Side 1/8
GB
-1-
Chart
PROGRAM SELECTION
BUTTON
Push “Programs” button
(repeatedly) until the indicator
of the required program lights
up (see “Table of programs”
below).
(see at right for options description)
START/RESUME BUTTON
Push this button to start the selected program: the
indicator lights up and goes off at the end of the program.
When the door is opened during a washing cycle, the
cycle is temporarily paused: the Start indicator blinks.
To resume the cycle push Start button and close
the door within 3 seconds.
CANCEL/OFF BUTTON
Push this button to switch off the control panel.
If pressed when a program is running it cancels the
program ongoing draining water for 1 minute
(0:01 is shown into the display).
If pressed when the dishwasher is switched off,
it drains any possible liquids from dishwasher
(1 minute process).
1) Program data obtained in conformity with European standard EN 50242, obtained under normal conditions (without
additional options) and may vary depending on conditions. Differences of up to 20 minutes are possible with sensor
programs as a result of the appliance’s automatic calibration system.
2) Reference program for energy label in compliance with EN 50242 regulations. - Note for Testing Institutes: for detailed information
on the EN/Standard loading comparison test and other tests, contact the following address: “nk_customer@whirlpool.com”.
Ta b l e o f p r o g ra m s
Deter-
gent
Consumption
P
Programs
Available
options
Loading instructions
Litres kWh
Minutes
1)
1
Sensor 40-70°C
Delay
Multizone
Power
Clean
Normally or heavily soiled crockery,
including pots and pans. None
soaking or hand pretreatment is
needed. In addition hygiene of the
complete loading is ensured with this
program.
X 7-14 0.99-1.80 70-185
2
Pre-Wash cold
Delay
Multizone
Crockery to be washed later.
— 4.0 0.03 14
3
Glasses 40°C
Delay
Multizone
Light soiling, for example glasses and
cups.
X 10.0 0.85 100
4
Quickwash 45°C
Delay
Multizone
Lightly soiled crockery, with no
dried-on food.
X 11.0 0.80 30
5
Eco
2)
50°C
Delay
Multizone
Power
Clean
Normally soiled crockery.
Energy-saving program.
X 11.0 0.98 170
6
Overnight 55°C
Delay
Multizone
Normally soiled crockery, gentle and
quiet thanks to the lower spray
pressure (39dbA).
X 13.0 1.20 290
5019 396 01939ADG 9442
BEFORE USING THE APPLIANCE FOR THE FIRST TIME CAREFULLY READ
THIS QUICK REFERENCE GUIDE AND THE ASSEMBLY INSTRUCTIONS!
Options and display description
SALT INDICATOR
When lit (at the end of
the cycle), the salt
reservoir needs to be
refilled.
RINSE AID
INDICATOR
When lit (at the end of
the cycle), the rinse aid
dispenser needs to be
refilled.
WASH TIME DISPLAY
Indicated the cycle duration and the remaining time (h:min). With “Delayed start” selected it indicates
the time remaining until program start (h.00) - below 1h (0:min).
If “Fx Ey” messages appears on the display, see page 6 - chapter “What to do if...”.
THE CONTROL PANEL OF THIS DISHWASHER ACTIVATES PUSHING
ANY BUTTON EXCEPT CANCEL/OFF BUTTON. FOR ENERGY SAVING
THE CONTROL PANEL DEACTIVATES AUTOMATICALLY AFTER 30
SECONDS IF NO CYCLE HAS STARTED.
MULTIZONE
Allows you to choose the washing
zones. Press this button (repeatedly)
to select the wash zones:
both racks
only lower rack
only upper rack
- indicator lits
TABLET SETTING
This setting allows to
optimize the cycle
performances according
the type of detergent
used. Push the Tablet
button for 3 seconds (until
the indicator lights up) if
you are using the
combined detergents in
tablet (rinse aid, salt and
detergent in 1 dose). If you
are using powder
detergent or liquid
detergent, the Tablet
indicator on the control
panel has to be off.
DELAYED START
BUTTON
Push the button
(repeatedly) to delay the
start of the program.
Adjustable from 1 to 24
hours. With each press of
the button, the delayed
start indicator increases
by one hour and after 24
restarts from 0. Then
press the START button.
The dishwasher will start
after the set time.
POWER CLEAN
Thanks to the additional power jets
this option provides a more intensive
and powerful wash in the lower rack,
in the specific area. This option is
recommended for washing pots and
casseroles (see page 4). Press this
button to activate Power Clean (the
indicator lights up).
OPERATION
INDICATOR
A LED light projected
on the floor indicates
that the dishwasher is
working.
Quick reference guide
