CLP-970
CLP-970C
Owner’s manual
IMPORTANT
Check your power supply
Make sure that your local AC mains voltage
matches the voltage specified on the name
plate on the bottom panel. In some areas a
voltage selector may be provided on the bottom
panel of the main keyboard unit near the power
cord. Make sure that the voltage selector is set
for the voltage in your area. The voltage
selector is set at 240V when the unit is initially
shipped. To change the setting use a “minus”
screwdriver to rotate the selector dial so that
the correct voltage appears next to the pointer
on the panel.
CLP-970M
SPECIAL MESSAGE SECTION
PRODUCT SAFETY MARKINGS: Yamaha electronic
products may have either labels similar to the graphics
shown below or molded/stamped facsimiles of these
graphics on the enclosure. The explanation of these
graphics appears on this page. Please observe all cautions
indicated on this page and those indicated in the safety
instruction section.
See bottom of Keyboard enclosure for graphic symbol markings
The exclamation point within the
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servic-
ing) instructions in the literature
accompanying the product.
The lightning flash with arrowhead
symbol, within the equilateral trian-
gle, is intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product’s enclo-
sure that may be of sufficient magni-
tude to constitute a risk of electrical
shock.
IMPORTANT NOTICE: All Yamaha electronic products
are tested and approved by an independent safety testing
laboratory in order that you may be sure that when it is
properly installed and used in its normal and customary
manner, all foreseeable risks have been eliminated. DO
NOT modify this unit or commission others to do so
unless specifically authorized by Yamaha. Product perfor-
mance and/or safety standards may be diminished.
Claims filed under the expressed warranty may be denied
if the unit is/has been modified. Implied warranties may
also be affected.
SPECIFICATIONS SUBJECT TO CHANGE: The
information contained in this manual is believed to be
correct at the time of printing. However, Yamaha reserves
the right to change or modify any of the specifications
without notice or obligation to update existing units.
ENVIRONMENTAL ISSUES: Yamaha strives to pro-
duce products that are both user safe and environmentally
friendly. We sincerely believe that our products and the
production methods used to produce them, meet these
goals. In keeping with both the letter and the spirit of the
law, we want you to be aware of the following:
Battery Notice: This product MAY contain a small non-
rechargable battery which (if applicable) is soldered in
place. The average life span of this type of battery is
approximately five years. When replacement becomes
necessary, contact a qualified service representative to
perform the replacement.
Warning: Do not attempt to recharge, disassemble, or
incinerate this type of battery. Keep all batteries away
from children. Dispose of used batteries promptly and as
regulated by applicable laws. Note: In some areas, the
servicer is required by law to return the defective parts.
However, you do have the option of having the servicer
dispose of these parts for you.
Disposal Notice: Should this product become damaged
beyond repair, or for some reason its useful life is consid-
ered to be at an end, please observe all local, state, and
federal regulations that relate to the disposal of products
that contain lead, batteries, plastics, etc.
NOTICE: Service charges incurred due to lack of knowl-
edge relating to how a function or effect works (when the
unit is operating as designed) are not covered by the man-
ufacturer’s warranty, and are therefore the owners respon-
sibility. Please study this manual carefully and consult
your dealer before requesting service.
NAME PLATE LOCATION: The graphic below indi-
cates the location of the name plate. The model number,
serial number, power requirements, etc., are located on
this plate. You should record the model number, serial
number, and the date of purchase in the spaces provided
below and retain this manual as a permanent record of
your purchase.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CLP-970/970M/970C
Model
Serial No.
Purchase Date
92-469 1
CLP-970
3
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
* Please keep these precautions in a safe place for future reference.
WARNING
Always follow the basic precautions listed below to avoid the possibility of serious injury or even
death from electrical shock, short-circuiting, damages, fire or other hazards. These precautions
include, but are not limited to, the following:
• Do not open the instrument or attempt to disassemble the internal parts or modify them in any way. The
instrument contains no user-serviceable parts. If it should appear to be malfunctioning, discontinue use
immediately and have it inspected by qualified Yamaha service personnel.
