Whirlpool FFT M22 8X2BS BE Manual

Whirlpool Tørretumbler FFT M22 8X2BS BE

Læs gratis den danske manual til Whirlpool FFT M22 8X2BS BE (16 sider) i kategorien Tørretumbler. Denne vejledning er vurderet som hjælpsom af 50 personer og har en gennemsnitlig bedømmelse på 4.9 stjerner ud af 25.5 anmeldelser. Har du et spørgsmål om Whirlpool FFT M22 8X2BS BE, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/16

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance,

please register your product on

www.whirlpool.eu/register

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code in your appliance

• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-sales

Service, please state the codes provided on your product's identification plate.

Before using the appliance carefully

read the Safety Instruction.

PLEASE SCAN THE QR CODE ON YOUR APPLIANCE IN ORDER TO REACH MORE INFORMATION.

Quick guide

Before using the appliance carefully

read the Safety Instruction.

CARE LABEL

Always check the care labels, especially when placing garments in

the tumble dryer for the ﬁ rst time. Below are the most commonly

used symbols:

May be tumble dried.

Do not tumble dry.

Tumble dry – high heat.

Tumble dry – low heat.

DAILY USE

Doing this will keep your machine working at its BEST:

- remember to empty your water tank after each drying

cycle.

- remember to clean your lters after each drying cycle.

Refer to the Care & Maintenance section.

1. Plug the dryer into the power supply socket.

2. Open the door and load garments; always refer to instructions on

clothing labels and the max loads indicated in the programme

section. Empty pockets. Make sure garments do not get caught

between the door and/or the door filter. Do not load items that

are dripping wet. Do not tumble dry large, very bulky items. For

optimal drying result, garments should be loaded one by one.

3. Close the door.

4. Press the "On/Off" button.

5. Select the most suitable programme

for the type of fabric in

that load.

6. Select the options, if necessary.

7. Press the "

Start/Pause"

button to begin drying.

8. At the end of the drying cycle, a buzzer will beep. An indicator on

the control panel signals the end of the cycle. Turn the machine

off by pressing the "On/Off" button, open the door and pull the

clothing immediately out to prevent the formation of creases on

laundry.

If the machine is not switched off manually, after about a quarter

of an hour from the end of the cycle , the appliance turns off

automatically to save energy.

Note that some models perform a final cool tumble phase, for this

reason the fabrics may not feel hot.

In case of power failure, it is necessary to press the "Start/Pause"

button to restart the cycle

Opening the door during the cycle

The tumble dryer door can be opened at any time during the cycle

to check progress and remove any garments already dry.

However, since opening the door can extend the drying time, the

recommendation is to keep the door closed throughout the cycle

process to save time and energy.

After closing the door, press the "Start/Pause" button within 15

minutes to resume the machine operation.

FIRST TIME USE

Make sure that the water tank is correctly inserted. Make sure

that the drain hose on the back of the dryer is ﬁxed correctly,

either to the dryer’s water tank, or to your domestic drainage

system.

The dryer must be installed in a room with a temperature

ranging between 5°C and 35°C to ensure proper operation.

Before you use your dryer ensure that it has been in a upright

position for at least 6 hours.

CONTROL PANEL

1 ON/OFF button (hold for Reset)

2 Programme selection Knob

3 Start/Pause

Options Buttons*

4 Cycle end

5 High heat

6 Anti tangle (hold for Mute)

7 Dryness level

8 Start delay

9 Timed drying

10 Rapid (hold for Key lock)

11 Gentle

12 FreshCare+

*Note: some models may have the wording in full instead of the icons.

INDICATORS

Dryness level: Iron dry - Hanger dry - Cupboard dry - Extra dry

Cycle phase: Drying - Cool down - End of cycle

Empty water tank - Clean door lter - Clean bottom lter

Refer to troubleshooting section: Failure: Call after sales service

78 9

3“

78 9

3“

These buttons allow you to personalise the selected programme

according to personal requirements. Not all options are available

for all programmes. Some options may be incompatible with

ones you have previously set; if so, you will be alerted by the

buzzer and/or blinking indicators. If the option is available, the

option indicator will stay on. The programme may retain some

options selected in previous drying cycles.

OPTIONS

Dryness level

Press the related button several times to obtain a diﬀerent

level of residual moisture on garments. An indicator signals the

level being selected.

Iron dry: very delicate drying. Items will be more easily

ironed immediately after the cycle.

Hanger dry: a level intended for delicate garments ready to

be hanged.

Cupboard dry: the laundry is ready to be folded and put

away.

Extra dry: for laundry intended to be worn at the end of the

cycle.

Timed drying

This option is to manually set the drying time. Press the

corresponding button to set the required time for drying. An

indicator on the control panel signals the time being selected.

Start delay

This option is for delaying the start of the cycle. Press the

corresponding button several times to ﬁnd the required delay. Once

the max time is reached, the option is reset by pressing the button

again. An indicator on the control panel signals the time being

selected. After pressing the "Start/Pause" button, the machine signals

the time remaining to the start of the cycle. If the door is opened, press

the "Start/Pause" button once the door has been closed.

Rapid

Enables quicker drying.

