FEATURES
• Dual-stacked sealed surface burners
with flame recognition and automatic
reignition for safety and ease of use.
• Heavy-duty stainless steel exterior with
island trim.
• Individual spark ignition system—only
the burner in use will spark.
• Porcelain-coated, cast iron continuous
burner grates.
• Signature red, black or stainless steel
control knobs (specify with range).
• Top configurations include infrared
charbroiler, infrared griddle and French
top with stainless steel covers.
• Dual convection ovens with two fans for
even heat distribution.
• Ten cooking modes—bake, roast, broil,
convection, convection bake, convec-
tion roast, convection broil and proof—
bake stone and dehydration modes
require accessory.
• Cobalt blue porcelain oven interiors.
• Temperature probe and broiler pan.
• Wolf exclusive pivoting hidden touch
control panel and coaxial oven knobs.
• Three adjustable oven racks per oven;
one full-extension easy glide, one full-
extension door glide and one standard.
• Self-clean, delayed start, timed cook
and Sabbath features.
• Wolf exclusive spring and damper door
hinge system.
MODEL OPTIONS
SIX BURNERS
Charbroiler / Griddle DF606CG
Double Griddle DF606DG
French Top DF606F
FOUR BURNERS
Charbroiler / French Top DF604CF
Griddle / French Top DF604CF
LP gas models, add (-LP).
60" Dual Fuel Range
wolfappliance.com
ACCESSORIES
• 5" and 10" stainless steel risers, and
20" riser with shelf.
• Signature red, black or stainless steel
control knobs.
• Stainless steel, brass or chrome bezels.
• Cast iron S-grates and wok grate.
• Single or double hardwood cutting
board (griddle models).
• Full-extension easy glide oven rack.
• 30" baking sheet.
• Temperature probe and broiler pan.
• Bake stone kit (stone, rack and peel).
• Dehydration kit (racks and door stop).
• Griddle cleaning kit (griddle models).
• Front leg and rear caster covers.
• Stainless steel kickplate.
• High altitude conversion kit—LP above
8,600' and NG above 10,250'.
Accessories avail able through an authorized
Wolf dealer. For local dealer information, visit
the find a showroom section of our website,
wolfappliance.com.
Model DF604CF
DF606CG
DF606DG
DF604CF
DF604GF
DF606F
60" Dual Fuel Range
wolfappliance.com
©Wolf Appliance, Inc. all rights reserved. 11/2014
DIMENSIONS
SPECIFICATIONS
PRODUCT
Dimensions 60
1
/8"W x 36
7
/8"H x 29
1
/2"D
Door Clearance 19
1
/2"
Weight 875–950 lb
OVENS
Interior 25"W x 16
1
/2"H x 19"D
AHAM Overall Capacity 4.5 cu ft each
AHAM Usable Capacity 2.8 cu ft each
ELECTRICAL
Supply 240/208 VAC, 60 Hz
Service 50 amp circuit
GAS
Supply
3
/4" rigid pipe
Inlet
1
/2" NPT female
BURNER RATING (Btu)
SURFACE SIMMER HIGH
Large (5 or 3) 950 15,000
Small 325 9,200
FEATURE NATURAL LP
Charbroiler 16,000 16,000
Griddle 15,000 13,000
Double Griddle 30,000 26,000
French Top 15,000 15,000
Specifications are subject to change without
notice. Visit wolfappliance.com/specs for the
most up-to-date information.
Dimensions may vary ±
1
/8" (3). Dimensions in
parentheses are millimeters unless otherwise
specified.
INSTALLATION
FRONT VIEWSIDE VIEW
*Without ventilation hood, 36" (914) minimum clearance countertop to combustible materials, 44" (118) for charbroiler.
NOTE: Shaded area above countertop indicates minimum clearance to combustible surfaces,
combustible materials cannot be located within this area.
For island installation, 12"
(305) minimum clearance back of range to combustible rear wall above countertop.
13"
(330)
18"
(457)
6"
(152)
2
1
/4"
(57)
LOCATION OF GAS AND
ELECTRICAL EXTENDS
ON FLOOR
A
3
1
/4" (83)
10" (254)
GAS
13" (330)
ELECTRICAL
36
7
/8" (937)
TO COOKING
SURFACE
W
OPENING WIDTH
30" (762) TO 36" (914)
TO BOTTOM OF
VENTILATION HOOD*
G E
60
1
/8" (1527)
9
1
/4"
(235)
36
7
/8"
(937)*
45
7
/8" (1165)
55
7
/8" (1419)
40
7
/8" (1038)
47" (1194)
26
1
/8" (664)
25" (635)
24
1
/8" (613)
27
1
/2" (699)
29
1
/2" (749)
*36
7
/8" (937) MIN TO 39" (991) MAX.
35
7
/8"
(911)
36
7
/8"
(937)*
60
1
/4" (1530)
31"
(787)
A riser is required for installations against a combustible surface.
