Side 1/2

WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. JULY, 2015

waclighting.com

Phone (800) 526.2588

Fax (800) 526.2585

Headquarters/Eastern Distribution Center

44 Harbor Park Drive

Port Washington, NY 11050

Central Distribution Center

1600 Distribution Ct

Lithia Springs, GA 30122

Western Distribution Center

1750 Archibald Avenue

Ontario, CA 91760

INSTALLATION INSTRUCTION

InvisiLED® 24V PRO 2

LED-TX24

SAFETY INSTRUCTION

IMPORTANT: NEVER attempt any work without shutting o the electricity.

• Read all instructions before installing.

• Always turn o power at fuse box prior to installation to prevent electrical shock.

• Intended for indoor use. Dry and damp locations.

• For installation by a qualied electrician.

• System is intended for installation in accordance with National Electric Code, and local regulations.

• Consult with local inspector to assure compliance.

• InvisiLED® PRO 2 Tape lights have no polarity for connection. If a 1/2” x 1/2” or greater cove or channel is not built-in,

a RETROFIT Channel may be necessary to conceal the tape lights or provide an extended surface for mounting

or directing the light.

WIRING AND INSTALLATION:

Please refer to installation diagrams shown on next page

1. Determine the number of separately powered runs needed. Calculate the number of power supplies.

Min. / max. run length 6inch / 25 ft per run (100W transformer)

Current 165 mA/ft

Power consumption 4.0 Watts/ft

2. Measure the length of each run and round it o to the nearest 6-inch interval. Determine the necessary quantities

of 1-ft, 5-ft, and 6-in sections.

3. Count the number turns in the runs in order to determine the number of L, X, and Y connectors.

4. If making lateral turns at angles other than 90°, determine the number of joiner cables necessary to make the

lateral adjustment.

5. Connect to incoming 120V supply

Hard Wire

• Transformer must be installed away from heat sources and accessible for service

• Enclosed transformer is UL listed. The transformer box has a separate line volt, and low volt wiring compartments. Trade size

knock out are provided on both compartments. Connect building wires to like color transformer wires with wire nuts.

Building ground wire my be green or uninsulated, and attaches to green wire from transformer box.

Portable

• 24 Volts Transformer plugs into standard 120 Volts 3 prong grounded outlet

• Transformer must be installed away from the heat sources

6. Connect the output female connector of the transformer with the male connector of the InvisiLED tape or lead wires,

to form straight lines or turns around the installation surface.

7. Classic LED sections may be cut where indicated at the end of the run only.

8. On smooth surfaces, the included adhesive is sucient in most applications. However if mounting surface is a porous

or textured surface, then use a Mounting Clip every 6 inches to reinforce the installation.

9. Terminate each separately powered run with an end cap. Cut end caps or male end caps are the available choices for

cut or uncut sections respectively.