FreshCare+

If laundry is left inside of the drum once the cycle has

ended, it can be subjected to bacterial proliferation. This

option helps to prevent this from happening by controlling the

temperature and gently rotating the drum. This will continue for

up to 6 hours after the end of the cycle. This setting will remain in

the memory of the previous cycle. If this is used alongside Start

Delay, a crease treatment will be perfomed during this phase by

periodic rotations of the drum.

Key lock

This option makes all machine controls inaccesible, except the

"On/Oﬀ" button. When the machine is on:

• to activate the option, keep the button pressed until the

machines signals that the option has been enabled.

• to disable the option, keep the button pressed until the machine

signals that the option has been disabled.

This option remains in memory if selected in previous drying.

Cycle end

This option activates a prolonged buzzer at the end of the

cycle. Enable it if you are not sure to hear the normal sound at the

end of the cycle. This option remains in memory if selected in the

previous drying.

Mute

This option turns oﬀ all sounds of control panel. Only

warnings remain active.

• to activate the option, keep the button pressed until the indicator

goes on.

• to disable the option, keep the button pressed until the indicator

goes oﬀ.

High heat

It improves the drying capacity. Option suitable for drying

tough garments, it is used with timed cycles.

Anti tangle

This option performes a special drum movement that

reduces tangling and knotting of your clothes. It gives best results

when used with smaller loads.

Gentle

Enables a more gentle treatment of the laundry by reducing

the drying temperature.

The duration of these programs will depend on the size of the

load, types of textiles, the spin speed used in your washer and

any extra options selected. In machines equipped with display,

the duration of the cycles is shown on the control panel. The

remaining time is constantly checked and adjusted during the

drying cycle to show the best possible estimate.

Option to use - If all your loads on Automatic Cycles are

consistently less dry or more dry than you would like, you may

increase or decrease the dryness level using the speciﬁc option.

*MAX LOAD 8 Kg (Dry load)

PROGRAMS

Eco kg Max*

This is the most eﬃcient programme in terms of energy

consumption and is suitable for drying normal wet cotton

laundry. The values on the Energy Label are based on this

programme.

NOTE: For optimal energy eﬃciency this cycle by default is set up to

"Cupboard Dry" level. For a higher dryness level we suggest using

the Cotton cycle.

Cotton kg Max*

Cycle suitable for drying all types of cotton, ready to be placed

in the cupboard.

Mixed kg 4

This programme is ideal for drying cotton and synthetic

fabrics together.

Bed linen kg Max*

This programme is intended for drying cotton sheets.

Duvet

Programme intended to dry bulky items, such as a single duvet.

Shirts kg 3

This is a programme for Shirts made from cotton or cotton

blend/synthetics.

Jeans kg 3

For drying sturdy cotton including denim trousers and

jackets.

Easy ironing

This cycle relaxes ﬁbres, thus making ironing and folding

easier. Suitable for small load of damp or dry cotton and cotton

blend fabrics. Not for wet items.

Refresh

A short programme suitable for refreshing ﬁbres and

garments through the emission of fresh air. Do not use on wet

items. It can be used on with any load size but is more eﬀective

with small loads. It lasts about 20 minutes.

Rapid 30' kg 0.5

Ideal for drying cotton garments spun at high speed in the

washing machine.

Sport kg 4

For drying synthetics or cotton sports garments.

Silk kg 0.5

Gentle drying of silk garments.

Wool kg 1

Programme for drying wool clothes. It is advisable to turn the

items inside out before drying. If heavy edges remain damp, leave

them to dry naturally.

Delicates kg 2

For drying delicate laundry requiring gentle treatment.

Synthetics kg 4

For drying synthetic fabrics.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Tørretumbler
Model:	FFT M22 8X2BS BE
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	595 mm
Dybde:	649 mm
Højde:	849 mm
Vægt:	44000 g
Produktfarve:	Hvid
Kontroltype:	Buttons, Rotary
Indbygget skærm:	Ja
Skærmtype:	LCD
Strøm:	10 A
Ledningslængde:	1.5 m
Årligt energiforbrug:	234 kWh
Strømforbrug (slukket):	0.5 W
Placering af apparat:	Fritstående
Inverter-teknologi:	Ja
Tilsluttet belastning:	850 W
Støjniveau:	64 dB
Ilægningstype:	Front-læsning
Tromlekapacitet:	8 kg
Forsinket start-timer:	Ja
Børnesikring:	Ja
Understøttede scanningstilstande:	1092 mm
Tromle volumen:	120 L
Cyklustid:	194 min.
Forsinket start (maks.):	24 t
Energieffektivitetsskala:	A+++ til D
Filterrengøringsindikator:	Ja
Indikator for resterende tid:	Ja
Strømforbrug (fortsat-tændt):	1 W
Tørreprogrammer:	Wool, Mix, Sport, Timed, Quick, Freshen-up, Delicate/silk, Eco, Jeans/denim, Cotton
Tørresystem:	Kondensering
Anti-krølle funktion:	Ja
Energiforbrug:	1.78 kWh
Varmekilde:	Elektrisk
Varighed af tilstanden fortsat-tændt:	15 min.
Justerbart tørringsniveau:	Ja
Dørstil:	Glasdør
