THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.

In order to receive a more complete assistance, please

Policies, standard documentation, ordering of spare parts and additional product information can be

found by:

• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com

• Using QR Code

• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When

contacting our After-sales Service, please state the codes provided on your product’s identiﬁ cation plate.

Quick guide

Before using the appliance carefully read the Safety

Instruction.

xxxxxxxxxxxx

xxxx

Eco Monitor

This indicator shows the energy consumption level according to

the programme and the options set. The consumption is

proportional to the lines on the display, by the ecomonitor icon.

OPENING THE DOOR DURING THE CYCLE

Laundry can be checked while the drying cycle runs and any

garments already dry can be removed, while drying continues for

the remaining items. After closing the door, press the "Start/Pause"

button to resume machine operation.

Keep the door closed until the cycle end to save time and energy.

NAVIGATION

The "UP" and "DOWN" buttons are used to navigate the available

menus.

• Press the button to conﬁrm the selection.

• Press the option button at the symbol, where present on the

display, to return to the previous screen.

If no selection is conrmed, after about 10 seconds, the display

return to the main screen.

SETTINGS

To access the Settings menu, press and hold the relevant button for a

few seconds.

• Set language shows the available languages on the display.

• Sounds allows to enable or disable the sounds (some sounds, as

warnings, will remain active anyway).

• Brightness allows to modify the display brightness.

• Factory Default allows to reset the default settings. After having

selected the setting, press and hold the button for a few

seconds.

FIRST TIME USE

When starting the appliance the ﬁrst time, the control panel will

automatically show the set language menu. The UP and DOWN

buttons are used to show the languages available in the

machine. Press the button to conﬁrm. The machine cannot be

used without having selected the language.

Make sure that the water tank is correctly inserted.

The dryer must be installed in a room with a temperature

ranging between 5°C and 35°C to ensure proper operation.

Before using the dryer make sure it has been in an upright

position for at least 6 hours.

Should you wish to change the opening side of the door, please

contact our After-sales Service. (See phone number in the

warranty booklet).

DAILY USE

Doing this will keep your machine working at its BEST:

- remember to empty your water tank after each drying cycle.

- remember to clean your lters after each drying cycle.

Refer to the Care & Maintenance section.

1. Plug the dryer into the power supply socket.

2. Open the door and load garments; always refer to instructions on

clothing labels and the max loads indicated in the programme

section. Empty pockets. Make sure garments do not get caught

between the door and/or the door filter. Do not load items that

are dripping wet. Do not tumble dry large, very bulky items.

3. Close the door.

4. Press the "On/Off" button.

5. Select the most suitable programme

for the type of fabric in that

load.

6. Select the options, if necessary.

7. Press the "

Start/Pause"

button to begin drying.

8. At the end of the drying cycle, a buzzer will beep. An indicator on

the control panel signals the end of the cycle. Pull the load out

immediately to prevent the formation of creases on laundry.

9. Turn the machine off by pressing the "On/Off" button, open the

door and pull the clothing out. If the machine is not switched off

manually, after about a quarter of an hour from the end of the

cycle , the appliance turns off automatically to save energy.

Note that some programme/option accords with "Crease Care"

system. This means that for some hours, after the end of the

drying cycle, the drum rotates at regular intervals to prevent the

formation of creases.

In case of power failure, it is necessary to press the "Start/Pause"

button to restart the cycle.

CARE LABEL

Always check the care labels, especially when placing garments in

the tumble dryer for the ﬁ rst time. Below are the most commonly

used symbols:

May be tumble dried.

Do not tumble dry.

Tumble dry – high heat.

Tumble dry – low heat.

