Side 1/4

1 “ON/OFF” button

2 Programme selector

3 “Start/Pause” button

4 “Spin” button

5 “Intensive rinse” button

6 “Clean+” button

7 “Start delay” button

8 “FreshCare+” /

“Key lock“button

9 “Temperature” button

DISPLAY INDICATORS

Pre-wash activated

Door locked

FreshCare+ activated

Start delay activated

Key lock activated

Washing phase

Indicates washing phase of the cycle

Failure: Call Service

Refer to Troubleshooting section

Failure: Water lter clogged

Water cannot be drained; water lter

might be blocked

Failure: No water

No or not sucient inlet water.

In the event of any failure, refer to the

“TROUBLESHOOTING” section

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance,

please register your appliance on

www.whirlpool.eu/register

Before using the appliance carefully read the Safety Instruction.

Before using the machine, it is imperative that the transport bolts are removed. For more detailed

instructions on how to remove them, see the Installation Guide.

CONTROL PANEL

PROGRAMME CHART

PRODUCT DESCRIPTION

1. Worktop

2. Detergent dispenser

3. Control panel

4. Door handle

5. Door

6. Water lter

7. Adjustable feet (4)

DETERGENT DISPENSER

Compartment 1: Pre-wash detergent (powder)

Compartment 2: Washing detergent

(powder or liquid)

Compartment 3: Additives (fabric softeners,

etc.)

The fabric softener must not exceed the “MAX”

level.

! Use powder detergent for white cotton

garments, for pre-washing, and for washing at

temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

Quick guide

+1 +2 +3 312

21 53

Max load 9 Kg

Power consumption in o -mode 0.5 W / in left-on mode 8 W Detergents and additives Recommended

detergent

Residual

dampness % (**)

Energy

consumption

kWh

Total water lt

Laundry

temperature °C

Programme

Temperatures Max. spin

speed

(rpm)

Max

load

(kg)

Duration

(h : m)

Pre-

wash

Main

wash Softener

Powder Liquid

Setting Range 1 2 3

Mixed 40°C - 40°C 4,5 *** –1000   –– – – –

White 60°C - 90°C 9,01400 2:45     (90°) 49 0,9 90 55

Cotton 40°C - 60°C 9,01400 3:55 –    49 1,1 95 40

Eco 40-60 40 °C 40°C

1351 9,0 3:40 –    53 0,86 54 38

1351 4,5 2:50 –    53 0,68 54 37

1351 2,5 2:10 –    53 0,46 40 33

Sport 40°C - 40°C 4,0 *** –600   –– – – –

Duvet 30°C - 30°C 3,5 *** –1000   –– – – –

20°C 20 °C - 20 °C 1400 9,0 1:50 –  –49 0,16 90 22

Spin & Drain – – 9,0 *** – – – – – – – – –1400

Rinse & Spin – – 9,0 *** – –1400 – – – – – –

Rapid 30’ 30°C - 30°C 4,5800 0:30 –  –71 0,2 45 27

Colours 15° 15°C 15°C 4,5 *** – 1000   –– – – –

Wool 40°C - 40°C 2 *** –800   –– – – –

Delicates 30°C - 30°C 1 *** –0  –– – – –

Synthetics 40°C - 60°C 41200 2:55 –    35 0,75 55 43

Eco Cotton 60 °C 60 °C 1400 9,0 4:00 –     53 0,8 56 -

40 °C 40 °C 1400 9,0 3:55 –    49 1,1 95 -

 Dosing required Dosing optional

** After programme end and spinning with maximum selectable spin speed, in default

programme setting.

*** The duration of the programme is shown on the display.

6th Sense - the sensor technology adapts water, energy and programme duration to your wash load.

Eco Cotton - Test wash cycles in compliance with regulations 1061/2010. Set “ ” wash

cycle at a temperature of 40°C or 60°C to access this cycles.

This data may dier in your home due to changing conditions in inlet water temperature,

water pressure etc. Approximate programme duration values refer to the default setting of

the programmes, without options.

The values given for programmes other than the Eco 40-60

programme are indicative only.

1) Eco 40-60 - Test wash cycle in compliance with EU Ecodesign regulation 2019/2014. The most

efficient programme in terms of energy and water consumption for washing normally soiled cotton laundry.

