Whirlpool AWA 5108/1 Manual

Whirlpool Vaskemaskine AWA 5108/1

Læs gratis den danske manual til Whirlpool AWA 5108/1 (17 sider) i kategorien Vaskemaskine. Denne vejledning er vurderet som hjælpsom af 19 personer og har en gennemsnitlig bedømmelse på 5.0 stjerner ud af 10 anmeldelser. Har du et spørgsmål om Whirlpool AWA 5108/1, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/17

CONTENTS

BEFORE USING THE WASHING MACHINE

FIRST WASH CYCLE

PRECAUTIONS AND GENERAL RECOMMENDATIONS

DESCRIPTION OF THE WASHING MACHINE

PREPARATION OF THE WASHING

DETERGENTS AND ADDITIVES

PROGRAMME SELECTION

CLEANING THE FOREIGN BODY TRAP

DRAINING RESIDUAL WATER

CARE AND MAINTENANCE

TROUBLESHOOTING GUIDE

AFTER-SALES SERVICE

TRANSPORT AND HANDLING

INSTALLATION

BEFORE USING THE WASHING MACHINE

1.Remove the packaging and check

a. Cut and remove the shrink-wrap.

b.Remove the top protection and the protective

corners.

c. Remove the bottom protection by tilting and

turning the washing machine on one rear bottom

corner.

d. Open the lid by pressing it slightly down while

raising the handle. Remove the polystyrene cushion.

e. Remove the blue protective film from the panel

(depending on model).

•After unpacking, make sure that the washing

machine is undamaged. If in doubt, do not use

the washing machine. Contact After-Sales

Service or your local retailer.

•Keep the packaging materials (plastic bags,

polystyrene parts, etc.) out of reach of children;

they are potentially dangerous.

2.Remove the transport bracket

•The washing machine is fitted with transport

screws and a transport bracket to prevent

damage during transport. Before using the

washing machine you must remove the

transport bracket (see “Installation/Remove

the transport bracket”).

3.Install the washing machine

•Place the washing machine on a flat and stable

floor surface.

• Adjust the feet to ensure that the machine is

stable and level (see “Installation/Adjust the

feet”).

4.Water supply

•Connect the water supply inlet hose in

accordance with the regulations of your local

water company (see “Installation/Connect the

water inlet hose”).

• Water supply: Cold water only

• Tap: 3/4” threaded hose connection

• Pressure: 100-1000 kPa (1-10 bar).

For Great Britain & Ireland only:

•Water inlet: hot and cold fill.

The warm water inlet temperature must not exceed

60° C.

5.Drain hose

•Connect the drain hose to the siphon or hook it

over the edge of a sink with the “U” bend (see

“Installation/Connect the water drain hose”).

•If the washing machine is connected to a built-

in drainage system, ensure the latter is equipped

with a vent to avoid simultaneous loading and

draining of water (siphoning effect).

6.Electrical connection

•Electrical connections must be carried out by a

qualified technician in compliance with the

manufacturer’s instructions and the current

standard safety regulations.

•The technical data (voltage, power and fuses)

are given on the rating plate on the rear of the

washing machine.

•The washing machine must be connected

exclusively by means of a socket with an earth

connection in accordance with current

regulations. The washing machine must be

earthed by law. The manufacturer declines all

liability for damage to persons or property

deriving directly or indirectly from failure to

observe the directions.

•Do not use extension leads or multi sockets.

•Before any maintenance on the washing

machine disconnect it from the mains supply.

•Access to the mains plug or to disconnection

from the mains supply via a double-pole switch

must be ensured at all times following the

installation.

•Do not operate the washing machine if it has

been damaged during transport. Inform the

After-Sales Service.

•Mains cable replacement is only to be carried out

by After-Sales Service.

•The washing machine must be connected to an

effective earthing installation, in compliance with

the regulations in force. In particular, washing

machines installed in premises containing a shower

or a bath must be protected by a differential residual

current device of at least 30 mA. Earthing the

washing machine is obligatory under the law. The

manufacturer declines all liability for damage to

persons or property deriving either directly or

indirectly from failure to observe the directions

above.

•The washing machine may only be used in the

household for the prescribed uses.

Dimensions:

Width: 400 mm

Height: 900 mm

Depth: 600 mm
