Side 1/5

Installation Guide

90cm freestanding cookers

Your freestanding cooker is designed to fit into a 900mm wide gap

between standard kitchen cabinets. The appliance integrates with

the kitchen cabinets by matching the height, depth and kick panel.

The cooker may also be installed at the end of a line of benches or

with a free space either side. In addition, a slot-in type installation is

catered for allowing a continuous cabinetry kick panel to be used.

WARNING

• The cooker must be installed and serviced only by an authorised

person.

• A Certificate of Compliance MUST be supplied to be kept by the

customer.

• The packing materials must be removed before you install the

cooker.

• The surrounding kitchen cabinets must be able to withstand 85°C.

Electrolux WILL NOT accept responsibility for damage caused by

installation into kitchen cabinets which cannot withstand 85°C.

• The pipes used for installation MUST have sufficient loops so the

cooker can be moved for service (gas models).

• The vents, openings and air spaces MUST NOT be blocked.

• Two anti-tilt brackets are supplied and stored in the base of the

packaging

• The anti-tilt brackets MUST be installed to avoid accidental

tipping (freestanding and slot-in models).

• You MUST NOT lift or pull the cooker by the door handle.

• The cooker MUST be checked every five years.

• If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in

order to avoid a hazard.

• The appliance must not be installed behind a decorative door in

order to avoid overheating.

• Due to the weight (95-100kg) and size of the cooker, 2 persons

are required to install it.

Gas model clearance requirements

• Ensure the appliance is installed in accordance with AS/NZS

5601.1 or AS/NZS 5601.2 with regard to clearances to combustible

surfaces and materials, and clearances to rangehoods and exhaust

fans, to ensure clearances of 200mm from burners to vertical

combustible surfaces. Observe the minimum dimension of 100mm

from each side of the cooker to combustible surfaces.

• Clearances to combustible surfaces may be reduced if combustible

surfaces are protected in accordance with AS/NZS 5601.1, or AS/

NZS 5601.2.

• When setting the cooker height, ensure the top of the cooker is at

least 10mm higher than the level of the benchtop.

and WESTINGHOUSE are trademarks of Westinghouse Electric Corporation. Used under license by Electrolux Home Products Pty Ltd. All Rights

Dimensions

600mm minimum

vertical clearance

from combustible

surfaces

Gas hob 910mm

(adjustable 910-930mm)

Ceramic hob 906mm

(adjustable 906-926mm)

15mm

(height of trivet above hob)

600mm

895mm

60mm

Splashback

The splashback is secured to the back of the cooker.

REMOVE the splashback before installing the feet.

Undo this screw

to remove the

splashback.

Re-attach the

screw afterwards

To access your detailed user manual simply scan the QR code on your

smart phone.

For more detailed information and installation guide refer to user manual at

westinghouse.com.au/manuals

The freestanding type installation requires four screw-in feet to be

installed before it can be fitted in between cabinets, with cabinets

on one side or without adjacent cabinets. There is no clearance

requirement to adjacent side cabinets.

To ensure cooker stability, the anti-tilt brackets must be installed.

Four screw-in feet are supplied with the appliance and can be

found in the accessories pack in the oven. Select models are

supplied with a clip-on kick panel.

900mm minimum

755mm NOM

900mm NOM

600mm

both sides

Installation of feet

• Freestanding appliances are supplied with four screw-in feet in

the internal accessory pack. The screw-in feet can be adjusted

by turning the lower half clockwise or anti-clockwise.

IMPORTANT

• If the appliance is a gas hob model, remove the burner cap

and burner crown. Store all items safely, away from the

installation area.

1. You MUST remove the oven door before commencing

installation.

Locking tab up at

normal position

Press the locking tab down for

removing the door.

2. Gently close the door until it comes to a stop.

Then lift the door off the hinge.

Installation Guide

90cm freestanding cookers

3. Tilt and carefully lay the appliance on its back to gain access to

the installation point for the screw in feet.

CAUTION

• To avoid scratching the floor and the appliance itself, fold the

packaging carton board and place it underneath the appliance

as protection.

• The cooker MUST be laid on its back when installing the feet.

4. Install the four supplied feet via the four installation points.

Make sure that each foot is securely fastened.

Put the oven door handle

protection foam underneath the

laid down cooker to protect your

cooker when putting it upright

5. Adjust the height of the screw-in feet to make sure the hob

surface is 10mm above the bench when appliance is upright.

Bench height + 10mm minimum

6. Tilt the appliance upright by lifting the back of the hob and

pivoting it about the back two feet.

WARNING

Heavy item! This step must be performed by two persons.

FREESTANDING INSTALLATION
