SAFETY INSTRUCTIONS IMPORTANT TO BE READ AND OBSERVED

Download the complete instruction manual http://

docs.whirlpool.eu or call the phone number shown

on the warranty booklet

Before using the appliance, read these safety

instructions. Keep them nearby for future reference.

These instructions and the appliance itself provide

important safety warnings, to be observed at all

times. The manufacturer declines any liability for

failure to observe these safety instructions, for

inappropriate use of the appliance or incorrect

setting of controls.

These instructions are valid if the country symbol

appears on the appliance. If the symbol doesn't

appear on the appliance, it is necessary to refer to the

technical instructions which will provide the

necessary instructions concerning modication of

the appliance to the conditions of use of the country.

CAUTION : The use of the gas cooking appliance

results in the production of heat, moisture and

products of combustion in the room in which it is

installed. Ensure that the kitchen is well ventilated

especially when the appliance is in use: keep natural

ventilation holes open or install a mechanical

ventilation device (mechanical extractor hood).

Prolonged intensive use of the appliance may call for

additional ventilation, for example opening of the

window, or more eective ventilation,increasing the

level of mechanical ventilation where present.

WARNING: The appliance and its accessible parts

become hot during use. Care should be taken to

avoid touching heating elements. Children less than

8 years of age must be kept away unless continuously

supervised.

WARNING : If the hob surface is cracked, don’t use

the appliance – risk of electrical shock.

WARNING : Danger of re : Do not store items on

the cooking surfaces.

CAUTION : The cooking process has to be

supervised. A short cooking process has to be

supervised continuously.

WARNING : Unattended cooking on a hob with fat

or oil can be dangerous – risk of re. NEVER try to

extinguish a re with water, but switch o the

appliance and then cover ame e.g. with a lid or a re

blanket.

Do not use the hob as a work surface or support.

Keep clothes or other ammable materials away

from the appliance, until all the components have

cooled down completely – risk of re.

If the information in this manual is not followed

exactly, a re or explosion , may result causing

property damage or injury.

Very young children (0-3 years) should be kept

away from the appliance. Young children (3-8 years)

should be kept away from the appliance unless

continuously supervised. Children from 8 years old

and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge can use this appliance only if they are

supervised or have been given instructions on safe

use and understand the hazards involved. Children

must not play with the appliance. Cleaning and user

maintenance must not be carried out by children

without supervision.

CAUTION : In case of hotplate glass breakage:-shut

immediately o all burners and any electrical heating

element and isolate the appliance from the power

supply; - do not touch the appliance surface; -do not

use the appliance.

The glass lid can break in if it is heated up. Turn o all

the burners and the electric plates before closing the

lid. Do not shout down lid when burner alight.

PERMITTED USE

CAUTION: the appliance is not intended to be

operated by means of an external switching device,

such as a timer, or separate remote controlled system.

This appliance is intended to be used in

household and similar applications such as: sta

kitchen areas in shops, oces and other working

environments; farm houses; by clients in hotels,

motels, bed & breakfast and other residential

environments.

No other use is permitted (e.g. heating rooms).

This appliance is not for professional use. Do not

use the appliance outdoors.

Use pots and pans with bottoms the same width

as that of the burners or slightly larger (see specic

table). Make sure pots on the grates do not protrude

beyond the edge of the hob.

Improper use of the grids can result in damage to

the hob: do not position the grids upside down or

slide them across the hob.

Do not let the burner ame extend beyond the edge of the pan.

Do not use : Cast iron griddles, ollar stones, terracotta pots and pans.

Heat diusers such as metal mesh, or any other types. Two burners

simultaneously for one receptacle (e.g. Fish kettle).

Should particular local conditions of the delivered gas make the ignition of

burner dicult, it is advisable to repeat the operation with the knob turned

to small ame setting.

In case of installation of a hood above the cooktop, please refer to the hood

instructions for the correct distance.

The protective rubber feet on the grids represent a chocking hazard for

young children. After removing the grids, please ensure that all the feet are

correctly tted.

INSTALLATION

The appliance must be handled and installed by

two or more persons - risk of injury. Use protective

gloves to unpack and install - risk of cuts.

Installation, including water supply (if any) and

electrical connections, and repairs must be carried

out by a qualied technician. Do not repair or replace

any part of the appliance unless specically stated in

the user manual. Keep children away from the

installation site. After unpacking the appliance, make

sure that it has not been damaged during transport.

In the event of problems, contact the dealer or your

nearest After-sales Service. Once installed, packaging

waste (plastic, styrofoam parts etc.) must be stored

out of reach of children - risk of suocation. The

appliance must be disconnected from the power

supply before any installation operation - risk of

electrical shock. During installation, make sure the

appliance does not damage the power cable - risk of

re or electrical shock. Only activate the appliance

when the installation has been completed.

The electrical and gas connections must comply

with local regulation.

WARNING : Modication of the appliance and its

method of installation are essential in order to use

the appliance safely and correctly in all the additional

countries.

Use pressure regulators suitable for the gas

pressure indicated in the instruction.

The room must be equipped with an air extraction

system that expels any combustion fumes.

The room must also allow proper air circulation, as

air is needed for combustion to occur normally. The

ow of air must not be less than 2 m3/h per kW of

installed power.

The air circulation system may take air directly

from the outside by means of a pipe with an inner

cross section of at least 100 cm2; the opening must

not be vulnerable to any type of blockages.

The system can also provide the air needed for

combustion indirectly, i.e. from adjacent rooms tted

with air circulation tubes as described above.

However, these rooms must not be communal

rooms, bedrooms or rooms that may present a re

hazard.