• Do not expose the instrument to rain, use it near water or in damp or wet conditions, or place containers on
it containing liquids which might spill into any openings.
• If the power cord or plug becomes frayed or damaged, or if there is a sudden loss of sound during use of
the instrument, or if any unusual smells or smoke should appear to be caused by it, immediately turn o the
power switch, disconnect the electric plug from the outlet, and have the instrument inspected by qualified
Yamaha service personnel.
• Only use the voltage specified as correct for the instrument. The required voltage is printed on the name
plate of the instrument.
• Before cleaning the instrument, always remove the electric plug from the outlet. Never insert or remove an
electric plug with wet hands.
• Check the electric plug periodically and remove any dirt or dust which may have accumulated on it.
(1) B-6
4
CLP-970
PRECAUTIONS
CAUTION
Always follow the basic precautions listed below to avoid the possibility of physical injury to you or
others, or damage to the instrument or other property. These precautions include, but are not limited
to, the following:
• Do not place the power cord near heat sources such as heaters or radiators, and do not excessively bend
or otherwise damage the cord, place heavy objects on it, or place it in a position where anyone could walk
on, trip over, or roll anything over it.
• When removing the electric plug from the instrument or an outlet, always hold the plug itself and not the
cord. Pulling by the cord can damage it.
• Do not connect the instrument to an electrical outlet using a multiple-connector. Doing so can result in lower
sound quality, or possibly cause overheating in the outlet.
• Remove the electric plug from the outlet when the instrument is not to be used for extended periods of time,
or during electrical storms.
• Before connecting the instrument to other electronic components, turn o the power for all components.
Before turning the power on or o for all components, set all volume levels to minimum. Also, be sure to set
the volumes of all components at their minimum levels and gradually raise the volume controls while playing
the instrument to set the desired listening level.
• Do not expose the instrument to excessive dust or vibrations, or extreme cold or heat (such as in direct sun-
light, near a heater, or in a car during the day) to prevent the possibility of panel disfiguration or damage to
the internal components.
• Do not use the instrument near other electrical products such as televisions, radios, or speakers, since this
might cause interference which can aect proper operation of the other products.
• Do not place the instrument in an unstable position where it might accidentally fall over.
• Before moving the instrument, remove all connected cables.
• When cleaning the instrument, use a soft, dry or slightly damp cloth. Do not use paint thinners, solvents,
cleaning fluids, or chemical-impregnated wiping cloths. Also, do not place vinyl, plastic or rubber objects on
the instrument, since this might discolor the panel or keyboard.
• Do not rest your weight on, or place heavy objects on the instrument, and do not use excessive force on the
buttons, switches or connectors.
• Take care that the key cover does not pinch your fingers, and do not insert a finger or hand in the key cover
gap.
• Never insert or drop paper or metallic or other objects between the slits of the key cover and the keyboard.
If this happens, immediately turn o the power and remove the electric plug from the outlet and have the
instrument inspected by qualified Yamaha service personnel.
• Do not place the instrument against a wall (allow at least 3 cm/one-inch from the wall), since this can cause
inadequate air circulation, and possibly result in the instrument overheating.
• Read carefully the attached documentation explaining the assembly process. Failure to assemble the
instrument in the proper sequence might result in damage to the instrument or even injury.
• Do not operate the instrument for a long period of time at a high or uncomfortable volume level, since this
can cause permanent hearing loss. If you experience any hearing loss or ringing in the ears, consult a phy-
sician.
(1) B-6
CLP-970 5
PRECAUTIONS
■ USING THE BENCH (If included)
• Do not play carelessly with or stand on the bench. Using it as a tool or step-ladder or for any other purpose
might result in accident or injury.
• Only one person should sit on the bench at a time, in order to prevent the possibility of accident or injury.
• If the bench screws become loose due to extensive long-term use, tighten them periodically using the
included tool.
■ SAVING USER DATA
• Always save data to a floppy disk or an external device such as the Yamaha MIDI Data Filer MDF3 fre-
quently, in order to help prevent the loss of important data due to a malfunction or user operating error.
Yamaha cannot be held responsible for damage caused by improper use or modifications to the instrument,
or data that is lost or destroyed.
