To supply the required 3- or 4-wire, single phase, 120/240
volt, 60 Hz, AC only electrical supply (or 3- or 4-wire,
120/208 volt electrical supply, if specied on the serial/rating
plate) on a separate 30-amp circuit, fused on both sides of
the line. Connect to an individual branch circuit. Do not have
a fuse in the neutral or grounding circuit.
■Do not use an extension cord.
■
120 Volt, 60 Hz, AC only, 15- or 20- amp fused electrical
supply is required. A time-delay fuse or circuit breaker is
recommended. It is also recommended that a separate
circuit serving only this dryer be provided.
The Vent System Chart provides venting requirements that w
help achieve best drying performance.
NOTE: Bottom exhaust installations have a 90º turn inside th
dryer. To determine maximum exhaust length, add one 90º tu
to the chart.
■
Select route that will provide straightest and most direct
path outdoors.
■Plan installation to use fewest number of elbows and tur
■When using elbows or making turns, allow as much room
as possible.
■Bend vent gradually to avoid kinking.
■Use as few 90° turns as possible.
Determine vent length and elbows needed for best
drying performance:
■
Use following Vent System Chart to determine type of vent
material and hood combinations acceptable to use.
NOTE: Do not use vent runs longer than those specied
the Vent System Chart. Exhaust systems longer than tho
specied will:
■
Shorten life of dryer.
■Reduce performance, resulting in longer drying times and
increased energy usage.
Vent System Chart
Number of
90° elbows
Type
of vent
Box/louvered
hoods
Angled
hoods
1
4
3
2
0 Rigid metal
Rigid metal
Rigid metal
Rigid metal
Rigid metal
64 ft. (20 m)
54 ft. (16.5 m)
44 ft. (13.4 m)
35 ft. (10.7 m)
27 ft. (8.2 m)
58 ft. (17.7 m
48 ft. (14.6 m
38 ft. (11.6 m
29 ft. (8.8 m)
21 ft. (6.4 m)
Because Whirlpool Corporation policy includes a continuous commitment
to improve our products, we reserve the right to change materials and
specications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specications subject to change without notic