Note: spin speed values shown on the display can slightly diers from the values stated in the

table.

For all Test Institutes

Long wash cycle for cottons: set wash cycle with a temperature of 40°C.Cotton

Synthetic program along: set wash cycle with a temperature of 40°C.Synthetics

PROGRAMMES

For choosing the appropriate programme for your kind of

laundry, always respect the instructions on the care labels

of the laundry. The value given in the tub symbol is the

maximum temperature possible for washing the garment.

Mixed

For washing lightly to normally soiled resilient garments in cotton, linen,

synthetic bres and mixed bres.

White

For washing normally to heavily soiled towels, underwear, table and bed

linen, etc in resilient cotton and linen. Only when the temperature is

selected at 90°C the cycle is provided with a prewash phase before main

washing phase. In this case it is recommended to add detergent both, in

the prewash and main wash section.

Cotton

Normally to heavily soiled and robust cottons .

Eco 40-60

For washing normally soiled cotton garments declared to be washable

at 40 °C or 60 °C, together in the same cycle. This is the standard cotton

programme and the most ecient in terms of water and energy

consumption.

Sport

For washing lightly soiled sports clothing (tracksuits, shorts, etc.). For best

results, we recommend not exceeding the maximum load indicated in

the ‚‘‘PROGRAMME CHART‘‘. We recommend using liquid detergent , and

adding the amount suitable for half-load.

Duvet

Designed for washing eiderdown padded items such as double or single

duvets, cushions and anoraks. It is recommended to load such padded

items in the drum with the edges folded inwards and not to exceed ¾ of

the drum’s volume. For optimal washing, we recommend using a liquid

detergent.

20 °C

For washing lightly soiled cotton garments, at a temperature of 20 °C.

Spin & Drain

Spins the load then empties the water. For resilient garments. If you

exclude the spin cycle, the machine will drain only

Rinse & Spin

Rinses and then spins. For resilient garments.

Rapid 30’

For washing lightly soiled garments quickly. This cycle lasts only 30

minutes, saving time and energy.

Colours 15°

This cycle helps protect colours by washing in cold water (15°C) and uses

less energy to heat the water while still oering satisfactory wash results.

Suitable for lightly soiled, ustained garments. This cycle oers wash

results comparable to 40°c mixed at just 15°C

Wool

All wool garments can be washed using programme ‚“Wool“ even

those carryng the “hand-wash only “ label. For best results, use special

detergents and do not exceed max kg declaration of laundry.

Delicates

For washing particularly delicate garments. Preferably turn garments

inside out before washing.

Synthetics

For washing soiled garments made from synthetic bres (such as

polyester, polyacrylic, viscose, etc.) or cotton/synthetic blends.

Eco Cotton

For washing normally soiled cotton garments. At 40°C and 60°C.

FIRST TIME USE

To remove any manufacturing debris select the “Cotton” programme

at a temperature of 60°C. Pour a small quantity of detergent powder into

the main wash compartment of the detergent dispenser (maximum 2

1/3 of the quantity the detergent manufacturer recommends for lightly

soiled laundry). Start the programme without adding any laundry.

DAILY USE

Prepare your laundry according to the recommendations in the “HINTS

AND TIPS” section. Load the laundry, close the door, open the water

tap and press the “ON/OFF” button to switch the washing machine

on, the “Start/Pause” button ashes. Turn the programme selector

to the desired programme and select any option if needed. The

temperature and spin speed can be changed by pressing the “Temp.”

button or the “Spin Speed” button. Pull out the detergent dispenser and

add the detergent (and additives/softener) now. Observe the dosing

recommendations on the detergent pack. Then close the detergent

dispenser and press the “Start/Pause” button. The “Start/Pause”

button will lights up and the door will be locked.

PAUSE A RUNNING PROGRAMME

To pause the wash cycle, press the “Start/Pause” ; the indicator light

will go o and the remaining time on display ash. To start the wash cycle

from the point at which it was interrupted press the button again.

OPEN THE DOOR, IF REQUIRED

After starting a programme, the “Door locked” indicator lights up to

show that the door can not be opened. As long as a wash programme is

running, the door remains locked. To open the door while a programme

is in progress, press the “Start/Pause” to pause the programme.

