Side 1/8

Quick Guide

THANK YOU FOR BUYING AWHIRLPOOL PRODUCT.

In order to receive amore complete assistance, please

SETTING MENU

1. Switch on the appliance by pressing the button.ON-OFF

2. Hold the Settings (Half Load ) button for 3 seconds, until you hear

a beep and the display shows „SEt”.

3. After one second the rst available setting (letter „ ”) will be displayed.

4. Press PREVIOUS /NEXT to scroll through the list of available settings

(see table below), then press START/Pause to view and change the

value of the currently selected setting.

5. Press PREVIOUS /NEXT to change the value, then press START/Pause

to save the new value or return to the main menu.

6. To change another setting, repeat points 4 and 5.

7. Press or wait 30 seconds to exit the menu.ON-OFF

LETTER

SETTING

VALUES

(Default - )*in bold

Cycle Counter - number of washing cycles

carried out by the dishwasher.

Eg. 25 cycles: 25;

Eg. 13.947 cycles:

13_947

(scrolling

for 3 times)

Water Hardness Level (see “SETTING THE WA-

TER HARDNESS” and “WATER HARDNESS TABLE”)

1 | 2 | | 4 | 53

Rinse Aid Level

(see “ADJUSTING THE DOSAGE OF RINSE AID”)

0 | 1 | 2 | 3 | 4 | 5

NaturalDry (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O

1 | 0

Light on the oor (see “OPTIONS AND FUNCTIONS”)

“1” = On, “0” = O

1 | 0

Sound

“1” = On, “0” = O

1 | 0

Factory Settings - START/Pausepress to re-

store to the factory default all the values of the

settings included in the settings menu.

*) The default value does not apply to the Cycle Counter.

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on

the dishes and on the machine’s functional components.

The salt reservoir is located in the lower part of the dish-

washer (under the lower rack on the left side).

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

• Salt must be lled when the SALT REFILL indicator light on the control

panel is lit.

1. Remove the lower rack and unscrew the reservoir cap (anticlockwise).

2. Position the funnel (see gure) and ll the salt reservoir right up to its

edge (approximately 0,5 kg); it is not unusual for alittle water to leak out.

3. Only the rst time you do this: ll the salt reservoir with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly so that no detergent can get into

the container during the wash program (this could damage the water sof-

tener beyond repair).

Run aprogram every time as soon as you completed relling the salt

reservoir to avoid corrosion.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on the heater, contributing also to better cleaning ef-

ciency. This system regenerates itself with salt, therefore it is required

to rell the salt container when empty.

The frequency of regeneration depends on the water hardness level setting

- regeneration takes place once per Eco cycles with the water hardness 4-6

level set to . 3

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes ~3 L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005 kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse aid dis-

penser Ashould be lled when the RINSE AID REFILL

indicator light in the control panel is lit.

1. Open the dispenser by pressing and pulling up B

the tab on the lid.

2. Pour in the rinse aid (max. 110 ml), making sure it

does not overow from the dispenser. If this hap-

pens, clean the spill immediately with adry cloth.

3. Press the lid down until you hear aclick to close it.

NEVER pour the rinse aid directly into the appli-

ance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening

device C. Introduce the detergent into the dry dis-

penser D only. Place the amount of detergent for

pre-washing directly inside the tub.

1. When measuring out the detergent refer to the

mentioned earlier information to add the proper

quantity. Inside the dispenser , there are indicaD-

tions to help the detergent dosing.

2. Remove detergent residues from the edges of the dispenser and close

the cover until it clicks.

3. Close the lid of the detergent dispenser by pulling it up until the closing

device is secured in place.

The detergent dispenser automatically opens up at the right time accord-

ing to the program.

Usage of detergent not designed for dishwashers may cause malfunc-

tion or damage to the appliance.

CONTROL PANEL

FIRST TIME USE

More information in the Daily Reference Guide on website.

Before using the appliance carefully read Safety and Installation Instructions.

After installation, please remember to remove all transport protection parts from

the dishwasher.

