.C. Part No. 351937-1 ml 5/3/19
Thank you for purchasing this Vollrath equipment. Before operating the equipment, read and familiarize yourself with the following operating and
safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
SAFETY PRECAUTIONS
To ensure safe operation, read the following statements and understand
their meaning. This manual contains safety precautions which are
Warning is used to indicate the presence of a hazard that will or can cause
severe personal injury or death.
Caution is used to indicate the presence of a hazard that will or can
cause minor or major personal injury if the caution is ignored.
NOTICE: Notice is used to note information that is important but not
hazard-related.
To reduce risk of injury or damage to the equipment:
• This equipment must be installed by a qualified person.
• Use only grounded electrical outlets that match the rated voltage on
the nameplate.
NOTICE: Do NOT modify the cord or plug on the drop-in. Modifying
any component may damage the drop-in or cause injury,
and will void the warranty. See the specification sheet on
Vollrath.com for electrical specifications.
• Do not use an extension cord with this equipment. Do not plug this
equipment into a power strip or multi-outlet power cord.
• This equipment should only be used in a flat, level position.
• Keep the equipment and power cord away from open flames, electric
burners or excessive heat.
• Do not operate equipment if it is damaged or malfunctioning.
• Do not operate unattended.
Refrigerated Pans Short Side Refrigerated Pans Non-Refrigerated Pans Refrigerated Frost Tops
NSF NSF Standard Frost Top
FC-4C-01120-N One Pan
FC-4CS-02120-N Two Pan 36491
One Pan
FC-4C-02120-F
Two Pan
FC-4C-02120-N Two Pan
FC-4CS-03120-N Three Pan 36450
Two Pan
FC-4C-03120-F
Three Pan
FC-4C-03120-N Three Pan
FC-4CS-04120-N
Four Pan
36451
Three Pan
FC-4C-04120-F
Four Pan
FC-4C-04120-N Four Pan
36452
Four Pan
FC-4C-05120-F
Five Pan
FC-4C-05120-N Five Pan
36453
Five Pan
FC-4C-06120-F
Six Pan
FC-4C-06120-N Six Pan
36454
Six Pan
Standard Standard Short Side
FC-4C-01120-R
One Pan
FC-4CS-02120-R Two Pan 36654 Two Pan
FC-4C-02120-R
Two Pan
FC-4CS-03120-R Three Pan 36657 Three Pan
FC-4C-03120-R
Three Pan
FC-4CS-04120-R
Four Pan
36660
Four Pan
FC-4C-04120-R
Four Pan
FC-4C-05120-R
Five Pan
FC-4C-06120-R
Six Pan
WARNING
CAUTION
2 Refrigerated and Non-Refrigerated Cold Pan and Frost Top Drop-ins Operator’s Manual
FUNCTION AND PURPOSE
Cold pans are intended to hold containers of pre-chilled cold food at the
proper serving temperature for service. Frost tops are intended to hold
plated, pre-chilled food and beverages for short periods of time. Frost
tops are not intended for direct contact with food. This equipment is not
intended to chill hot food. For best performance, stainless steel
containers are recommended. This equipment is not intended for
household, industrial or laboratory use.
RECORD YOUR SERIAL NUMBER
The serial number for this equipment can be found on the rating plate
located below the well, near the power cord. To aid in future
communication about your product, please record the serial number in
the space below.
FEATURES AND CONTROLS
BEFORE FIRST USE
Before using this equipment it must be cleaned and dried thoroughly.
See the Cleaning section in this manual.
Serial Number
Rating
Plate
A
Mounting clip
B
On/off switch
C
Drain valve
C
A
B
C
B
Open
Closed
