WARNING:
IMPORTANT: NEVER attempt to do any work without shutting o the electricity.
• Read all instructions before installing.
• System is intended for installation by a qualied electrician in accordance with the National Electrical Code and local regulations.
• Go to the main fuse box, or circuit breaker. Place the main power switch in the “OFF” position and unscrew the fuse(s) or switch “OFF” the circuit
breaker switch(es) that control the power to the xture or room that you are working on.
• Place the wall switch in the “OFF” position.
AVERTISSEMENT:
IMPORTANT: Coupez l’électricité avant TOUTE manipulation.
• Lisez toutes les instructions avant d’installer.
• Système est destiné à être installé par un électricien qualié en conformité avec le code national de l’électricité et les règlements locaux.
• Accédez au panneau central de disjoncteurs ou de fusibles de votre demeure et placez l’interrupteur principal en position d’arrêt (« OFF »).
• Placez l’interrupteur mural en position d’arrêt (« OFF »).
CAUTION:
All parts must be used as indicated in these instructions. Do not substitute any parts, leave parts out, or use any parts that are worn out or broken.
Failure to follow this instruction could invalidate the ETL/cETL listing of this xture.
OVERVIEW:
Housing is for IC Airtight remodel and new construction applications. Housing requires a remote power supply to power the LED and a trim for a
nished look. Refer to specication sheets for compatible remote power supply and trim options .
OVERALL HOUSING DIMENSION
SPECIFICATIONS
Input DC 18V, 600mA Constant Current
Ceiling Thickness 1/2” - 2”
INSTALLATION INSTRUCTION
AETHER ATOMIC - TRIMLESS DOWNLIGHT, PINHOLE, WALL WASH
R1ARRL, R1ASRL, R1ABFL
R1ARRL R1ASRL R1ABFL
Installation Type Ceiling Thickness
Minimum Required
Ceiling Plenum Height
New Construction
2” - 2”
3”
Remodel
2” 3 2”
1”
4 2”
2”
5 2”