INDICATORS

Cycle phase: Drying - Cool Down

Empty water tank - Clean secondary lter - Clogged door lters - Autoclean - Eco Monitor

Refer to Troubleshooting section:

Failure call After-sales Service -

DEMO

Demo Mode

CONTROL PANEL

1 Programme selection knob

2 On/Oﬀ button

3 Start/Pause button

Options buttons

4 FreshCare+

5 Cycle End Signal

6 Rapid

7 Cycle Options (hold for Settings)

8 Dryness Level

9 Timed Drying

10 Start Delay

Navigation buttons and Key Lock

11 UP

12 DOWN

13 CONFIRM (hold for Key Lock)

SYNTHETICS

1:35

-:--

8 9 10

PROGRAMS

The duration of these programs will depend on the size of the

load, types of textiles, the spin speed used in your washer and

any extra options selected. In machines equipped with display,

the duration of the cycles is shown on the control panel. The

remaining time is constantly checked and adjusted during the

drying cycle to show the best possible estimate.

Option to use - If all your loads on Automatic Cycles are

consistently less dry or more dry than you would like, you may

increase or decrease the dryness level using the speciﬁc option.

Eco Cotton kg Max*

This is the most eﬃcient programme in terms of energy

consumption and is suitable for drying normal wet cotton

laundry. The values on the Energy Label are based on this

programme.

NOTE: for optimal energy eﬃciency, select “Cupboard Dry” using

dryness level option. To increase the dryness level, select “Extra Dry”.

Mixed kg 4

This programme is ideal for drying cotton and synthetic

fabrics together.

Synthetics kg 4

For drying synthetic fabrics.

Wool kg 1

Programme for drying wool clothes. It is advisable to turn the

items inside out before drying. If heavy edges remain damp, leave

them to dry naturally.

Delicates kg 2

For drying delicate laundry requiring gentle treatment.

Mixed Colors kg 3

Programme for the gentle drying of coloured fabrics.

Bed Linen kg Max*

This programme is intended for drying cotton sheets.

Duvet

Programme intended to dry bulky items, such as a single duvet.

Easy Ironing

This cycle relaxes ﬁbres, thus making ironing and folding

easier. Suitable for small load of damp or dry cotton and cotton

blend fabrics. Not for wet items.

More Cycles

•

Microber kg 2

Gentle drying for microﬁber.

•

Towels kg Max*

For drying sturdy cotton laundry, such as terry towels.

•

Tecnhical Wear kg 4

For drying synthetics or cotton technical wear.

•

Down Jackets kg 2

To dry down jackets, restoring their natural softness (2 jackets).

•

Mats kg 3

To dry small bath or kitchen mats. Do not dry mats with

plastic parts, as this could cause a ﬁre hazard.

•

Lingerie kg 2

To dry very delicate underwear. Close all hooks before drying.

•

Cuddly Toys

This cycle preserves the appearance of cuddly toys, keeping

them at their best. Remove all accessories before proceeding with

drying. Each single piece must not exceed 600 gr.

Sport kg 4

For drying synthetics or cotton sports garments.

Jeans kg 3

For drying sturdy cotton including denim trousers and jackets.

Shirts kg 3

This is a programme for cotton or cotton blend/synthetics shirts.

Rapid 30' kg 0.5

Ideal for drying cotton garments spun at high speed in the

washing machine.

Refresh

A short programme suitable for refreshing ﬁbres and

garments through the emission of fresh air. Do not use on wet

items. It can be used on with any load size but is more eﬀective

with small loads. It lasts about 20 minutes.

OPTIONS

These buttons allow you to personalise the selected programme

according to personal requirements.

Not all options are available for all programmes. Some options

may be incompatible with ones you have previously set; if so,

you will be alerted by the buzzer and/or blinking indicators.

If the option is available, the option indicator will stay on. The

programme may retain some options selected in previous drying

cycles.

Dryness Level

Press the relevant button several times to obtain a diﬀerent

level of residual moisture on your laundry. The display signals the

level being selected. After few seconds of inactivity, the display

returns to the main menu.

Iron Dry: very delicate drying. Items will be more easily

ironed immediately after the cycle.

