Quick guide

SLIDING RUNNERS AND SHELF GUIDES

Before using the oven remove the protective tape [a] and then

remove the protective foil [b] from the sliding runners.

REMOVING THE SLIDING RUNNERS [c]

Pull the lower part of the sliding runner to uncouple the lower

hooks (1) and pull the the sliding runners upwards, removing

them from the upper hooks (2).

REFITTING THE SLIDING RUNNERS [d]

Hook the upper hooks on the shelf guides (1) then press the

lower part of the sliding runners against the shelf guides, until

the lower hooks are clicking (2).

[c] [d]

REMOVING AND REFITTING THE SHELF GUIDES

1. To remove the shelf guides, rmly grip the external part of

the guide, and pull it towards you to extract the support and

the two internal pins from the lodging.

2. To reposition the shelf guides, position them near the cavity

and initially insert the two pins into their lodgings. Next,

position the external part near its lodging, insert the support,

and rmly press towards the wall of the cavity to make sure

the shelf guide is properly secured.

FIRST TIME USE

1. SETTING THE TIME

You will need to set the time when you switch on the

appliance for the rst time: Press until the icon and the

two digits for the hour start ashing on the display.

Use

or to set the hour and press to conrm. The

two digits for the minutes will start ashing. Use or to

set the minutes and press to conrm.

Please note: When the icon is ashing, for example following

lengthy power outages, you will need to reset the time.

2. HEAT THE OVEN

A new oven may release odours that have been left behind

during manufacturing: this is completely normal.

Before starting to cook food, we therefore recommend

heating the oven with it empty in order to remove any

possible odours. Remove any protective cardboard or

transparent lm from the oven and remove any accessories

from inside it.

Heat the oven to 250 °C for about one hour. The oven must be

empty during this time.

CONTROL PANEL DESCRIPTION

1 32 4 5

1. SELECTION KNOB

For switching the oven on by selecting

a function. Turn to the position to

switch the oven o.

2. LIGHT

With the oven switched on, press

to turn the oven compartment lamp on

or o.

3. SETTING THE TIME

For accessing the cooking time settings,

delayed start and timer.

For displaying the time when the oven

is o.

4. DISPLAY

5. ADJUSTMENT BUTTONS

For changing the cooking time settings.

6. THERMOSTAT KNOB

Turn to select the temperature you

require when activating manual

functions.

Please note: The knobs are retractable. Press

the knobs in the middle and they pop up.

THANK YOU FOR BUYING A WHIRLPOOL

PRODUCT

In order to receive a more complete

assistance, please register your product on

ww w . whirlpool . eu/register

Before using the appliance carefully read the Safety

Instruction.

FUNCTIONS & DAILY USE

CONVENTIONAL

For cooking any kind of dish on one shelf only.

FORCED AIR

For cooking dierent foods that require the same

cooking temperature on several shelves (maximum three) at

the same time. This function can be used to cook dierent

foods without odours being transferred from one food to

another.

AUTOMATIC CLEANING - PYRO

For cooking large joints of meat (above 2.5kg). We

recommend turning the meat over during cooking to ensure

that both sides brown evenly. We also recommend basting the

joint every so often to prevent it from drying out excessively.

PIZZA

For baking dierent types and sizes of pizza and bread.

It is a good idea to swap the position of the baking trays

halfway through cooking.

GRILL

For grilling steaks, kebabs and sausages, cooking

vegetables au gratin or toasting bread.

When grilling meat, we recommend using a dripping pan

to collect the cooking juices: position the pan on any of the

levels below the wire shelf and add 200 ml of drinking water.

TURBO GRILL

For roasting large joints of meat (legs, roast beef,

chicken). We recommend using a dripping pan to collect the

cooking juices: position the pan on any of the levels below the

wire shelf and add 200 ml of drinking water.

RISING

For helping sweet or savoury dough to rise eectively.

Turn the thermostat knob to the icon to activate this function.

ECO FORCED AIR

For cooking roasts and stued roasting joints on a

single shelf. Food is prevented from drying out excessively by

gentle, intermittent air circulation.

When this ECO function is in use, the light will remain

switched o during cooking but can be switched on again by

pressing

FISH

MEAT

BREAD

The functions provide excellent results thanks to

the addition of steam in cooking cycles. Only when the oven

is cold, pour drinking water on the bottom of the oven and

select the specic function for your preparation. The optimal

water quantities and temperatures for each food category are

listed in the relative cooking table. Do not preheat the oven

before inserting food.

