Download the complete instruction manual http://

docs.whirlpool.eu or call the phone number shown

on the warranty booklet.

These instructions are valid if the country symbol

appears on the appliance. If the symbol doesn’t appear

on the appliance, it is necessary to refer to the technical

instructions which will provide the necessary instructions

concerning modication of the appliance to the

conditions of use of the country.

CAUTION: The use of the gas cooking appliance

results in the production of heat, moisture and products

of combustion in the room in which it is installed. Ensure

that the kitchen is well ventilated especially when the

appliance is in use: keep natural ventilation holes open or

install a mechanical ventilation device (mechanical

extractor hood). Prolonged intensive use of the appliance

may call for additional ventilation, such as opening a

window, or more eective ventilation, for example

increasing the level of mechanical ventilation (if possible).

Failure to follow the information in this manual exactly

may cause a re or explosion, resulting in property

damage or personal injury.

Before using the appliance, read these safety

instructions. Keep them nearby for future reference.

These instructions and the appliance itself provide

important safety warnings, to be observed at all times.

The manufacturer declines any liability for failure to

observe these safety instructions, for inappropriate

use of the appliance or incorrect setting of controls.

WARNING: If the hob surface is cracked, don’t use

the appliance – risk of electrical shock.

WARNING: Danger of re: Do not store items on the

cooking surfaces.

CAUTION: The cooking process has to be supervised. A

short cooking process has to be supervised continuously.

WARNING: Unattended cooking on a hob with fat or

oil can be dangerous – risk of re. NEVER try to

extinguish a re with water, but switch o the appliance

and then cover ame e.g. with a lid or a re blanket.

Do not use the hob as a work surface or support.

Keep clothes or other ammable materials away from

the appliance, until all the components have cooled

down completely – risk of re.

Very young children (0-3 years) should be kept away

from the appliance. Young children (3-8 years) should

be kept away from the appliance unless continuously

supervised. Children from 8 years old and above and

persons with reduced physical, sensory or mental

capabilities or lack of experience and knowledge can

use this appliance only if they are supervised or have

been given instructions on safe use and understand

the hazards involved. Children must not play with the

appliance. Cleaning and user maintenance must not be

carried out by children without supervision.

CAUTION: In case of hotplate glass breakage: shut

immediately o all burners and any electrical heating

element and isolate the appliance from the power

supply; do not touch the appliance surface; do not use

the appliance.

The glass lid can break in if it is heated up. Turn o all

the burners and the electric plates before closing the

lid. Do not shout down lid when burner alight.

WARNING: The appliance and its accessible parts

become hot during use. Care should be taken to avoid

touching heating elements. Children less than 8 years of

age must be kept away unless continuously supervised.

PERMITTED USE

CAUTION: the appliance is not intended to be

operated by means of an external switching device,

such as a timer, or separate remote controlled system.

This appliance is intended to be used in household

and similar applications such as: sta kitchen areas in

shops, oces and other working environments; farm

houses; by clients in hotels, motels, bed & breakfast and

other residential environments.

No other use is permitted (e.g. heating rooms).

This appliance is not for professional use. Do not use

the appliance outdoors.

Use pots and pans with bottoms the same width as

that of the burners or slightly larger (see specic table).

Make sure pots on the grates do not protrude beyond

the edge of the hob.

Improper use of the grids can result in damage to

the hob: do not position the grids upside down or slide

them across the hob.

Do not let the burner ame extend beyond the edge of the pan.

If the hob surface is in glass material, do not use the cast iron griddles, ollar

stones, terracotta pots and pans.

Do not use: heat diusers such as metal mesh, or any other types; two burners

simultaneously for one receptacle (e.g. Fish kettle).

Should particular local conditions of the delivered gas make the ignition of

burner dicult, it is advisable to repeat the operation with the knob turned to

small ame setting.

In case of installation of a hood above the cooktop, please refer to the hood

instructions for the correct distance.

The protective rubber feet on the grids represent a choking hazard for young

children. After removing the grids, please ensure that all the feet are correctly

tted.

INSTALLATION

The appliance must be handled and installed by two

or more persons - risk of injury. Use protective gloves to

unpack and install - risk of cuts.