Always turn the power o when the instrument is not in use.
(1) B-6
CLP-970
7
Table of contents
Introduction.......................................................... 2
PRECAUTIONS ........................................................................................................................................ 3
About this Owner’s Manual and Reference Booklet..................................................................................................... 6
Table of contents ................................................................................................................................... 7
Application Index
Use this index to find reference pages that may be helpful for your application and situation. ................................. 11
Handling the Floppy Disk Drive(FDD) and Floppy Disk ...................................................................... 13
Maintenance ........................................................................................................................................ 14
Included Accessories ............................................................................................................................ 15
Features ................................................................................................................................................ 16
Before Using the Clavinova.................................................................................................................. 18
Key cover ....................................................................................................................................................................... 18
Music stand ................................................................................................................................................................... 18
Turning the power on................................................................................................................................................... 19
Adjusting the display contrast ...................................................................................................................................... 20
Setting the volume ........................................................................................................................................................ 20
Using headphones......................................................................................................................................................... 20
Basic Operation .................................................. 21
Part Names ........................................................................................................................................... 22
Listening to the Demonstration Tunes................................................................................................ 24
Listening to 50 Piano Preset Songs ..................................................................................................... 26
Playing the 50 piano preset songs ................................................................................................................................ 26
Practicing a one-hand part using 50 preset songs .......................................................................................................28
Selecting and Playing Voices ............................................................................................................... 30
Selecting Voices............................................................................................................................................................. 30
Using the pedals ............................................................................................................................................................ 31
Adding variation to the sound [BRILLIANCE]/[REVERB]/[CHORUS].................................................................. 32
Transposition ... [TRANSPOSE].................................................................................................................................. 34
Combining two voices (Dual mode)............................................................................................................................ 35
Splitting the keyboard range and playing two different voices (Split mode) ............................................................ 37
Using the metronome................................................................................................................................................... 40
Recording Your Performance............................................................................................................... 41
Recording a New Song.................................................................................................................................................. 41
Recording to [TRACK 1]........................................................................................................................................ 41
Re-recording TRACK 1........................................................................................................................................... 43
Re-recording TRACK 1 partially............................................................................................................................ 44
Recording to [TRACK2]......................................................................................................................................... 45
Recording to the third or more tracks [EXTRA TRACKS] .................................................................................. 46
Other recording techniques.......................................................................................................................................... 46
Adding data to or recording over an existing song ............................................................................................... 46
8
CLP-970
Table of contents
Changing a voice or tempo after recording ........................................................................................................... 47
Adjusting the volume balance between playback and your performance [SONG BALANCE] ......................... 48
Recording in Dual or Split mode ........................................................................................................................... 49
Saving Recorded Songs and Handling the Files...[FILE]...................................................................... 50
Clavinova memory.................................................................................................................................................. 50
Basic file operation.................................................................................................................................................. 51
Saving recorded or other songs to Clavinova Storage memory...[SaveToMemory] ................................................. 52
Saving recorded or other songs to floppy disk...[SaveToDisk] .................................................................................. 53
Deleting songs in Clavinova Storage memory or a floppy disk...[DeleteSong]......................................................... 53
Renaming a song...[RenameSong]............................................................................................................................... 54
Copying data from one floppy disk to another...[CopyDisk] .................................................................................... 55
Formatting a floppy disk...[FormatDisk] .................................................................................................................... 56
Changing the type of characters on screen...[CharacterCode]................................................................................... 56
Playing Back Recorded Songs and Commercially-available Music Data............................................. 57
Playing back a song ....................................................................................................................................................... 57
Turning track playback on and off............................................................................................................................... 59
Supported song data type ............................................................................................................................................. 59
Connections ......................................................................................................................................... 61
Connectors .................................................................................................................................................................... 61
Connecting a personal computer................................................................................................................................. 63
Detailed Settings ................................................ 69
Detailed Settings.................................................................................................................................. 70
Parameter List ............................................................................................................................................................... 70
Making detailed settings ............................................................................................................................................... 72
Detailed settings for recording and playback [SONG SETTING] ........................................................ 74
Correcting note timing [Quantize].............................................................................................................................. 74
