W11679965B

QUICK START GUIDE WHIRLPOOL

DRYER

OPERATING INSTRUCTIONS

WARNING

Fire Hazard

No washer can completely remove oil.

Do not dry anything that has ever had any type of

oil on it (including cooking oils).

Items containing foam, rubber, or plastic must be

dried on a clothesline or by using an Air Cycle.

Failure to follow these instructions can result in

death or fire.

WARNING

Explosion Hazard

Keep flammable materials and vapors, such as

gasoline, away from dryer.

Do not dry anything that has ever had anything

flammable on it (even after washing).

Failure to follow these instructions can result in

death, explosion, or fire.

WARNING: To reduce the risk of fire, electric shock, or injury to

persons, read the IMPORTANT SAFETY INSTRUCTIONS, located

in your appliance’s Owner’s Manual, before operating this

appliance.

Step 1. Clean lint

screen

Step 2. Load clothes

Step 3. Press Power Button Step 4. Select the desired

cycle for your load*

Step 5. Adjust cycle settings and options, if desired

Step 6. Press, hold, and release Start Button

NOTE: Start button must be held for 1 second to

start cycle. Once the bottom line of lights left of

the Start button are illuminated, release the Start

button.

CONTROL PANEL AND FEATURES

*Not all features, cycles, and options are available on all models. Appearance may vary.

POWER

Press to turn On/Off or to stop/cancel a cycle.

CYCLE KNOB

Turn knob to select desired cycle.

NOTE: Your dryer comes with two types of cycles-Sensor drying

cycles and Timed drying cycles.

SENSOR DRYING CYCLES:

Use Sensor Cycles for better fabric care and energy savings. The

dryer senses air temperature and shuts off when the load reaches

the selected dryness level. Note that you cannot adjust the time

with these cycles.

TIMED DRYING CYCLES:

In these cycles, you can specify the drying time. Time options

available are 15, 30, 60 and 90 minutes. For a complete list of all

cycles, please refer to the online Product Guide document.

START/PAUSE

Press and hold the Start/Pause button for 1 second until all status

lights are illuminated, then release to start cycle. Press during a

cycle to pause.

NOTE: These clothes dryer’s Government energy certifications

were based on the Timed Dry Cycle, Maximum Drying

Temperature and Maximum Dry Time Settings. The as-shipped

defaults of Normal Dryness, Medium Temp, Wrinkle Shield off,

were used.

CYCLE MODIFIERS (Not all modifiers are available on all

cycles)

TEMP

Press to modify the cycle’s available temperature. (Extra Low,

Low, Medium, and High)

TIME (Air Only, Timed Dry, and Quick Dry Only)

Press to modify the time for the timed cycle between 15, 30, 60,

and 90 minutes.

OPTIONS

Press to add or remove options for each cycle. Press once to

activate Mute and twice to activate Wrinkle Shield.

CHECK VENT

The Check Vent will light up when lint has accumulated and

needs to be cleared from the dryer vent. Keeping this clean will

improve the drying performance. Steps to clean the vent can be

found in the online product guide.

MUTE

Use this option to turn the end of drying cycle signal on or off.

WRINKLE SHIELD

If you will be unable to remove a load immediately, activate this

option to add 150 minutes of periodic tumbling to help reduce

wrinkles from forming after the cycle completes.

WRINKLE ASSIST

If you will be unable to remove a load immediately, activate this

option to add 30 minutes of periodic tumbling to help reduce

wrinkles from forming after the cycle completes.

CHOOSING THE RIGHT CYCLE

A Product Guide with cycle guide

information for your dryer can be

found online at

www.whirlpool.com/owners. The

document will help identify which

cycle to choose for various load types

as well as the default cycle options.

For example we recommend using

the NORMAL cycle with Medium

temperature for cottons, linens and

mixed-garment loads.

SPECIALITY CYCLE

WRINKLE CONTROL

This cycle is designed to help remove or reduce wrinkles, this

cycle is great for permanent press clothing. The dryer cycle

uses low heat and a cool down period to keep clothes from

wrinkling or creasing.

For detailed installation instruction and maintenance information, winter storage, and transportation tips, please see the “Owner’s Manual”

included with your machine.

ASSISTANCE OR SERVICE AND ADDITIONAL INFORMATION

For information on any of the following items, a full product guide, warranty, detailed product dimensions, or for complete instructions for use

and installation, please visit www.whirlpool.com/owners or in Canada www.whirlpool.ca/owners. This may save you the cost of a service

call.

Product

Schedule

Service

How To’s & FAQ

Manuals &

Downloads

Add Service

Plan

Parts Accessories

Model &

Serial

Number

Tag Location

To speak with a customer service representative or if you have additional questions, call us toll free at

1–866–698–2538 or in Canada call 1–800–807–6777.

You can write with any questions or concerns at:

Whirlpool Brand Appliances

Customer eXperience Center

553 Benson Road

Benton Harbor, MI 49022–2692

Whirlpool Brand Appliances

Customer eXperience Centre

200–6750 Century Ave.

Mississauga, Ontario L5N 0B7

Please include a daytime phone number in your correspondence.
