Whirlpool W5 721E OX 2 Manual

Whirlpool Køleskab W5 721E OX 2

Læs gratis den danske manual til Whirlpool W5 721E OX 2 (3 sider) i kategorien Køleskab. Denne vejledning er vurderet som hjælpsom af 33 personer og har en gennemsnitlig bedømmelse på 3.7 stjerner ud af 17 anmeldelser. Har du et spørgsmål om Whirlpool W5 721E OX 2, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/3

Quick guide

* Available only on certain models

THANK YOU FOR BUYING A WHIRLPOOL PRODUCT

In order to receive a more complete assistance, please

Before using the appliance carefully read the Safety

Instruction.

PRODUCT DESCRIPTION

FIRST TIME USE

Wait at least two hours, after the installation, before connecting

the appliance to the power supply. Connect the appliance to the

power supply it starts the operation automatically. The ideal storage

temperatures for the food are preset in the factory.

After turning the appliance on, you must wait for 4-6 hours for the

correct storage temperature to be reached for a normally lled

appliance.

CONTROL PANEL

1. Indicator Leds (to display the current temperature set point or the Fast Cooling

function)

2. Fast Cooling Button / Temperature Button

TEMPERATURE SETTING

Press the Temperature button on the control panel to adjust the

temperature from the warmest through the lower to the coldest

level. Pressing the Temperature button, the temperature setting will

change cyclically. At rst plug-in of appliance temperature setpoint is

present at medium position (factory setting). Following table shows

temperature setpoints:

OFF ON

Hightemp.

Med-high temp.

Medium temp.

Med-low temp.

Low temp.

Fast cooling

Note: Displayed set points correspond to the average temperature

throughout the whole refrigerator.

FAST COOLING

The use of the Fast Cooling function is recommended to increase the

cooling capacity of the refrigerator compartment when placing a very

high quantity of food within it.

To activate the Fast Cooling function, press and hold for 3 seconds the

Temperature button on the control panel till all the 3 LEDs will turn on.

The function is automatically deactivated after 24 hours and return to

previous selected set point.

The function can be manually deactivated by pressing and holding for

3 seconds the Temperature button on the control panel.

Note: Fast Cooling function should be also switched ON before placing

fresh food to be frozen in the freezer compartment, in order to maximize

the freezing capacity.

FAN*

The Fan improves temperature distribution inside the product,

allowing better preservation of stored food.

By default, the fan is switched on. To turn o the fan press the button

located on the bottom right corner of fan housing. If the ambient

temperature exceeds 27°C, or if drops of water are present on the

glass shelves, it is essential that the fan is on to ensure the proper

preservation of the food. Deactivation of the fan allows energy

consumption to be optimised. Please note that when the fan is

switched on it will not continuously work. The fan will start/stop

working depending on the temperature and/or humidity level inside

the fridge.

If the appliance has the Fan it can be equipped with the antibacterial

lter. Visit the website page or contact consumer service to purchase

the lter.

LED LIGHT

If the LED light system does not work, please contact the Service to

replace it.

Important: The refrigerator compartment light switches on when

the refrigerator door is opened. If the door is kept open for more than

8 minutes the light will be automatically switched o.

HUMIDITY CONTROL *

Open the humidity regulator (position B) if you want to store food in a

less humid environment like fruit, or close it (position A) to store food

in a more humid environment like vegetable.

TUCK SHELF *

Thanks to the rail system, this shelf allows you to slide under the front

part, creating an extra space for storing tall bottles or pitchers.

NO-FROST REFRIGERATOR COMPARTMENT

Refrigerator compartment defrosting is completely automatic. Droplets

of water on the rear wall inside the refrigerator compartment indicate

that the automatic defrost phase is in progress.

The defrost water is automatically run into a drain hole and collected in

a container, where it evaporates.

DEFROSTING THE FREEZER COMPARTMENT

The freezer should be defrosted once or twice a year or when excessive

frost is present (3 mm thickness). The formation of frost is normal.

The amount and rate at which frost accumulates depends on room

conditions and how often the door is open. To defrost the unit, switch

o the product and take out all food.

Leave the freezer door open to allow the frost to melt.

Use the box under the bottom front of the appliance to collect water

(showed on the gure).

Clean the inside of the freezer. Rinse and dry thoroughly. Switch the

appliance back on and store the food inside.

STOP FROST ACCESSORY

The STOP FROST accessory is designed to collect some of the frost that

forms in the freezer compartment and it is easy to remove and clean,

therefore reducing the time needed to defrost the inside of the freezer

compartment.

HOW TO USE THE APPLIANCE

Legend

TEMPERATE ZONE

Suggested for storage of tropical fruit, cans, drinks,

eggs, sauces, pickles, butter, jam

COOL ZONE

Suggested for the storage of cheese, milk, daily food,

delicatessen, yogurt

FRUIT & VEGETABLE DRAWER

FREEZING ZONE DRAWER

(Max cool zone)

Suggested to freeze fresh / cooked food.

FREEZER DRAWERS

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Køleskab
Model:	W5 721E OX 2
Bredde:	595 mm
Dybde:	655 mm
Højde:	1763 mm
Produktfarve:	Rustfrit stål
Lampe type:	LED
Strøm:	1.2 A
Årligt energiforbrug:	233 kWh
Placering af apparat:	Fritstående
Dørhængsel:	Højre
Tilsluttet belastning:	150 W
Støjniveau:	39 dB
Justerbare fødder:	Ja
Energieffektivitetsskala:	A til G
Støjemissionsklasse:	C
Energieffektivitetsklasse:	E
Vendbare døre:	Ja
Fryser, netto rumindhold:	111 L
Frysekapacitet:	5 kg/24t
Opbevaringstid under strømafbrydelse:	24 t
Fingeraftryk resistent:	Ja
Køleskab antal hylder/kurve:	4
Antal grøntsagsskuffer:	1
Køleskabsdøre:	3
Køleskab, netto rumindhold:	197 L
Total netto kapacitet:	308 L
No Frost (køleskab):	Ingen
Køleskab indvendigt lys:	Ja
Stjernebedømmelse:	4*
Fryser position:	Bottom-placeret
Automatisk afrimning (fryser):	Ja
Hylder, materiale:	Hærdet glas
Ismaskine:	Ingen
Flaskeholder:	Ja
Hurtig frys funktion:	Ja
Fryser antal hylder/kurve:	3
Åben dør alarm:	Ja
Frisk zone, aflukke:	Ja
Automatisk afrimning (køleskab):	Ingen
Antal aftagelige hylder:	3
Afrimning vandafløb:	Ja