Specifying whether playback starts immediately along with the first voicing [QuickPlay] ...................................... 75
Auditioning the channels [ChannelListen] ................................................................................................................. 75
Deleting data from each channel [ChannelClear]....................................................................................................... 75
Specifying the range and playing back repeatedly [FromToRepeat] ......................................................................... 75
Playing back the phrase specified by the phrase number [PhraseMark] ................................................................... 76
Playing back a song repeatedly [SongRepeat] ............................................................................................................. 76
Detailed settings for the metronome METRONOME [SETTING] ........................................................ 77
Setting the metronome time signature [TimeSignature]............................................................................................ 77
Setting the metronome volume level [MetronomeVolume]...................................................................................... 77
Selecting the metronome voice [MetronomeSound] ................................................................................................. 77
Detailed settings for the voices [VOICE SETTING].............................................................................. 78
Setting the octave [Octave]*......................................................................................................................................... 78
Setting the volume level [Volume]*............................................................................................................................. 78
Setting the position of right and left channels [Pan]* ................................................................................................ 79
Fine tuning the pitch (only in Dual mode) [Detune] ................................................................................................. 79
Selecting the reverb type [ReverbType]....................................................................................................................... 79
Setting the reverb depth [ReverbSend]*...................................................................................................................... 79
CLP-970
9
Table of contents
Selecting the chorus type [Chorus Type]..................................................................................................................... 80
Setting the chorus depth [ChorusSend]*..................................................................................................................... 80
Setting the chorus on/off [ChorusOnOff]................................................................................................................... 80
Selecting the variation effect type [VariationType] .................................................................................................... 80
Setting the variation effect depth [VariationSend]* ................................................................................................... 81
Setting the touch sensitivity [TouchSense]*................................................................................................................ 81
Setting the right pedal function [RPedal].................................................................................................................... 81
Setting the center pedal function [MPedal] ................................................................................................................ 82
Setting the left pedal function [LPedal] ....................................................................................................................... 82
Setting the auxiliary pedal function [AuxPedal] ......................................................................................................... 82
MIDI [MIDI SETTING]........................................................................................................................... 83
About MIDI...................................................................................................................................................................83
Setting the MIDI transmit channel [MidiOutChannel] ............................................................................................. 84
Setting the MIDI receive channel (Port A) [MidiInAChannel] ................................................................................. 84
Setting the MIDI receive channel (Port B) [MidiInAChannel] ................................................................................. 85
Setting Local control on/off [LocalControl]................................................................................................................ 85
Selecting performance from the keyboard or song data for MIDI transmission [MidiOutSelect].......................... 85
Selecting a type of data received via MIDI [ReceiveParameter]................................................................................. 85
Selecting a type of data transmitted via MIDI [TransmitParameter] ........................................................................ 86
Executing song data bulk dump [SongBulkDump].................................................................................................... 86
Transmitting the initial settings on the panel [InitialSetup] ...................................................................................... 86
Executing voice data bulk dump [VoiceBulkDump].................................................................................................. 86
Other settings ...................................................................................................................................... 87
Selecting a touch response [TouchResponse] ............................................................................................................. 87
Fine tuning the pitch [Tune]........................................................................................................................................ 87
Selecting a tuning curve for a piano voice [PianoTuningCurve] ............................................................................... 87
Selecting a scale [Scale]................................................................................................................................................. 88
Depth of string resonance [StringResonanceDepth] .................................................................................................. 88
Depth of sustain sampling for the damper pedal [SustainSamplingDepth].............................................................. 88
Setting the speed of vibraphone’s vibrato effect [VibraphoneRotorSpeed] .............................................................. 89
Selecting a pedal function for vibraphone [VibraphonePedalMode] ........................................................................ 89
Assigning the START/PAUSE function to a pedal [PedalStart/Pause]...................................................................... 89
Selecting a type of auxiliary pedal [AuxPedalType].................................................................................................... 89
Setting the point at which the damper pedal starts to affect the sound [HalfPedalPoint] ....................................... 90
Pitch bend range [PitchBendRange]............................................................................................................................ 90
Replacing the XG voices with preset voices [XGAlternative]..................................................................................... 90
Selecting items saved at shutdown [MemoryBackUp] ............................................................................................... 91
Restoring the normal (default) settings [FactorySet] ................................................................................................. 91
Other method for restoring the normal settings ......................................................................................................... 91
Message List ......................................................................................................................................... 92
Questions about Operations and Functions........................................................................................ 97
10
CLP-970
Table of contents
Appendix ............................................................ 99
Troubleshooting................................................................................................................................. 100
Data Compatibility............................................................................................................................. 101
Preset Voice List ................................................................................................................................. 103
Voice Combination Examples (Dual and Split) ................................................................................. 105
CLP-970/970M/970C: Keyboard Stand Assembly............................................................................. 106
Index................................................................................................................................................... 109
CLP-970
11
Application Index
Use this index to find reference pages that may be helpful for your application
and situation.
