Side 1/4

Quick Guide

CONTROL PANEL

WASH CYCLE TABLE

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance,

please register your product on

www.whirlpool.eu/register

Before using the appliance carefully read the Safety Instruction.

Before using the machine, it is imperative that the transport bolts are removed.

For more detailed instructions on how to remove them, see the Installation Guide.

PRODUCT DESCRIPTION

1. Worktop

2. Detergent dispenser

3. Control panel

4. Door handle

5. Door

6. Water lter

7. Adjustable feet (4)

DETERGENT DISPENSER

Compartment 1: Pre-wash detergent

(powder)

Compartment 2: Washing detergent

(powder or liquid)

Compartment 3: Additives (fabric softeners,

etc.)

The fabric softener must not exceed the “MAX”

level.

! Use powder detergent for white cotton

garments, for pre-washing, and for washing at

temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

Maximum load 8 kg

Power input in o mode 0,5 W / in left-on mode 8 W

Detergents and

additives

Recommended

detergent

Residual

dampness % (***)

Energy

consumption kWh

Total water lt

Laundry

temperature °C

Programme

Temperatures

Max.

spin

speed

(rpm)

Dry-

ing

Max. load

for wash

cycle (kg)

Max. load

for drying

cycle (kg)

Duration

(h : m)

Prewash Main Softener

Powder Liquid

Setting Range 1 2 3

MIXED 40°C

- 40°C

1000 8,0 6,0 ** -



– – – –

COTTON 2 40°C

- 60°C

1400 8,0 6,0 3:55 -



49 1 90 40

SYNTHETICS 3 40°C

- 60°C

1200 4 4 2:55 -



35 0,75 55 43

RAPID 30’ 30°C

- 30°C

800 - 4,5 4,5 0:30 -



71 0,2 45 27

20°C 20 °C

- 20 °C

1400 8,0 6,0 1:50 -



49 0,16 90 22

WASH&DRY 45’ 30°C 30°C

1400 1,0 1,0 ** -



– – – –

WASH & DRY 90’ 30°C 30°C

1200 2,0 2,0 ** -



– – – –

SPIN & DRAIN * - -

1400 8,0 6,0 ** - - - - - – – – –

RINSE & SPIN - -

1400 8,0 6,0 ** - -



- - – – – –

WHITE 60°C

- 90°C

1400 8,0 6,0 2:45 (90°)



49 0,9 90 55

ECO 40-60 (1) 40 °C 40°C

1351 8,0

6,0

3:30 -



53 0,77 54 33

1351

4,0 2:45 -



53 0,65 52 36

1351

2,0 2:10 -



53 0,45 37 33

WOOL 40°C

- 40°C

800 2,0 2,0 ** -



– – – –

DELICATES 30°C

- 30°C

0 1,0 1,0 ** -



– – – –

COLOURS 15° 15°C 15°C

1000 4,5 4,5 ** -



– – – –

  Required dosage Optional dosage

ECO COTTON 4

60 °C 60 °C 1400 8,0 6,0 3:45 -



53 1,04 60 –

1. On/O button

2. Programme selector

3. Start/Pause button

4. Temperature button

5. FreshCare+ button

6. Dry Only button / Lock button

7. Drying settings button

8. Display

9. Start delay button

10. Spin speed button

DISPLAY INDICATORS

Washing phase

Indicates washing phase of the cycle

Drying phase

FreshCare+ activated

Key lock activated

Drying only

Timer drying mode

Drying automatic levels

Start delay activated

Door locked

Note: spin speed values shown on the display can slightly differs from the values stated in the table.

2) Long cotton programme: set the “ “ programme with a temperature of 40°C.

3) Synthetic program along: set the “ “ programme with a temperature of 40°C.

* Select the programme and set the spin speed to “ “ to empty only.0

** The duration of the programme is shown on the display.

***

After programme end and spinning with maximum selectable spin speed, in default

programme setting.

6th Sense - the sensor technology adapts water, energy and programme duration to your wash load.

4) Eco Cotton -

Test wash cycle in compliance with regulations 1061/2010. Set “

” wash

cycle at a temperature of 60°C to access this cycles.

For wash programmes with temperatures above 50°C, we recommend using powder detergent

rather than liquid, and following the directions given on the detergent package.

This data may dier in your home due to changing conditions in inlet water temperature,

water pressure etc. Approximate programme duration values refer to the default setting of

the programmes, without options.

The values given for programmes other than the Eco 40-60

programme are indicative only.

For all Test Institutes

1) Eco 40-60 (Wash)- Test wash cycle in compliance with EU Ecodesign regulation 2019/2014.

The most efficient programme in terms of energy and water consumption for washing normally soiled

cotton laundry.