Liquid petroleum gas sinks to the oor as it is

heavier than air. Therefore, rooms containing LPG

cylinders must also be equipped with vents to allow

gas to escape in the event of a leak. As a result LPG

cylinders, whether partially or completely full, must

not be installed or stored in rooms or storage areas

that are below ground level (cellars, etc.). It is

advisable to keep only the cylinder being used in the

room, positioned so that it is not subject to heat

produced by external sources (ovens, replaces,

stoves, etc. ) which could raise the temperature of the

cylinder above 50°C.

Carry out all cabinet cutting works before tting

the appliance in the furniture and remove all wood

chips and sawdust.

If the appliance is Not installed above an oven, a

separator panel (not included) must be installed in

the compartment under the appliance.

Should you experience diculty in turning the burners knobs, please

contact After Sales Service for replacement of the burner tap if found to be

faulty.

The openings used for the ventilation and dispersion of heat must never be

covered.

GAS CONNECTION

WARNING : Prior to installation, ensure that the

local distribution conditions (nature of gas and gas

pressure) and the adjustment of the appliance are

compatible.

Check that the pressure of the gas supply is

consistent with the values indicated in Table 1

(“Burner and nozzle specications”).

WARNING : The adjustment conditions for this

appliance are stated on the label (or data plate).

WARNING : This appliance is not connected to a

combustion products evacuation device. It shall be

installed and connected in accordance with current

installation regulations. Particular attention shall be

given to the relevant requirements regarding

ventilation.

If the appliances is connected to liquid gas, the

regulation screw must be fastened as tightly as

possible.

IMPORTANT : When gas cylinder is adopted, the

gas cylinder or gas container must be properly

settled (vertical orientation).

WARNING : This operation must be performed by

a qualied technician

Use only exible or rigid metal hose for gas

connection.

Connection with a rigid pipe (copper or steel)

Connection to the gas system must be carried out in

such a way as not to place any strain of any kind on

the appliance. There is an adjustable L-shaped pipe

tting on the appliance supply ramp and this is tted

with a seal in order to prevent leaks. The seal must

always be replaced after rotating the pipe tting (the

seal is provided with the appliance). The gas supply

pipe tting is a threaded 1/2 gas cylindrical male

attachment.

Connecting a exible jointless stainless steel pipe

to a threaded attachment The gas supply pipe tting

is a threaded 1/2 gas cylindrical male attachment.

These pipes must be installed so that they are never

longer than 2000 mm when fully extended. Once

connection has been carried out, make sure that the

exible metal pipe does not touch any moving parts

and is not compressed. Only use pipes and seals that

comply with current National regulations.

IMPORTANT : If a stainless steel hose is used, it

must be installed so as not touch any mobile part of

the furniture (e.g. drawer). It must pass through an

area where there are no obstructions and where it is

possible to inspect it on all its length.

The appliance should be connected to the main

gas supply or to gas cylinder in compliance with the

current National regulations. Before carry out the

connection, make sure that the appliance is

compatible with the gas supply you wish to use. If

this is not the case, follow the instructions indicated

in the paragraph “Adapting to dierent types of gas”.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Komfur
Model:	GOWL 758/NB
Vekselstrømsindgangsspænding:	220-240 V
Vekselstrømsindgangsfrekvens:	50-60 Hz
Bredde:	730 mm
Dybde:	510 mm
Højde:	51 mm
Vægt:	15200 g
Produktfarve:	Sort
Kontroltype:	Dreje
Indbygget skærm:	Ingen
Strøm:	0.2 A
Ledningslængde:	8.5 m
Placering af apparat:	Indbygget
Installationsrum bredde:	560 mm
Installationsrum dybde:	490 mm
Komfurtype:	Gaskomfur
Overfladetype:	iXelium
Antal kogeplader / madlavningsområde:	5
Blus/kogeplade zone 1 strøm:	3000 W
Blus/kogeplade zone 2 strøm:	1000 W
Blus/kogeplade zone 1 type:	Stor
Kogezone 1 form:	Rund
Blus/kogeplade zone 1 position:	Venstre bagende
Blus/kogeplade zone 1 strømkilde:	Gas
Blus/kogeplade zone 2 type:	Simre
Kogezone 2 form:	Rund
Blus/kogeplade zone 2 position:	Venstre front
Blus/kogeplade zone 2 strømkilde:	Gas
Kontrolposition:	Front
Nem at rengøre:	Ja
Tilsluttet belastning (elektrisk):	- W
Ovnbredde størrelse:	75 cm
Blus/kogeplade zone 3 type:	Ekstra stor
Blus/kogeplade zone 4 type:	Regelmæssig
Blus/kogeplade zone 4 strømkilde:	Gas
Kogezone 4 form:	Rund
Blus/kogeplade zone 3 strømkilde:	Gas
Kogezone 3 form:	Rund
Blus/kogeplade zone 3 position:	Central
Blus/kogeplade zone 4 position:	Højre bagende
Indbygget hætte:	Ingen
Tilsluttet belastning (gas):	12300 W
Blus/kogeplade zone 5 position:	Højre forside
Blus/kogeplade zone 5 strømkilde:	Gas
Antal gasbrændere:	5
Blus/kogeplade zone 5 type:	Regelmæssig
Blus/kogeplade zone 4 strøm:	1750 W
Blus/kogeplade zone 5 strøm:	1750 W
Blus/kogeplade zone 3 strøm:	4000 W
Kogezone 5 form:	Rund
Understøttet grydemateriale:	Støbejern
Wokbrænder:	Ja
Beskyttelse af termoelement:	Ja
Wokbrændeposition:	Midten
