Side 1/8

GB -1-

Chart

(see at right for options description)

PROGRAM SELECTION

BUTTON

Push “P” button (repeatedly)

until selected program number

is shown on the display

(P1...Px) - see “Table of

programs” below.

START/RESUME BUTTON

Push this button to start the selected program: the

indicator lights up and goes off at the end of the program.

When the door is opened during a washing cycle, the

cycle is temporarily paused: the Start indicator blinks.

To resume the cycle push Start button and close

the door within 3 seconds.

CANCEL/OFF BUTTON

Push this button to switch off the control panel.

If pressed when a program is running it cancels the

program ongoing draining water for 1 minute (0:01

is shown into the display). If pressed when the

dishwasher is switched off, it drains any possible

liquids from dishwasher (1 minute process).

1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without any options) and may vary depending

on conditions. Differences of up to 20 minutes are possible with sensor programs as a result of the appliance’s automatic calibration system.

2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information on the EN/Standard loading comparison test

and other tests, contact the following address: “nk_customer@whirlpool.com”.

3) The antibacterial action has been tested by the Institut Pasteur of Lille (France), based on the NF EN 13697 standard of November 2001.

RECYCLING WATER SYSTEM: these programs save water in a dedicated tank.

A TANK CLEANING CYCLE (at least 45 min.) is automatically run every 30 cycles or after every power off, to assure the best product conditions.

Table of programs

Deter-

gent

Consumption

Drying

Phase

Programs

Available

options

Loading instructions

Litres kWh

Minutes

6th Sense

Power Clean

40°-70°C

Delay

Multizone

Power Clean

Use for normal soiled dishes with dried-on food.

Senses the level of soiling on the dishes and adjusts the

program accordingly. When the sensor is detecting the

soil level an animation appears in the display and the

cycle duration is updated. The Power Clean option is

activated automatically with this program. To

deactivate, press the Power Clean button on the

control panel.

X 7-14 1.00-1.65 80-165 Full

Pre-Wash cold

Delay

Multizone

Crockery to be washed later. — 4.0 0.03 14 NO

Fragile 40°C

Delay

Multizone

Light soiling, for example glasses and cups. X 10.0 0.85 100 Light

Rapid 45°C

Delay

Multizone

Lightly soiled crockery, with no dried-on food. X 11.0 0.80 30 NO

Eco

50°C

Delay

Multizone

Power Clean

Normally soiled crockery.

Energy-saving program.

X 6.0 1.03 185 Full

Fast Daily 60°C

Delay

Multizone

Normally soiled crockery. X 10.0 1.30 80 Full

Silent 50°C

Delay

Multizone

Normally soiled crockery, gentle and quiet thanks to

the lower spray pressure (39 dbA).

X 10.0 1.20 290 Light

Intensive 65°C

Delay

Multizone

Power Clean

Recommended program for heavily soiled crockery,

especially suitable for pans and saucepans.

X 11.0 1.60 145 Full

Steam

Delay

Multizone

Power Clean

Program including steam action dedicated for heavily

soiled crockery, pots and pans. Soaking or hand

pretreatment is no longer needed.

X 10.0 1.70 180 Full

P10

Hygiene

Delay

Multizone

Power Clean

Normally or heavily soiled crockery, with additional

antibacterial wash. Program interruption (e.g. due to

door opening) can compromise elimination of germs.

X 13.0 1.50 118 Full

5019 396 03760

BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ THIS

QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!

Options and display description

WASH TIME DISPLAY

Indicated the cycle duration and the remaining time (h:min). With “Delayed start” selected it indicates

the time remaining until program start (h.00) - below 1h (0:min).

If “Fx Ey” messages appears on the display, see page 6 - chapter “What to do if...”.

THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING ANY

BUTTON EXCEPT CANCEL/OFF BUTTON. FOR ENERGY SAVING THE

CONTROL PANEL DEACTIVATES AUTOMATICALLY AFTER

30 SECONDS IF NO CYCLE HAS STARTED.

MULTIZONE

Allows you to choose the washing

zones. Press this button (repeatedly)

to select the wash zones:

both racks

only lower rack

only upper rack

- indicator lits

TABLET SETTING

This setting allows to

optimize the cycle

performances according

the type of detergent

used. Push the Tablet

button for 3 seconds (until

the indicator lights up)

if you are using the

combined detergents in

tablet (rinse aid, salt and

detergent in 1 dose).

If you are using powder

detergent or liquid

detergent, the Tablet

indicator on the control

panel has to be off.

DELAYED START

BUTTON

Push the button

(repeatedly) to delay the

start of the program.

Adjustable from 1 to 24

hours. With each press of

the button, the delayed

start indicator increases

by one hour and after

24 restarts from 0. Then

press the START button.

The dishwasher will start

after the set time.

POWER CLEAN

Thanks to the additional power jets

this option provides a more intensive

and powerful wash in the lower rack,

in the specific area. This option is

recommended for washing pots and

casseroles (see page 4). Press this

button to activate Power Clean (the

indicator lights up).

For non Power Clean loading to

achieve best cleaning performances

and resources optimization, Power

Clean should be switched off.

SALT INDICATOR

When lit (at the end of the cycle), the

salt reservoir needs to be refilled.

RINSE AID INDICATOR

When lit (at the end of the cycle), the

rinse aid dispenser needs to be refilled.

OPERATION

INDICATOR

A LED light

projected on the

floor indicates that

the dishwasher is

working.

Quick reference guide

Whirlpool is a registered trademark of Whirlpool USA

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	ADG 8798 A++ PC IX
Vekselstrømsindgangsspænding:	220 - 230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	597 mm
Dybde:	570 mm
Højde:	820 mm
Vægt:	43000 g
Indbygget skærm:	Ja
Strøm:	10 A
Pakkevægt:	44200 g
Pakkedybde:	660 mm
Pakkebredde:	640 mm
Pakkehøjde:	840 mm
Energieffektivitetsklasse (gammel):	A++
Årligt energiforbrug:	261 kWh
Placering af apparat:	Delvist indbygget
Støjniveau:	42 dB
Antal vaskeprogrammer:	10
Forsinket start-timer:	Ja
Dør farve:	Ikke anvendelig
Vaskeklasse:	A
Vandforbrug pr. cyklus:	6 L
Farve på kontrolpanel:	Black, Stainless steel
Antal kuverter:	13 kuverter
Forsinket start (maks.):	24 t
Opvaskeprogrammer:	Intensive, Night, Pre-wash, Quick, Steam
Tørringsklasse:	A
Årligt vandforbrug:	1680 L
Energiforbrug pr. cyklus:	0.92 kWh
Antal temperaturindstillinger:	8
AquaStop funktion:	Ja
