Side 1/48
®
www.tek.com/Color_Printers/
P H A S E R® 7 8 0 C O L O R
L A S E R P R I N T E R
U s e r G u i d e
1
Tektronix Supplies, Media, and Accessories and Options
To order supplies and accessories, contact your local reseller or
visit the Tektronix web site:
www.tek.com/Color_Printers/supplies
Supplies
Description Order number
Toner Cartridges
Black 016-1678-00
Cyan 016-1679-00
Magenta 016-1680-00
Yellow 016-1681-00
Fuser Roll Cartridge
016-1866-01
Color Imaging Unit
016-1864-00
Imaging Unit Waste
Cartridge
016-1865-00
Media
Description Order number
Laser Paper
90 g/m
2
(24 lb.) bond
500 sheets
A/Letter 016-1368-00
A4 016-1369-00
B/Tabloid (11 x 17 in.) 016-1699-00
Tabloid Plus (13 x 19 in.) 016-1709-00
A3 016-1700-00
Transparencies
50 sheets
A/Letter 016-1701-00
A4 016-1702-00
Tabloid Extra (12 x 18 in.) 016-1706-00
Image Transfer Media
100 sheets
B/Tabloid (11 x 17 in.) 016-1703-00
Glossy Coated Paper
100 sheets (A/A4)
50 sheets (B/A3/Tabloid
Plus)
A/Letter 016-1704-00
A4 016-1705-00
B/Tabloid (11 x 17 in.) 016-1718-00
Tabloid Plus (13 x 19 in.) 016-1697-00
A3 016-1719-00
Ordering Information
9
Supported Page Sizes and Print Area
Select
Page Size
from the printer’s front panel or your application’s
Print
menu.
Media/Page Size Dimension Trays
Paper
■
Letter (A) 8.5 x 11 in. Universal tray
■
Legal 8.5 x 14 in. Universal tray
■Tabloid (B) 11 x 17 in. Universal tray
■Tabloid Extra
(Graphics or Plus
feature set)
12 x 18 in. Universal tray
■Tabloid Plus
(Graphics or Plus
feature set)
13 x 19 in.
330 x 483 mm
Multi-purpose tray
■SRA3 320 x 450 mm Multi-purpose tray
■A3 297 x 420 mm Universal tray
■A4 210 x 297 mm Universal tray
■A5 148 x 210 mm Multi-purpose tray
■B4 257 x 364 mm Universal tray
■B5 182 x 257 mm Universal tray
Labels See page 18 for
supported labels.
Multi-purpose tray
Media/Page Size Dimension Trays
Transparencies
■Letter (A) 8.5 x 11 in. Transparency tray or
multi-purpose tray
■A4 210 x 297 mm Transparency tray or
multi-purpose tray
■Tabloid Extra 12 x 18 in. Multi-purpose tray
Envelopes
■US #10 4.13 x 9.5 in. Multi-purpose tray
■DL 110 x 220 mm
4.3 x 8.6 in.
Multi-purpose tray
■Choukei 3 GOU 120 x 235 mm
4.7 x 9.2 in.
Multi-purpose tray
■Kakugata 2 GOU 240 x 332 mm
9.4 x 13.1 in.
Multi-purpose tray
■Hagaki (postcard) 100 x 148 mm
3.9 x 5.8 in.
Multi-purpose tray
■C4 229 x 324 mm
9.0 x 12.8 in.
Multi-purpose tray
■C5 162 x 229 mm
6.4 x 9.0 in.
Multi-purpose tray
■C6 114 x 162 mm
4.5 x 6.4 in.
Multi-purpose tray
11
Loading Media Trays
1Pull out the paper tray.
2Squeeze and slide back the blue paper guides.
3Press down to snap the metal plate into place.
4Insert the paper; set it under the metal hook at the front right
of the tray.
5Set both back and side paper guides flush against the paper.
6Push in the paper tray.
Envelopes, labels, card stock, and other specialty media must be
loaded in the external multi-purpose tray at the right side of the
printer. See “Specialty Media” on page 14.
3040-38
Letter/A4-size paper:
Always load with the short
edge toward the rear of the
tray.
1 2
3 4
6
1 2
3 4
5 6
3040-08
19
Tektronix Image Transfer Media
1Make sure that your document size is set up as Tabloid
(11 x 17 in.).
2Load the image transfer sheet into the multi-purpose tray with
the short edge inserted into the printer. Load with the blank
side up. Insert only one sheet at a time.
3Adjust the paper guide.
4At the printer’s front panel:
aWait until the Multi-Purpose Tray Media
Size message is displayed. Press until
Tabloid is displayed. Press Select to
continue.
bWhen the Multi-Purpose Tray
Media Type prompt appears, press until
Fabric Transfer is displayed. Press
Select.
5From your application’s menu, select Print Multi-Purpose
Tray. Click .Print
6To transfer the image, follow the instructions provided with the
Tektronix media.
Capacity: 1 sheet
Feed image transfer media one sheet at a time to
prevent jamming.
3040-49