Hanger Dry: a level intended for delicate garments ready

to be hanged.

Cupboard Dry: the laundry is ready to be folded and put

away.

extra

Extra Dry: for laundry intended to be worn at the end of

the cycle.

Timed Drying

This option is to manually set the drying time. Press the

corresponding button to set the required time for drying. An

indicator on the control panel signals the time being selected.

Start Delay

This option is for delaying the start of the cycle. Press the

corresponding button several times to ﬁnd the required delay.

Once the max time is reached, the option is reset by pressing

the button again. An indicator on the control panel signals the

time being selected. After pressing the "Start/Pause" button, the

machine signals the time remaining to the start of the cycle. If the

door is opened, press the "Start/Pause" button once the door has

been closed.

FreshCare+

If laundry is left inside of the drum once the cycle

has ended, it can be subjected to bacterial proliferation. This

option helps to prevent this from happening by controlling the

temperature and gently rotating the drum. This will continue for

up to 6 hours after the end of the cycle. This setting will remain in

the memory of the previous cycle. If this is used alongside Start

Delay, a crease treatment will be perfomed during this phase by

periodic rotations of the drum.

Rapid

Enables quicker drying.

Key Lock

This option makes all machine controls inaccesible, except

the "On/Oﬀ" button. When the machine is on:

• to activate the option, keep the button pressed until the

machines signals that the option has been enabled.

• to disable the option, keep the button pressed until the

machine signals that the option has been disabled.

This option remains in memory if selected in previous drying.

Cycle End Signal

This option activates a prolonged buzzer at the end of the

cycle. Enable it if you do not think you will hear the normal sound

at the end of the cycle. After having pressed the option button, it

can be enabled or disabled using the "UP" and "DOWN" buttons.

Press the button to conﬁrm.

This option remains in memory, if selected in previous drying.

Cycle Option

This button provides access to the menu of options below. Scroll

the options with the “UP” and “DOWN” buttons and press the

button to conﬁrm the selection.

•

Gentle

Enables a more gentle treatment of the laundry by

reducing the drying temperature.

•

Anti Tangle

This option performes a special drum movement that

reduces tangling and knotting of your clothes. It gives best results

when used with smaller loads.

*MAX LOAD 8 Kg (Dry load)

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Tørretumbler
Model:	W6 D84WB EE
Vekselstrømsindgangsspænding:	220 - 240 V
Vekselstrømsindgangsfrekvens:	50 Hz
Bredde:	597 mm
Dybde:	656 mm
Højde:	849 mm
Vægt:	50500 g
Produktfarve:	Hvid
Kontroltype:	Rotary, Touch
Indbygget skærm:	Ja
Skærmtype:	LCD
Strøm:	10 A
Ledningslængde:	1.5 m
Årligt energiforbrug:	176 kWh
Placering af apparat:	Fritstående
Dørhængsel:	Højre
Tilsluttet belastning:	700 W
Støjniveau:	62 dB
Ilægningstype:	Front-læsning
Tromlekapacitet:	8 kg
Forsinket start-timer:	Ja
Near Field Communication (NFC):	Ingen
Børnesikring:	Ja
Justerbare fødder:	Ja
Tromle volumen:	120 L
Dør farve:	Sort
Cyklustid:	190 min.
Energieffektivitetsskala:	A+++ til D
Selvrensende:	Ingen
Indikator for resterende tid:	Ja
Indikator for fuld vandtank:	Ja
Wi-Fi kontrolleret:	Ingen
Tørreprogrammer:	Bedding, Blanket, Blouse/shirt, Cotton, Iron dry, Jeans/denim, Lingerie, Microfiber, Mix, Synthetics
Tørresystem:	Varmepumpe
Anti-krølle funktion:	Ja
Energiforbrug:	- kWh
Varmekilde:	Elektrisk
Lydalarm:	Ja
Justerbart tørringsniveau:	Ja
Dørstil:	Uigennemsigtig dør
