Sound Enclosure Installation Guide

Figure 1 Figure 2 Figure 3 Figure 4 Figure 5

Figure 6 Figure 7 Figure 8 Figure 9

Step 1: To install the sound enclosure, rst you must remove the standard jar pad to access the screw holes on

the upper housing. This jar pad will not t properly with the sound enclosure. To remove it, peel it back,

starting in the corner and working your way over the drive coupling until it is completely off the base unit,

as seen in Figures 1, 2 and 3.

Step 2: Once the standard jar pad has been removed, nd the 3 screw holes located on the left, back and right

side of the upper housing as seen in Figures 4, 5 and 6.

Step 3: Place the base of the sound enclosure on the motor housing so the screw holes on the enclosure line up

with the screw holes on the base. Use a Phillips-head screwdriver and the 3 screws included with sound

enclosure to secure the enclosure to the base unit in the 3 locations as seen in Figures 7, 8 and 9.

Step 4: Once the sound enclosure is secured tightly, select the custom jar pad (included with sound enclosure).

Please note the standard jar pad will NOT t properly with the sound enclosure. The correct custom jar

pad has a recessed area around the outer edge. It also has a curved front with tabs on the sides, as seen

in Figures 10, 11, and 12. This curved area should face the front of the blender.

Step 5: Attach custom jar pad included with sound enclosure onto upper housing with the curve

facing out, as seen in Figure 13. Press tightly around coupling to secure custom jar pad onto

upper housing, as seen in Figures 14 and 15.

Figure 11 Figure 12 Figure 13 Figure 14 Figure 15

Figure 10

IB-11899

Part number – 027306

RV03 1212

12WC131700

Guía de instalación del recinto de insonorización

Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5

Fig. 6 Fig. 7 Fig. 8 Fig. 9

Paso 1: Para instalar el recinto de insonorización, primero se debe retirar el cojinete amortiguador estándar, el

cual no es compatible con el recinto. Para retirarlo, alce una esquina y jale hacia arriba, por encima del

acoplamiento de eje y hasta la otra esquina (ver las guras 1, 2 y 3).

Paso 2: Una vez retirado el cojinete estándar, note los oricios para tornillos ubicados en la izquierda, parte de

atrás y derecha de la base (ver las guras 4, 5 y 6).

Paso 3: Coloque el recinto de insonorización sobre la base, haciendo coincidir los oricios para tornillos del

recinto con los de la base. Sujete el recinto sobre la base usando un destornillador cruciforme y los tres

tornillos inclusos con el recinto (ver las guras 7, 8 y 9).

Paso 4: Una vez los tornillos apretados, instale el cojinete especial (incluido con el recinto de insonorización).

Nota: El cojinete amortiguador estándar NO es compatible con el recinto de insonorización. El cojinete

especial tiene un lo acanalado y un lado redondeado con lengüetas en los costados (ver las guras 10,

11 y 12). El lado redondeado debe apuntar hacia el frente del aparato.

Paso 5: Instale el cojinete amortiguador especial sobre la base del aparato, el lado redondeado apuntando hacia

el frente. Presione rmemente alrededor del acoplamiento de eje para sujetarlo (ver las guras 14 y 15).

Fig. 11 Fig. 12 Fig. 13 Fig. 14 Fig. 15

Fig. 10
