Whirlpool AWT 2289 Manual

Whirlpool Vaskemaskine AWT 2289

Læs gratis den danske manual til Whirlpool AWT 2289 (15 sider) i kategorien Vaskemaskine. Denne vejledning er vurderet som hjælpsom af 32 personer og har en gennemsnitlig bedømmelse på 4.3 stjerner ud af 16.5 anmeldelser. Har du et spørgsmål om Whirlpool AWT 2289, eller vil du spørge andre brugere om produktet?

Download PDF
Side 1/15
CONTENTS
BEFORE USING THE WASHING MACHINE
FIRST WASH CYCLE
PRECAUTIONS AND GENERAL RECOMMENDATIONS
DESCRIPTION OF THE WASHING MACHINE
PREPARATION OF THE WASHING
DETERGENTS AND ADDITIVES
CLEANING THE FOREIGN BODY TRAP
DRAINING RESIDUAL WATER
CARE AND MAINTENANCE
TROUBLESHOOTING GUIDE
AFTER-SALES SERVICE
TRANSPORT AND HANDLING
INSTALLATION
108
BEFORE USING THE WASHING MACHINE
1.Remove the packaging and check
a.Cut and remove the shrink-wrap.
b.Remove the top protection and the protective
corners.
c. Remove the bottom protection by tilting and
turning the appliance on one rear bottom
corner.
2.Remove the transport bracket
The appliance is fitted with transport screws and
a transport bracket to prevent damage during
transport. Before using the washing machine
you must remove the transport bracket
(see
Installation/Remove the transport bracket).
Do not forget to screw back 4 screws to the rear
panel by which was fixed the transport bracket - to
avoid noisy and vibration of the machine.
3.Install the washing machine
Place the appliance on a flat and stable floor
surface.
Adjust the feet to ensure that the machine is
stable and level (see Installation/Adjust the
feet).
4.Water supply
Connect the water supply inlet hose in
accordance with the regulations of your local
water company (see Installation/Connect the
water inlet hose).
Water supply: Cold water only
Tap: 3/4 threaded hose connection
Pressure: 100-1000 kPa (1-10 bar).
For Great Britain & Ireland only:
Water inlet: hot and cold fill. The warm water
inlet temperature must not exceed 60° C.
5.Drain hose
Connect the drain hose to the siphon or hook it
over the edge of a sink with the U bend (see
Installation/Connect the water drain hose).
If the washing machine is connected to a built-
in drainage system, ensure the latter is equipped
with a vent to avoid simultaneous loading and
draining of water (siphoning effect).
6.Electrical connection
Electrical connections must be carried out by a
qualified technician in compliance with the
manufacturers instructions and the current
standard safety regulations.
The technical data (voltage, power and fuses)
are given on the rating plate on the rear of the
appliance.
The appliance must be connected exclusively by
means of a socket with an earth connection in
accordance with current regulations. The
appliance must be earthed by law. The
manufacturer declines all liability for damage to
persons or property deriving directly or
indirectly from failure to observe the directions.
Do not use extension leads or multi sockets.
Before any maintenance on the washing
machine disconnect it from the mains supply.
Access to the mains plug or to disconnection
from the mains supply via a double-pole switch
must be ensured at all times following the
installation.
Do not operate the washing machine if it has
been damaged during transport. Inform the
After-Sales Service.
Mains cable replacement is only to be carried out
by After-Sales Service.
The appliance must be connected to an effective
earthing installation, in compliance with the
regulations in force. In particular, appliances
installed in premises containing a shower or a bath
must be protected by a differential residual current
device of at least 30 mA. Earthing the appliance is
obligatory under the law. The manufacturer declines
all liability for damage to persons or property
deriving either directly or indirectly from failure to
observe the directions above.
The washing machine may only be used in the
household for the prescribed uses.
Dimensions:
Width: 400 mm
Height: 900 mm
Depth: 600 mm

Produkt Specifikationer

Mærke: Whirlpool
Kategori: Vaskemaskine
Model: AWT 2289