Listening
Listening to demo songs...............................................“Listening to the Demonstration Tunes” on page 24
“Playing the 50 piano preset songs” on page 26
Listening to demo songs with different voices ............“Listening to the Demonstration Tunes” on page 24
Listening to songs from “50 greats for the Clavinova” .......“Playing the 50 piano preset songs” on page 26
Listening to my recorded performance ............................................ “Recording to [TRACK 1]” on page 41
“Playing back a song” on page 57
Listening to songs in a floppy disk............................................................. “Playing back a song” on page 57
Playing
Using three pedals.............................................................................................“Using the pedals” on page 31
Playing an accompaniment that matches pitch ................... “Transposition ... [TRANSPOSE]” on page 34
Changing tonal color
Viewing the list of voices................................................................................ “Preset Voice List” on page 103
Simulating a concert hall........................................................................................... “[REVERB]” on page 33
Combining two voices..................................................... “Combining two voices (Dual mode)” on page 35
Playing different sounds with left and right hands
........................... “Splitting the keyboard range and playing two different voices (Split mode)” on page 37
Making a voice brighter and sharper, or softer and smoother ........................“[BRILLIANCE]” on page 32
Adding spread to the sound .................................................................................... “[CHORUS]” on page 33
Practicing
Muting the right- or left-hand part ........... “Practicing a one-hand part using 50 preset songs” on page 28
Practicing with an accurate and steady tempo.......................................“Using the metronome” on page 40
Practicing using your recorded song .......................................... “Recording Your Performance” on page 41
“Turning track playback on and off” on page 59
Recording
Recording your performance ...................................................... “Recording Your Performance” on page 41
Saving recorded songs to floppy disks or memory
...........................................................“Saving Recorded Songs and Handling the Files...[FILE]” on page 50
12
CLP-970
Application Index
Use this index to find reference pages that may be helpful for your application and situation.
Settings
Making detailed settings for recording and playback
............................................“Detailed settings for recording and playback [SONG SETTING]” on page 74
Making detailed settings for the metronome
......................................... “Detailed settings for the metronome METRONOME [SETTING]” on page 77
Making detailed settings for the voices
................................................................. “Detailed settings for the voices [VOICE SETTING]” on page 78
Making detailed settings for MIDI .................................................... “MIDI [MIDI SETTING]” on page 83
Making detailed settings for the Clavinova .........................................................“Other settings” on page 87
Connecting the Clavinova to other devices
What is MIDI?..................................................................................... “MIDI [MIDI SETTING]” on page 83
Recording your performance ..................................................... “AUX OUT [R], [L/L+R] jacks” on page 61
Raising the volume ..................................................................... “AUX OUT [R], [L/L+R] jacks” on page 61
Outputting other instruments’ sound from the Clavinova .......... “AUX IN [R], [L/L+R] jacks” on page 62
Connecting a computer........................................................ “Connecting a personal computer” on page 63
Assembling
Assembling and disassembling the Clavinova
................................................................... “CLP-970/970M/970C: Keyboard Stand Assembly” on page 106
Quick solution
What the Clavinova offers............................................................................. “Application Index” on page 11
“Features” on page 16
Returning to the main screen..............................................................................“[EXIT] button” on page 23
Resetting the Clavinova to the default setting
................................................................“Restoring the normal (default) settings [FactorySet]” on page 91
Meaning of the messages........................................................................................ “Message List” on page 92
If you have questions about operations and functions
.............................................................................. “Questions about Operations and Functions” on page 97
Troubleshooting............................................................................................. “Troubleshooting” on page 100
CLP-970
13
Handling the Floppy Disk
Drive(FDD) and Floppy Disk
Precautions
Be sure to handle floppy disks and treat the disk drive with
care. Follow the important precautions below.
