Before installing this product read all these instructions!

Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions.

Before making any connections, switch all the units in your system o at the mains.

Set the volume control at minimum when you switch on your system or change sources, and turn the level up gradually.

DO NOT use your amplier at full volume.

Ensure that all loudspeakers in the system are correctly wired.

DO NOT subject your loudspeakers to excessive cold, heat, humidity or sunlight.

Loudspeakers should not be placed directly facing other hi- units, or share the same shelf or cabinet.

DO NOT place heavy objects on top of loudspeakers.

Some manufacturers forbid the placing of objects on top of their TV sets. Check your TV handbook before installing the speaker directly on your

TV set. Consult your TV dealer if you are in any doubt.

DO NOT connect speaker terminals to the mains supply.

DO NOT dismantle the loudspeaker. There are no user serviceable parts inside it and you will void the warranty by doing so.

Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, the apparatus has

been exposed to rain or moisture, does not operate normally, or has been dropped.

Caution: Changes or modications not expressly approved by the manufacturer could void the user's authority to operate this device.

Unpacking Your Loudspeaker

Diamond 200 loudspeakers come in dierent shapes and sizes. If you are unpacking a oor stander, please remember that these units are heavy.

We suggest that you have someone to assist you.

Li the loudspeaker carefully out of the packing. try and li the loudspeaker using the protective bag.DO NOT

Unpack the accessories carefully.

If there is any sign of damage or if the contents are incomplete, report this to your dealer as soon as possible.

Retain the packing for future safe transport of the product. If you dispose of the packing, do so with respect to any recycling provisions in your area.

Attaching the Spikes to Floorstanding Models – 230, 240, 250

· Make sure you have plenty of unobstructed working space.

· Place a so cloth on the oor to protect the loudspeaker.

· Invert the loudspeaker onto the cloth.

· Thread a locknut onto each spike and loosely rub it up the thread.

· Thread the spikes into the spike inserts. Tighten them nger tight.

· Invert the loudspeaker. Be careful not to damage the oor with the spikes.

Levelling the Loudspeakers

When the speaker is upright: You will probably nd that the speaker will wobble with one spike not contacting the oor. Adjust this spike until

all four spikes are in contact to the oor.

With the aid of a spirit level move each spike in and out until the loudspeaker is level and siing squarely on all four

spikes without rocking.

Now tighten each locknut securely against the collar in the plinth to secure the spike.

Screw in rubber feet are provided for use on wood or stone oors etc. and should be aached in the same manner as the

spikes.

Important Safety Information

This symbol indicates that there are important operating and maintenance instructions in the literature

accompanying this unit.

Produkt Specifikationer

Mærke:	Wharfedale
Kategori:	Højttaler
Model:	Diamond 230
Bredde:	196 mm
Dybde:	306 mm
Højde:	938 mm
Vægt:	17800 g
Brugervejledning:	Ja
Produktfarve:	Sort
Pakkevægt:	21200 g
Pakkedybde:	310 mm
Pakkebredde:	420 mm
Pakkehøjde:	1060 mm
Udgangseffekt (RMS):	- W
Dybde (med stativ):	334 mm
Højde (med stativ):	964 mm
Frekvensområde:	40 - 20000 Hz
Impedens:	8 ohm (Ω)
Forbindelsesteknologi:	Ledningsført
Højttaler, type:	2,5-vejs
Lyd-output kanaler:	1.0 kanaler
Højttaler, placering:	Gulv
Antal drivere:	3
Driver diameter:	165 mm
Antal drivere til diskant:	1
Sensitivitet:	88 dB
Delefrekvens:	2300 Hz
Garantibevis:	Ja
Diskant diameter:	25 mm
Højttalerplacering:	Front
Basrefleks:	Ja
Drivercylinder, materiale:	Kevlar
Anbefalet forstærkereffekt (maks.):	150 W
Anbefalet forstærkereffekt (min.):	25 W