1. SELECT A FUNCTION

To select a function, turn the selection knob to the symbol

for the function you require: the display will light up and an

audible signal will sound.

2. ACTIVATE A FUNCTION

MANUAL

To start the function you have selected, turn the thermostat

knob to set the temperature you require.

Please note: During cooking you can change the function by

turning the selection knob or adjust the temperature by turning the

thermostat knob. The function will not start if the thermostat knob

will be on . You can set the cooking time, cooking end time (only

if you set a cooking time) and a timer.

RISING

To start the “Rising” function, turn the thermostat knob to the

relevant symbol; if the oven is set to a dierent temperature,

the function will not start.

Please note: You can set the cooking time, cooking end time (only if

you set a cooking time) and a timer.

Only when the oven is cold, ll

the embossing of the cavity

with the quantity of drinking

water suggested in the relative

cooking table. Place the food

in the oven.

Set and activate the

function: At the end, carefully

open the door and let steam

escape slowly.

Please note: During steam

cooking, do not open the door

and never top up the water.

3. PREHEATING AND RESIDUAL HEAT

Once the function starts, an audible signal and a ashing icon

on the display indicate that the preheating phase has

been activated.

At the end of this phase, an audible signal and the xed icon

on the display will indicate that the oven has reached

the set temperature: at this point, place the food inside and

proceed with cooking.

Please note: Placing the food in the oven before preheating has

nished may have an adverse eect on the nal cooking result.

After cooking and with the function deactivated, the icon

may continue to remain visible on the display even after the

cooling fan has switched o to indicate that there is residual

heat in the compartment.

Please note: It is advisable to air the room after using the appliance

for the rst time.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Ovn
Model:	OAS KC8V1SW IX
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	595 mm
Dybde:	551 mm
Højde:	595 mm
Vægt:	26900 g
Produktfarve:	Black, Stainless steel
Kontroltype:	Rotary, Touch
Indbygget skærm:	Ja
Skærmtype:	TFT
Strøm:	13 A
Pakkevægt:	28200 g
Pakkedybde:	650 mm
Pakkebredde:	640 mm
Pakkehøjde:	670 mm
Placering af apparat:	Indbygget
Dørhængsel:	Ned
Integreret ur:	Ja
Urtype:	Elektronisk
Installationsrum bredde:	568 mm
Installationsrum dybde:	560 mm
Installationsrum højde:	585 mm
Grill:	Ja
Damp madlavning:	Ja
Konvektion madlavning:	Ingen
Energieffektivitetsskala:	A+++ til D
Selvrensende:	Ja
Installationsrum højde (min.):	583 mm
Kontrolposition:	Front / Top front
Timer type:	Digital
Wi-Fi kontrolleret:	Ingen
Rengøringstype:	Katalytisk
ECO-tilstand:	Ja
Antal glasdørpaneler:	2
Varmebeskyttende dør:	Ja
Ovn - størrelse:	Medium
Ovntype:	Elektrisk ovn
Samlet indvendig ovn kapacitet:	71 L
Strøm for samtlige ovne:	2900 W
Antal ovne:	1
Ovn nettokapacitet:	71 L
Ovn termostatinterval:	0 - 250 °C
Konventionel madlavning:	Ja
Pizza fremstillingsfunktion:	Ja
Energiforbrug (konventionel):	0.89 kWh
Energiforbrug (tvungen konvektion):	0.69 kWh
Dør med blød lukning:	Ja
Udtrækkelige drejeknapper:	Ja
Bageplade:	Ja
Mikroovn madlavning:	Ingen
Blæser grillfunktion:	Ja
Ovndør åbning:	Dropdown åbning
Kontrolpanel materiale:	Metal
Antal bageplader:	3
Antal hylder:	1 hylder
Dørmateriale:	Glas
Installationsrum bredde (min.):	560 mm
Varmluft grill:	Ja
Håndtag farve:	Rustfrit stål
Knapper, farve:	Rustfrit stål
Turbo-tilstand:	Ja
Flertrins madlavning:	Ja
Katalytiske foringer på sidevægge:	Ja
