Quick guide

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

PRODUCT DESCRIPTION

1. Control panel

2. Fan

3. Shelf guides

(the level is indicated on the front

of the oven)

4. Door

5. Upper heating element/grill

6. Lamp

7. Identification plate

(do not remove)

8. Lower heating element

(not visible)

CONTROL PANEL DESCRIPTION

2 3 4 5

1. SELECTION KNOB

For switching the oven on by

selecting a function. Turn to the “0”

position to switch the oven off.

2. BACK

For returning to the previous screen.

During cooking allows to change

settings.

3. DISPLAY

4. CONFIRM

For confirming a selected function

or a set value.

5. ADJUSTMENT KNOB

For scrolling through the menus and

applying or changing settings.

Please note: The knobs are retractable.

Press the knobs in the middle and they

pop up.

ACCESSORIES

WIRE SHELF BAKING TRAY DRIP TRAY * SLIDING RUNNERS *

Use to cook food or as a

support for pans, cake tins

and other ovenproof items of

cookware

Use for cooking all bread and

pastry products, but also for

roasts, sh en papillotte, etc.

Use as an oven tray for

cooking meat, sh,

vegetables, focaccia, etc. or

position underneath the wire

shelf to collect cooking juices.

To facilitate inserting or

removing accessories.

TURNSPIT *

* Available only on certain models

The number and the type of accessories may vary depending on which model is purchased.

Other accessories can be purchased separately from the After-sales Service.

For even roasting of large

pieces of meat and poultry.

INSERTING THE WIRE SHELF AND OTHER

ACCESSORIES

Insert the wire shelf horizontally by sliding it across the

shelf guides, making sure that the side with the raised

edge is facing upwards.

Other accessories, such as the drip tray and the baking

tray, are inserted horizontally in the same way as the

wire shelf.

REMOVING AND REFITTING THE SHELF GUIDES

• To remove the shelf guides, lift the guides up and

then gently pull the lower part out of its seating: The

shelf guides can now be removed.

• To refit the shelf guides, first fit them back into their

upper seating. Keeping them held up, slide them

into the cooking compartment, then lower them into

position in the lower seating.

FITTING THE SLIDING RUNNERS IF PRESENT

Remove the shelf guides from the oven and remove the

protective plastic from the sliding runners.

Fasten the upper clip of the runner to the shelf guide

and slide it along as far as it will go. Lower the other

clip into position. To secure the guide, press the lower

portion of the clip firmly against the shelf guide. Make

sure that the runners can move freely. Repeat these

steps on the other shelf guide on the same level.

Please note: The sliding runners can be tted on any level.

USING THE TURNSPIT IF PRESENT

Push the skewer through the centre of the meat

(bound with string if poultry) and slide the meat onto

the skewer until it is positioned firmly on the fork and

cannot move. Push the second fork onto the skewer

and slide it on until it holds the meat firmly in place.

Tighten the fixing screw to secure it in position. Insert

the end into the recess provided in the oven’s cooking

compartment and rest the rounded part on the relevant

support.

Please note: To collect the cooking juices, position the drip

tray below and add 500 ml of water. To avoid burning yourself

when the skewer is hot, only handle it by the plastic handle

(which must be removed before cooking).

The use of this accessory is allowed only in combination

with the Turbogrill function.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Ovn
Model:	OAKZ9 379 P IX
Afrimningsfunktion:	Ja
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	595 mm
Dybde:	564 mm
Højde:	595 mm
Produktfarve:	Rustfrit stål
Kontroltype:	Rotary, Touch
Indbygget skærm:	Ja
Skærmtype:	LCD
Ledningslængde:	0.9 m
Placering af apparat:	Indbygget
Indvendig belysning:	Ja
Dørhængsel:	Ned
Installationsrum bredde:	568 mm
Installationsrum dybde:	550 mm
Installationsrum højde:	585 mm
Grill:	Ja
Konvektion madlavning:	Ja
Døråbningsvinkel:	80 °
Energieffektivitetsskala:	A+++ til D
Selvrensende:	Ja
Installationsrum højde (min.):	583 mm
Kontrolposition:	Top forside
Wi-Fi kontrolleret:	Ingen
Rengøringstype:	Pyrolyse
Ovn - størrelse:	Medium
Ovntype:	Elektrisk ovn
Samlet indvendig ovn kapacitet:	73 L
Strøm for samtlige ovne:	3650 W
Antal ovne:	1
Ovn nettokapacitet:	73 L
Holde varm funktion:	Ja
Pizza fremstillingsfunktion:	Ja
Energiforbrug (konventionel):	0.91 kWh
Energiforbrug (tvungen konvektion):	0.82 kWh
Udtrækkelige drejeknapper:	Ja
Ovndør åbning:	Dropdown åbning
Dørmateriale:	Glass, Metal
Installationsrum bredde (min.):	560 mm
Teleskopskinne medfølger:	Ja
Indvendig materiale:	Emalje
Håndtag farve:	Rustfrit stål
Knapper, farve:	Sølv
Hurtig start:	Ja