1. ON-OFF/Reset button with indicator light

2. PREVIOUS program button

3. NEXT program button

4. FAVOURITE button program

with indicator light

5. Salt reservoir empty indicator light

6. Rinse Aid reservoir empty indicator light

7. DESCALE indicator light

8. Closed Water Tap indicator light

9. Display

10. Program number remaining time and indicator

11. Power Clean® option button with indicator light

12. Half Load option button with indicator light/ - 3 sec. pressSettings

13. Extra Dry option button with indicator light

14. Delay option button with indicator light

15. START/Pause button with indicator light

PLEASE SCAN THE

QR CODE ON YOUR

APPLIANCE IN

ORDER TO HAVE

MORE DETAILED

INFORMATION

1 2 3 4 5 6 7 8 9 10

11 12 13

3 sec.

Quick Guide

CYCLE COUNTER - This feature shows the number of cycles the

dishwasher has performed.

For the number of cycles from 0-999, a xed number will be displayed.

Example for 25 cycles.

When the cycle number is higher than 1000, the number will scroll in

the display. The “_” represents the “

”, as for instance: 1.000 = 1_000,

13.947= 13_947 (the number will scroll for 3 times).

Example for

13.947 cycles:

After the cycle visualization, the display will return to visualize

„ ”

NOTE: The dishwasher may have already performed about 30 cycles.

This is due to the extended quality process carried out during

production. It guarantees higher product quality.

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories:

For information on comparative EN testing conditions, please send an email to the following address: dw_test_support@europeanappliances.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration by up to 20 min.

LIGHT ON THE FLOOR - A LED light projected on the oor indicates

that the dishwasher is working. The light goes o at the end of a cycle.

This feature is active by default, but it is possible to deactivate it in the

“SETTINGS MENU”.

POWER CLEAN® - Thanks to the additional power jets this option

provides a more intensive and powerful wash in the lower rack, in the

specific area. This option is recommended for washing pots and casseroles

(Please refer to the Power Clean® loading section).

EXTRA DRY - The higher temperature during the final rinse and the

extended drying phase allow improved drying. The EXTRA DRY option

results in the lengthening of the wash cycle.

DELAY - The start of the program may be delayed for a period of time

between and hours.0:30 24

The DELAY function cannot be set once a program has been started.

WATER TAP CLOSED – Alarm - Flashes when there is no inlet water or

water tap is closed.

NaturalDry - It is aconvection drying system which automatically opens

the door during/after drying phase to ensure exceptional drying perfor-

mance every day. Door opens at the temperature that is safe to your kitch-

en furniture. As additional steam protection, special designed protection

foil is added together with the dishwasher.

SENSING - When the sensor is detecting the soil level an animation

appears in the display (around 20 min.) and the cycle duration is

updated. SENSING is for the level of soiling on the dishes and is

present for all cycles (excepting Eco) adjusting the program accordingly.

HALF LOAD - If there are not many dishes to be washed, HALF LOAD is

used to save water, electricity or time, depending on the selected

program. Remember to halve the amount of detergent.

OPTIONS can be selected/ deselected, after choosing the program, directly by pressing the corresponding button (if available - the indicator

lights up) (see CONTROL PANEL). If an option is not compatible with the selected program (see PROGRAMS TABLE), the corresponding LED ashes rap-

idly 3 times and beeps will sound. The option will not be enabled. An option can change time or water or energy consumption for the program.

DESCALE – Alarm - Limescale accumulation was detected on the

internal components of the appliance. Check if the Water Hardness

Setting salt is at the correct value and is present in the salt container (see

FIRST TIME USE), then (WPro brand is recommended) use a descaling product

with Self-Clean program. After a successful descaling, the icon will stop

being displayed.

If the actions above are not performed, product performance will deteriorate.

DESCALE warning will start blinking and « » alarm will appear on the dES

display. If still no action is taken, the appliance will only allow a certain

number of cycles to be started (indicated during « » alarm display) and dES

then will be BLOCKED to prevent component damage, with only the Self-

Clean program available. Performing a full descaling will unblock the

product. In the case of extremely high amounts of limescale, descaling may

have to be performed twice to be ecient.

