Side 1/8

Gas Dryer

PRODUCT MODEL NUMBERS

W10562360A

05/2016

WGD4800B, WGD4810B, WGD4850B, WGD4890B,

WGD5500B, WGD5800B, WGD5810B, WGD4870B,

WGD5000D, WGD4810E, WGD4815E, WGD4915E,

WGD4975E, WGD4616F, WGD4916F

29" Wide Models

Dryer Dimensions

A B

22 3/4"

(578 mm)

273/4"

(705 mm)

A. Wide opening side-swing door

B. Wide opening hamper door

NOTE: Leveling legs should be 1/2" (13 mm) (to match height of

3.6 cu. ft. capacity washer) or 1½" (38 mm) (to match height of

3.8 cu. ft. capacity washer).

29"

(737 mm)

43 3/8"

(1102 mm)

1/2"

(13 mm)

29"

(737 mm)

11/2"

(38 mm)

43 3/8"

(1102 mm)

Installation Spacing

A B C

18"*

(457 mm)

(25 mm)

29"

(737 mm)

(25 mm)

1"*

(25 mm)

14" max.*

(356 mm)

27¾"

(705 mm)

48 in.

(310 cm )

2*2

3"*

(76 mm)

3"*

(76 mm)

24 in.

(155 cm )

2 *

A. Recessed area

B. Side view – closet or conned area

C. Closet door with vents

*Required spacing

27" Wide Models

Dryer Dimensions

A B

223/4"

(578 mm)

291/2"

(749 mm)

133/4"

(349 mm) 291/2"

(749 mm)

A. Wide opening side-swing door

B. Wide opening hamper door

27"

(686 mm)

11/2"

(38 mm)

43"

(1092 mm)

Installation Spacing

18"*

(457 mm)

(25 mm)

27"

(686 mm)

(25 mm)

1"*

(25 mm)

14" max.*

(356 mm)

(749 mm)

½"*

(140 mm)

48 in.

(310 cm )

24 in.

(155 cm )

3"*

(76 mm)

3"*

(76 mm)

A. Recessed area

B. Side view – closet or conned area

C. Closet door with vents

*Required spacing

27 3/4"

(705 mm)

13 3/4"

(349 mm)

ELECTRICAL REQUIREMENTS

A 120-volt, 60 Hz, AC-only, 15 or 20 amp fused electrical supply is required. A time-delay fuse or circuit breaker and a separate circuit

are recommended.

GAS SUPPLY REQUIREMENTS

Gas supply: This dryer is equipped for use with Natural gas. Dryer can be converted to L.P. gas. When rigid pipe is used it should be 1/2" IPS. When

acceptable to the gas supplier and local codes, 3/8" approved tubing may be used for lengths under 20 ft (6.1 m). For lengths over 20 ft (6.1 m), larger

tubing should be used. Pipe-joint compounds resistant to the action of L.P. gas must be used. An individual manual shutoff valve must be installed

within 6 ft (1.8 m) of the dryer in accordance with the National Fuel Gas Code ANSI Z223.1.

INSTALLATION REQUIREMENTS

Installation clearances:

The location must be large enough to allow the dryer door to

open fully.

Most installations require a minimum 5½" (140 mm) clearance

behind the dryer for the exhaust vent with elbow. See “Venting

Requirements.”

Installation spacing for recessed area or closet

The dimensions shown are for the minimum spacing allowed.

■ Additional spacing should be considered for ease of installation