Eco 40-60 (Drying)-

Test wash cycle in compliance with EU Ecodesign regulation

2019/2014

. To access “wash and dry” cycle select “Eco 40-60” wash programme and set

“Drying” option leval to

“ ”.

The most ecient programme in terms of energy and water

consumption for washing and drying normally soiled cotton laundry.

WASH CYCLES

Follow the instructions on the symbols of the garment’s wash

care label. The value indicated in the symbol is the maximum

recommended temperature for washing the garment.

Mixed

For washing lightly to normally soiled resilient garments in cotton, linen,

synthetic bres and mixed bres.

Cotton

for washing normally to heavily soiled towels, underwear, table and bed

linen etc. in resilient cotton and linen.

Synthetics

for washing normally soiled garments made from synthetic bres (such as

polyester, polyacrylic, viscose etc.) or cotton/synthetic blends.

Rapid 30’

for washing lightly soiled garments quickly: this cycle lasts only 30 minutes,

saving time and energy. Maximum load 3,5 Kg.

20 °C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

Wash&Dry 45’

for washing and drying lightly soiled cotton and synthetic bre garments

quickly. This cycle washes and dries a laundry load of up to 1 Kg in just 45

minutes.

Wash & Dry 90’

for washing and drying cotton and synthetic bre garments quickly. This

cycle washes and dries a laundry load of up to 2 Kg in just 90 minutes.

Spin & Drain

spins the load then empties the water. For resilient garments.

Rinse & Spin

rinses and then spins. For resilient garments.

White

For washing normally to heavily soiled towels, underwear, table and bed linen,

etc in resilient cotton and linen. Only when the temperature is selected at 90°C

the cycle is provided with a prewash phase before main washing phase. In this

case it is recommended to add detergent both, in the prewash and main wash

section.

Eco 40-60

For washing normally soiled cotton garments declared to be washable at

40 °C or 60 °C, together in the same cycle. This is the standard cotton

programme and the most ecient in terms of water and energy

consumption.

Wool

All wool garments can be washed using programme ‚“Wool“ even those

carryng the “hand-wash only “ label. For best results, use special detergents

and do not exceed max kg declaration of laundry.

Delicates

for washing particularly delicate garments. Preferably turn garments inside

out before washing.

Colour 15°

This cycle helps protect colours by washing in cold water (15°C) and uses

less energy to heat the water while still oering satisfactory wash results.

Suitable for lightly soiled, ustained garments. This cycle oers wash results

comparable to 40°c mixed at just 15°C

Eco Cotton

For washing normally soiled cotton garments at 60°C.

Door locked indicator

if the symbol is o the door is locked. To prevent any damage, wait

until the symbol turns on before opening the door.

To open the door while a cycle is in progress, press the START/PAUSE

button ; if the symbol is lit, the door can be opened.

FIRSTTIME USE

Once the appliance has been installed, and before you use it for the rst time,

run a wash cycle with detergent and no laundry, using the wash cycle (60°).

DAILY USE

Prepare the laundry by following the suggestions appearing under the

“TIPS AND SUGGESTIONS” section.

- Press the ON/OFF button ; the START/PAUSE indicator light will

ash slowly.

- Open the door. Load the laundry while making sure not to exceed the

maximum load quantity indicated in the Wash Cycle Table.

- Pull out the detergent dispenser drawer and pour the detergent into the

relevant compartments as described in “DETERGENT DISPENSER DRAWER”

section.

- Close the door.

- Use the WASH CYCLE selector knob to select the desired wash cycle: it

will be associated with a specic temperature and spin speed that can be

modied. The duration of the cycle will appear on the display.

- The machine automatically displays the default temperature and spin

speed values for the selected cycle, or the most recently used settings if

they are compatible with the selected cycle.

- Select the drying cycle if desired.

- Select the desired options.

- Press the START/PAUSE button to start the wash cycle; the relative

indicator light will light up steady and the door will lock ( symbol o).

PAUSING A CYCLE

To pause the wash cycle, press the START/PAUSE button again; the

indicator light will ash. If the symbol is lit, the door may be opened. To

start the wash cycle from the point at which it was interrupted, press the

START/PAUSE button again.

OPENING THE DOOR, IF NECESSARY

Once a cycle starts, the symbol turns o to signal that the door cannot

be opened. While a wash cycle is running, the door remains locked. To

open the door while a cycle is under way, for example, to add or remove

garments, press the START/PAUSE button to pause the cycle; the

indicator light will ash. If the symbol is lit, the door may be opened.

Press the START/PAUSE button again to continue the cycle.

CHANGING A RUNNING WASH CYCLE

To change a wash cycle while it is in progress, pause the washing machine

using the START/PAUSE button (the relative indicator light will ash), then

select the desired cycle and press the START/PAUSE button again.