PROGRAMS TABLE

OPTIONS AND FUNCTIONS

Please scan on your product in order to have more detailed information.the QR code

Program Programs description

Drying

phase

NaturalDry

Available options

Duration

of wash

program

(h:min)

**)

Water

consumption

(litres/cycle)

Energy

consumption

(kWh/cycle)

Eco 50°- Program is suitable to clean normally soiled tableware, that

for this use, it is the most ecient program in terms of its combined

energy and water consumption, and that it is used to assess compli-

ance with the EU Ecodesign legislation.

4:00 9.9 0.65

Auto Intensive - 65° Automatic program for

heavily soiled dishes and pans.

Senses the level of soil-

ing on the dishes and

adjusts the program

accordingly. When the

sensor is detecting the

soil level an animation

appears in the display

and the cycle duration

is updated.

2:25-3:10 17.0-25.0 1.30-1.70

Auto Mixed - 55° Automatic program for nor-

mally soiled dishes with dried food residues.

1:20-3:20 7.5-20.5 0.75-1.20

Auto Fast - 50° Automatic program for nor-

mally and lightly soiled dishes. The everyday

cycle that ensures optimal cleaning and dry-

ing performance in a shorter time.

1:00-1:50 8.0-16.0 0.70-1.10

Rapid 45° - Program is recommended for limited amount of lightly-soiled

dishes with no dried food residues. Does not include the drying phase.

0:30-0:40 10.5-15.0 0.55-0.65

Crystals - 45° Program for delicate items, which are more sensitive to

high temperatures, for example, glasses and cups.

1:40-1:50 12.5-17.0 0.95-1.20

Silent - 55° Suitable for night-time operation of the appliance. Ensures

optimal cleaning and drying performance with the lowest noise emission.

3:50-4:10 10.5-14.5 0.80-1.15

Sanitizing 65° - Normally or heavily soiled crockery, with additional anti-

bacterial wash. Can be used to perform maintenance of the dishwasher.

1:55-2:10 12.0-19.0 1.40-1.80

Prewash - Used to refresh crockery planned to be washed later. Node-

tergent is to be used with this program.

0:12 4.5 0.10

P10

Self Clean - 65°

Program to be used to perform maintenance of the

dishwasher, to be carried out only when the dishwasher is EMPTY using

specic detergents designed for dishwasher maintenance.

1:15 12.7 1.10

FAVOURITE PROGRAM  The FAVOURITE program may be saved and

will be easily accessible. Find the program using PREVIOUS/NEXT, and

then press the FAVOURITE program button for 3 seconds.

Produkt Specifikationer

Mærke:	Whirlpool
Kategori:	Opvaskemaskine
Model:	WH8IB15B2M6L0

Har du brug for hjælp?

Hvis du har brug for hjælp til Whirlpool WH8IB15B2M6L0 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Opvaskemaskine Whirlpool Manualer

Whirlpool WDPS8024SZ Manual

5 September 2025

Whirlpool WDPS7024Z Manual

5 September 2025

Whirlpool W2F HD624 X Manual

1 September 2025

Whirlpool W7F HP33 X Manual

1 September 2025

Whirlpool WH8IPB14AM6L0 Manual

1 September 2025

Whirlpool W0I D741A S Manual

31 August 2025

Whirlpool W7F HP33 S Manual

31 August 2025

Whirlpool W3I D734 S Manual

31 August 2025

Whirlpool WH7IPC15BM60 Manual

30 August 2025

Whirlpool W7U HS41 X Manual

28 August 2025

Opvaskemaskine Manualer

Nyeste Opvaskemaskine Manualer

Barazza 1LVE6I Manual

12 September 2025

Robinhood DWM12P6FSS Manual

12 September 2025

Siemens SK25210EU Manual

12 September 2025

Fagor 4LVF-435AD Manual

12 September 2025

Siemens SN46M293SK Manual

11 September 2025

Gorenje GV693A60UVAD Manual

11 September 2025

Bosch SMS40E38EU Manual

11 September 2025

Hoonved C 60 D E Manual

10 September 2025

LG TrueSteam Manual

10 September 2025

Hoonved C 46 D E Manual

10 September 2025