Provided the water level and/or temperature is/are not too high, the

“Door locked” indicator light goes o and you can open the door.

For example to add or remove laundry. Press the “Start/Pause” button

again to continue the programme.

PROGRAMME END

The “Door locked” indicator light goes o and the display shows

“End”. To switch o the washing machine after programme ends press

the “ON/OFF” button, the lights goes o. If you do not press “ON/

OFF” button, the washing machine will switch o automatically after

about a 10 minutes. Close the water tap, open the door and unload the

washing machine. Leave the door ajar to allow the drum to dry.

OPTIONS

! If the selected option is incompatible with the programme set,

the incompatibility will be signalled by a buzzer (3 beeps) and the

corresponding indicator light will ash.

! If the selected option is incompatible with another previously set

option, only the most recent selection will remain active.

Clean+

Clean+ is an option working on 3 dierent levels (Intensive, Daily

and Fast) that are specially designed to set the right washing action,

depending on your cleaning needs:

Intensive : this option is designed for high levels of dirtiness,

removing most stubborn stains.

Daily : this option is designed to remove everyday stains.

Fast : this option is designed to remove lightly soiled stains.

Intensive rinse

By selecting this option, the eciency of the rinse is increased and

optimal detergent removal is guaranteed. It is particularly useful for

sensitive skin. Press the button once, two or three times to select an

additional 1

, 2

or 3

rinses after the standard cycle rinse and

remove all traces of detergent. Press the button again to go back to the

“Normal rinse” rinse type.

Start delay

To set the selected programme to start at a later time, press the button

to set the desired delay time. Symbol lights on the display when this

fuction is enabled. To cancel the delayed start, press the button again

until the value ‚‘‘0‘‘ is shown on the display.

FreshCare+

This option enhances washing performance by generating steam

to inhibit the proliferation of the main bad odour sources inside the

machine. After steam phase, the washing machine will perform gentle

tumbling through slow rotations of the drum. FreshCare+ option starts

after the cycle ends for a maximum duration of 6h and you can interrupt

at any time by pressing any button on control panel or turning the knob.

(*) Wait around 5’ before open the door.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Vaskemaskine
Model:	BI WMWG 91484 UK
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	545 mm
Højde:	815 mm
Vægt:	66500 g
Produktfarve:	Hvid
Kontroltype:	Buttons, Rotary
Indbygget skærm:	Ja
Strøm:	13 A
Strømforbrug (standby):	0.5 W
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Indbygget
Dørhængsel:	Højre
Inverter-teknologi:	Ja
Installationsrum bredde:	600 mm
Installationsrum dybde:	570 mm
Installationsrum højde:	820 mm
Tilsluttet belastning:	1850 W
Ilægningstype:	Front-læsning
Tromlekapacitet:	9 kg
Maksimal centrifugeringshastighed:	1400 rpm
Antal vaskeprogrammer:	15
Støjniveau (centrifugering):	70 dB
Støjniveau (vask):	- dB
Forsinket start-timer:	Ja
Vaskeprogrammer:	Bedding, Cold, Cotton, Cottons 40°C, Delicate/silk, Eco, Mix, Rinse & spin, Spin/drain, Sport, White, Wool
Børnesikring:	Ja
Justerbare fødder:	Ja
Tromle volumen:	58 L
Balje materiale:	Plast
Balance system:	Ja
Spin-tørre klasse:	B
Cyklustid (maks.):	220 min.
Skum kontrol system:	Ja
Restfugtighed:	53 %
Vandforbrug pr. cyklus:	50 L
Energieffektivitetsskala:	A til G
Indikator for resterende tid:	Ja
Udøsslange længde:	1.2 m
Overløbsbeskyttelse:	Ja
Støjemissionsklasse:	A
Energieffektivitetsklasse:	C
Energiforbrug pr. 100 cyklusser:	65 kWh
Justerbar temperatur:	Ja
Justerbar centrifugeringshastighed:	Ja
Tilføj tøj (pause) -funktion:	Ja
Døråbning:	Sideåbning
Tænd/sluk-knap:	Ja