Compatible Disk Type
3.5" 2DD and 2HD type floppy disks can be used.
Inserting/Ejecting Floppy Disks
To insert a floppy disk into the disk drive:
Hold the disk so that the label of the disk is facing upward and
the sliding shutter is facing forward, towards the disk slot.
Carefully insert the disk into the slot, slowly pushing it all the
way in until it clicks into place and the eject button pops out.
To eject a floppy disk:
Before ejecting the disk, be sure to confirm that the floppy
disk drive is stopped. If the disk drive is operating (during
the [SaveToDisk] (P53), [DeleteSong] (P53), [RenameSong]
(P54), [CopyDisk] (P55), or [FormatDisk] (P56) opera-
tion), the Clavinova displays [Executing].
Never attempt to remove the disk or turn the power off
when the disk drive is operating. Doing so can damage the
disk and possibly the disk drive.
Press the eject button slowly as far as it will go; the disk will
automatically pop out. When the disk is fully ejected, care-
fully remove it by hand.
If the eject button is pressed too quickly, or if it is not
pressed in as far as it will go, the disk may not eject properly.
The eject button may become stuck in a half-pressed posi-
tion with the disk extending from the drive slot by only a few
millimeters. If this happens, do not attempt to pull out the
partially ejected disk, since using force in this situation can
damage the disk drive mechanism or the floppy disk. To
remove a partially ejected disk, try pressing the eject button
once again, or push the disk back into the slot and then
repeat the eject procedure.
Be sure to remove the floppy disk from the disk drive before
turning off the power. A floppy disk left in the drive for
extended periods can easily pick up dust and dirt that can
cause data read and write errors.
Cleaning the Disk Drive Read/Write Head
• Clean the read/write head regularly. This instrument
employs a precision magnetic read/write head which,
after an extended period of use, will pick up a layer of
magnetic particles from the disks used that will eventually
cause read and write errors.
• To maintain the disk drive in optimum working order
Yamaha recommends that you use a commercially-avail-
able dry-type head cleaning disk to clean the head about
once a month. Ask your Yamaha dealer about the avail-
ability of proper head-cleaning disks.
• Never insert anything but floppy disks into the disk drive.
Other objects may cause damage to the disk drive or
floppy disks.
Eject button
14 CLP-970
Handling the Floppy Disk Drive(FDD) and Floppy Disk
About the Floppy Disks
• To handle floppy disks with care:
• Do not place heavy objects on a disk or bend or apply
pressure to the disk in any way. Always keep floppy disks
in their protective cases when they are not in use.
• Do not expose the disk to direct sunlight, extremely high
or low temperatures, or excessive humidity, dust or liq-
uids.
• Do not open the sliding shutter and touch the exposed
surface of the floppy disk inside.
• Do not expose the disk to magnetic fields, such as those
produced by televisions, speakers, motors, etc., since
magnetic fields can partially or completely erase data on
the disk, rendering it unreadable.
• Never use a floppy disk with a deformed shutter or housing.
• Do not attach anything other than the provided labels to
a floppy disk. Also make sure that labels are attached in
the proper location.
• To protect your data (Write-protect Tab):
• To prevent accidental erasure of important data, slide the
disk’s write-protect tab to the “protect” position (tab
open).
• Data backup
• For maximum data security Yamaha recommends that
you keep two copies of important data on separate floppy
disks. This gives you a backup if one disk is lost or dam-
aged. To make a backup disk use the Copy Disk function
on page 55.
Maintenance
Clean the instrument using a dry, soft cloth or slightly damp, soft cloth (wring well).