The electrical and gas connections must comply

with local regulation.

Installation, including water supply (if any) and

electrical connections, and repairs must be carried out

by a qualied technician. Do not repair or replace any

part of the appliance unless specically stated in the

user manual. Keep children away from the installation

site. After unpacking the appliance, make sure that it

has not been damaged during transport. In the event

of problems, contact the dealer or your nearest After-

sales Service. Once installed, packaging waste (plastic,

SAFETY INSTRUCTIONS

IMPORTANT TO BE READ AND OBSERVED

styrofoam parts etc.) must be stored out of reach of

children - risk of suocation. The appliance must be

disconnected from the power supply before any

installation operation - risk of electrical shock. During

installation, make sure the appliance does not damage

the power cable - risk of re or electrical shock. Only

activate the appliance when the installation has been

completed.

WARNING: Modication of the appliance and its

method of installation are essential in order to use

the appliance safely and correctly in all the additional

countries.

Use pressure regulators suitable for the gas pressure

indicated in the instruction.

The room must be equipped with an air extraction

system that expels any combustion fumes.

The room must also allow proper air circulation, as

air is needed for combustion to occur normally. The

ow of air must not be less than 2 m

/h per kW of

installed power.

The air circulation system may take air directly from

the outside by means of a pipe with an inner cross

section of at least 100 cm

; the opening must not be

vulnerable to any type of blockages.

The system can also provide the air needed for

combustion indirectly, i.e. from adjacent rooms tted

with air circulation tubes as described above. However,

these rooms must not be communal rooms, bedrooms

or rooms that may present a re hazard.

Liquid petroleum gas sinks to the oor as it is heavier

than air. Therefore, rooms containing LPG cylinders

must also be equipped with vents to allow gas to escape

in the event of a leak. As a result LPG cylinders, whether

partially or completely full, must not be installed or

stored in rooms or storage areas that are below ground

level (cellars, etc.). It is advisable to keep only the cylinder

being used in the room, positioned so that it is not

subject to heat produced by external sources (ovens,

replaces, stoves, etc. ) which could raise the temperature

of the cylinder above 50°C.

Should you experience diculty in turning the burners knobs, please contact

After Sales Service for replacement of the burner tap if found to be faulty.

The openings used for the ventilation and dispersion of heat must never be

covered.

Carry out all cabinet cutting works before tting the

appliance in the furniture and remove all wood chips

and sawdust.

If the appliance is not installed above an oven, a

separator panel (not included) must be installed in the

compartment under the appliance.

GAS CONNECTION

WARNING: Prior to installation, ensure that the local

distribution conditions (type of gas and gas pressure)

and the adjustment of the appliance are compatible.

Check that the pressure of the gas supply is consistent

with the values indicated in “Burner and nozzle

specications” table.

WARNING: The conguration conditions for this

appliance are stated on the label (or data plate).

WARNING: This appliance is not connected to a

combustion products evacuation device. It must be

installed and connected in accordance with current

installation regulations. Particular attention must be

paid to the relevant requirements regarding ventilation.

If the appliances is connected to liquid gas, the

regulation screw must be fasted as tightly as possible.

IMPORTANT: When the gas cylinder or gas container is

installed, it must be properly settled (vertical orientation).

WARNING: This operation must be performed by a

qualied technician.

Use only exible or rigid metal hose for gas connection.

Connection with a rigid pipe (copper or steel)

Connection to the gas system must be carried out in

such a way as not to place any strain of any kind on the

appliance. There is an adjustable L-shaped pipe tting

on the appliance supply ramp and this is tted with a

seal in order to prevent leaks. The seal must always be

replaced after rotating the pipe tting (the seal is

provided with the appliance). The gas supply pipe

tting is a threaded 1/2 gas cylindrical male attachment.

Connecting a exible jointless stainless steel pipe to

a threaded attachment. The gas supply pipe tting is a

threaded 1/2 gas cylindrical male attachment. These

pipes must be installed so that they are never longer

than 2000 mm when fully extended. Once connection

has been carried out, make sure that the exible metal

pipe does not touch any moving parts and is not

compressed. Only use pipes and seals that comply

with current National regulations.