! To cancel a cycle that has already begun, press and hold the ON/OFF

button. The cycle will be stopped and the machine will switch o.

END OF THE CYCLE

This will be indicated by the word “END” on the display; when the

symbol switches on, the door may be opened. Open the door, unload the

laundry and switch o the machine. If you do not press “ON/OFF”

button, the washing machine will switch o automatically after about a

10 minutes. Close the water tap, open the door and unload the washing

machine. Leave the door ajar to allow the drum to dry.

OPTIONS

! If the selected option is incompatible with the programme set, the

incompatibility will be signalled by a buzzer and the corresponding

indicator light will ash.

! If the selected option is incompatible with another previously set

option, only the most recent selection will remain active.

Freshcare+

If associated with wash cycles, this option increases their performances by

generating steam to block proliferation of the main sources of unpleasant

odours inside the appliance (exclusively for the wash). After the steam

phase, the machine runs a delicate cycle with slow drum rotations. When

the Freshcare+ option is associated with drying cycles, it prevents

stubborn creases from stabilising on garments, thanks to slow drum

rotations.

The FreshCare+ cycle starts at the end of the wash or drying cycle and

continues for maximum 6 hours; it can be interrupted at any time by

pressing any button on the control panel, or by turning the knob. Wait

roughly 5 minutes before opening the door.

Start Delay

To set the selected programme to start at a later time, press the button to

set the desired delay time. The

symbol lights on the display when this

function is enabled. To cancel the delayed start, press the button again

until the value “0” is shown on the display.

Temperature

Each wash cycle has a pre-dened temperature. To modify the

temperature, press the button. The value will appear on the display.“ ”

Spin

Each wash cycle has a pre-dened spin speed. To modify the spin speed,

press the button. The value will appear on the display.“ ”

Setting the drying cycle

The rst time the button is pressed, the machine will automatically “ ”

select the maximum drying cycle which is compatible with the selected

wash cycle. Subsequent presses will decrease the drying level and then the

drying time, until the cycle is excluded completely (“OFF”).

Drying may be set as follows:

A- Based on the desired laundry dryness level:

Cupboard : suitable for laundry which can be put back in a cupboard

without being ironed.

Hanger : ideal for clothes which do not need to be dried fully.

Iron : suitable for clothes which will need ironing afterwards. the

remaining dampness softens creases, making them easier to remove.

B - Based on a set time period: between 210 and 30 minutes.

If your laundry load to be washed and dried is much greater than the

maximum stated load (see adjacent table of wash cycles), perform the

wash cycle, and when the cycle is complete, divide the garments into

groups and put some of them back in the drum.

At this point, follow the instructions provided for a “ ” cycle. Drying only

Repeat this procedure for the remainder of the load. Note: a cooling-down

period is always added to the end of each drying cycle.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Vaskemaskine
Model:	BI WDWG 861484
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	545 mm
Højde:	820 mm
Vægt:	66000 g
Produktfarve:	Hvid
Kontroltype:	Buttons, Rotary
Indbygget skærm:	Ja
Strøm:	10 A
Ledningslængde:	1.7 m
Placering af apparat:	Indbygget
Dørhængsel:	Venstre
Inverter-teknologi:	Ingen
Tilsluttet belastning:	1850 W
Ilægningstype:	Front-læsning
Maksimal centrifugeringshastighed:	1400 rpm
Støjniveau (centrifugering):	70 dB
Støjniveau (vask):	45 dB
Forsinket start-timer:	Ja
Vaskeprogrammer:	Cold, Cotton, Eco, Wool, Quick
Justerbare fødder:	Ja
Spin-tørre klasse:	B
Energieffektivitetsskala:	A til G
Indikator for resterende tid:	Ja
Støjemissionsklasse:	A
Justerbar centrifugeringshastighed:	Ja
Visningsvindue:	Ja
Tørreevne:	6 kg
Vaske kapacitet:	8 kg
Støjniveau (tørring):	- dB
Cyklustid vask og tørring:	560 min.
Vandforbrug pr. vask:	48 L
Vandforbrug pr. vask og tørring:	65 L
Anti-krølle funktion:	Ingen
Tromle indvendigt lys:	Ingen
Tilføj tøj (pause) -funktion:	Ja
Strømstiktype:	Type F (CEE 7/4)
Energieffektivitetsklasse (vask):	C
Energieffektivitetsklasse (vask og tørring):	D
Energiforbrug pr. 100 cyklusser (vask):	63 kWh
Energiforbrug pr. 100 cyklusser (vask og tørring):	307 kWh
Cyklustid vask:	210 min.
