Side 1/2

Model

Number Model Size Reversible Door Height Overall

"A"

Height - Top of

Cabinet "B"

Depth - Door

Open 90° "C"

Depth - With

Handles "D"

Depth - Without

Handles "E"

Depth - Cabinet

Only "F"

Width - Cabinet

"G"

WRT108FFD

WRT138FFD

WRT148FZD

WRT318FZD

WRT318FMD

18.2 cu ft 65Yes 7/8 " (1673 mm) 653/8 " (1660 mm) 593/4 " (1518 mm) 33

1/2 " (850 mm) 313/8 " (797 mm) 287/8 " (733 mm) 293/4" (756 mm)

WRT519SZD

WRT549SZD 19.2 cu ft 65Yes 7/8 " (1673 mm) 653/8 " (1660 mm) 597/8 " (1520 mm) 34

1/2 " (876 mm) 327/8 " (835 mm) 287/8 " (733 mm) 293/4" (756 mm)

ELECTRICAL REQUIREMENTS

Electrical: A 115 V, 60 Hz, AC only, 15 A or 20 A fused, grounded electrical supply

is required. It is recommended that a separate circuit serving only your refrigerator

be provided. Use an outlet that cannot be turned off by a switch. Do not use an

extension cord.

NOTE: Before performing any type of installation, cleaning, or removing a light

bulb, turn the control (Thermostat, Refrigerator or Freezer Control depending on

the model) to OFF and then disconnect the refrigerator from the electrical source.

When you are nished, reconnect the refrigerator to the electrical source and reset

the control (Thermostat, Refrigerator or Freezer Control depending on the model)

to the desired setting. See “Using the Controls.”

Water: A cold water supply with water pressure between 30 psi and 120 psi

(207 kPa and 827 kPa) is required to operate ice maker and water dispenser. If

you have questions about your water pressure, call a licensed, qualied plumber.

IMPORTANT: The pressure of the water coming out of a reverse osmosis system

going to the water inlet valve of the refrigerator needs to be between 30 psi and

120 psi (207 kPa and 827 kPa).

Reverse Osmosis Water Supply: If a reverse osmosis water ltration system is

connected to your cold water supply, the water pressure to the reverse osmosis

system needs to be a minimum of 40 psi to 60 psi (276 kPa to 414 kPa).

Electrical Shock Hazard

Plug into a grounded 3 prong outlet.

Do not remove ground prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can result in death,

fire, or electrical shock.

WARNING

Top Mount Refrigerator

90˚

Top of

Cabinet

Including

Handle

Cabinet

Not Including

Handle

Overall

Height

W11558135A

LOCATION REQUIREMENTS

To ensure proper ventilation for your refrigerator, it is recommended to allow a 1/2" (1.27 cm) space on each side and between overhead cabinets and

refrigerator top. Allow at least 1" (2.54 cm) between back of cabinet and the wall. If your refrigerator has an ice maker, make sure you leave extra space at the

back for the water line connections.

If you are installing your refrigerator next to a xed wall, leave 2" (5.08 cm) minimum on the hinge side (depending on your model) to allow the door to swing

open.

This space on the hinge side also allows for crisper removal when the door is fully swung open.

NOTE: This refrigerator is intended for use in a location where the temperature ranges from a minimum of 13°C (55°F) to a maximum of 43°C (110°F). The

preferred room temperature range for optimum performance, which reduces electricity usage and provides superior cooling, is between 15°C (60°F) and

32°C (90°F). It is recommended that you do not install the refrigerator near a heat source, such as an oven or radiator.

WARNING

Explosion Hazard

Keep flammable materials and vapors, such as

gasoline, away from refrigerator.

Failure to do so can result in death, explosion, or fire.

Top Mount Refrigerator

Because Whirlpool Corporation policy includes a continuous commitment to improve our products, we reserve the right to change materials and specifications without notice.

Dimensions are for planning purposes only. For complete details, see Installation Instructions packed with product. Specifications subject to change without notice.

2" (50.8 mm)

1/2" (12.7 mm)

07/21

W11558135A