IMPORTANT: If a stainless steel hose is used, it must

be installed so as not touch any mobile part of the

furniture (e.g. drawer). It must pass through an area

where there are no obstructions and where it is possible

to inspect it on all its length.

The appliance should be connected to the main gas

supply or to gas cylinder in compliance with the current

national regulations. Before making the connection,

make sure that the appliance is compatible with the gas

supply you wish to use. If this is not the case, follow the

instructions indicated in the paragraph “Adapting to

dierent types of gas”.

After connection to the gas supply, check for leaks

with soapy water. Light up the burners and turn the knobs

from maximum position 1* to minimum position 2* to

check ame stability.

ADAPTING TO DIFFERENT TYPES OF GAS

(This operation needs to be carried out by a qualied

technician).

In order to adapt the appliance to a type of gas other

than the type for which it was manufactured (indicated

on the rating label), follow the dedicated steps provided

after installation drawings.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Ovn
Model:	GOA 9523/WH
Vekselstrømsindgangsspænding:	230 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	860 mm
Dybde:	510 mm
Højde:	50 mm
Vægt:	17600 g
Produktfarve:	Hvid
Kontroltype:	Dreje
Indbygget skærm:	Ingen
Strøm:	0.2 A
Ledningslængde:	0.85 m
Pakkevægt:	20200 g
Pakkedybde:	612 mm
Pakkebredde:	960 mm
Pakkehøjde:	192 mm
Timer:	Ingen
Placering af apparat:	Indbygget
Installationsrum bredde:	840 mm
Installationsrum dybde:	490 mm
Installationsrum højde:	40 mm
Komfurtype:	Gaskomfur
Overfladetype:	Glas
Antal kogeplader / madlavningsområde:	5
Blus/kogeplade zone 1 strøm:	4800 W
Blus/kogeplade zone 2 strøm:	1750 W
Blus/kogeplade zone 1 type:	Ekstra stor
Kogezone 1 form:	Rund
Blus/kogeplade zone 1 position:	Venstre
Blus/kogeplade zone 1 strømkilde:	Gas
Blus/kogeplade zone 2 type:	Regelmæssig
Kogezone 2 form:	Rund
Blus/kogeplade zone 2 position:	Midt forside
Blus/kogeplade zone 2 strømkilde:	Gas
Kontrolposition:	Top forside
Tilsluttet belastning (elektrisk):	- W
Ovnbredde størrelse:	90 cm
Blus/kogeplade zone 3 type:	Regelmæssig
Blus/kogeplade zone 4 type:	Stor
Blus/kogeplade zone 4 strømkilde:	Gas
Kogezone 4 form:	Rund
Blus/kogeplade zone 3 strømkilde:	Gas
Kogezone 3 form:	Rund
Blus/kogeplade zone 3 position:	Midt bagende
Blus/kogeplade zone 4 position:	Højre bagende
Restvarmeindikator:	Ingen
Indbygget hætte:	Ingen
Tilsluttet belastning (gas):	12300 W
Installationsrum bredde (min.):	840 mm
Blus/kogeplade zone 5 position:	Højre forside
Blus/kogeplade zone 5 strømkilde:	Gas
Antal gasbrændere:	5
Blus/kogeplade zone 5 type:	Simre
Blus/kogeplade zone 4 strøm:	3000 W
Blus/kogeplade zone 5 strøm:	1000 W
Blus/kogeplade zone 3 strøm:	1750 W
Kogezone 5 form:	Rund
Elektronisk tænding:	Ja
Komfurlåg:	Ingen
Simre kogeplade / madlavningsområde:	1000 W
Almindelige kogeplade / madlavningsområde:	1750 W
Stor kogeplade / madlavningsområde:	3000 W
Installation, rum dybde (maks.):	490 mm
Understøttet grydemateriale:	Støbejern
Ekstra stor hurtig kogeplade / madlavningsområde:	4000 W
Tændblussikring:	Ja
Installation, rum dybde (min.):	480 mm
Elektronisk antændelsestype:	Enhåndstænding
Installationsrum bredde (maks.):	840 mm
Beskyttelse mod utilsigtet start:	Ingen
Fiskebrænder:	Ingen
Garantiperiode:	2 År