Do not use benzine, thinner, detergent, or chemical cloth for cleaning. Do not place vinyl, plastic, or rubber
products on the instrument.
Otherwise, the panel or keys may be discolored or degraded.
Before using the Clavinova, be sure to read “Precautions” on pages 3-5.
Tuning
Unlike an acoustic piano, the Clavinova does not need to be tuned. It always stays perfectly in tune.
Transporting
If you move to another location, you can transport the Clavinova along with other stuff. You can move the unit as it
is (assembled) or you can disassemble the unit down to the condition when you first open the package. Transport the
keyboard horizontally. Do not lean it to the wall and the like.
write-protect tab open
(protect position)
16 CLP-970
The music stand can be removed to allow
placement of a laptop-type personal computer or
other equipment on top of the instrument. (page 18)
A set of standard
stereo headphones
can be plugged in
here for private
practice. (page 20)
Connect an optional
pedal here and assign
one of the various
functions to the pedal.
(page 62)
Connect the pedal
cord here to use the
Clavinova’s pedals.
(page 63)
These jacks allow you to connect
an external tone generator to
reproduce the sound via the
Clavinova’s internal sound system
and speakers. (page 62)
Connect a MIDI device
here to use various
MIDI functions.
(page 63, 66)
(About MIDI—page 83)
Connect recording equipment
(such as a cassette tape
recorder) here to record your
performance. (page 61)
This jack and selector switch allow direct
connection to a personal computer for
sequencing and other music applications.
(page 62-67)
PHONES
MIDI
HOST SELECT
PC-1 PC-2
Mac MIDI
TO HOST
AUX PEDAL
PEDAL
OUT INTHRU
L/ L+RR
AUX IN
L/ L+RR
AUX OUT
POWER
MIDI
SETTING
OTHER
SETTING
EFFECT
BRILLIANCEVOICE
SETTING
CHORUSREVERBSTRINGS/
CHOIR
ORGAN
BASS
MALLET
ORGAN/
STRINGS
VOICE
E. PIANO/
BASS
PIANO
MAIN
LEFT
PIANO/
E. PIANO
SPLIT
POINT
HARPSI-
CHORD
HARPSI/
MALLET
TEMPO
METRONOME
UPDOWN
FILE
SONG
SETTING
SETTINGSTART/STOP
TRACK
1
SONG SELECTDEMO
TRANSPOSEMAX
MASTER VOLUME
MIN
CLP-970
SONG BALANCE
NEW SONG
TRACK
2EXTRA
TRACKS
STOP
SONG
SYNCHRO START
START/
PAUSE REC
CONTRASTB
D
YES
EXIT
NO
A
C
Features
The Yamaha Clavinova CLP-970 digital piano offers unmatched sonic realism and natural grand-piano type playabil-
ity as well as Yamaha’s original “AWM Dynamic Stereo Sampling” tone generation technology for rich, musical
voices, and a special “Graded Hammer” keyboard that provides graded key weight and response throughout the key-
board range. The CLP-970 GrandPiano1 voice features totally new samples painstakingly recorded from a full con-
cert grand piano. The CLP-970 GrandPiano1 voice features five velocity-switched samples ( ), a Dynamic Sampling
“Soundboard Reverb” (page 33) effect that accurately simulates the resonance of a piano soundboard, “String Reso-
nance” (page 88) that recreates resonance of piano strings, special “ ” (page 88)that samples the Sustain Sampling
unique resonance of an acoustic grand piano’s soundboard and strings when the damper pedal is pressed, and “Key-
off Samples” that add the subtle sound produced when the keys are released. The CLP-970 comes much closer to the
sound of a true acoustic piano.
CLP-970 17
Features
[OTHER SETTING]
Fine-tune the touch response
and pitch, etc. (page 87)
The Clavinova includes 50 preset
songs.
This section enables you to listen to
these songs, practice using a
convenient practice function, play back
Clavinova music data (sold in music
stores), and record and play back your
performance. (page 26, 41, 57)
The display allows
accurate control
and operation.
(page 23)
[MIDI SETTING]
Make detailed MIDI
settings, such as MIDI
receive/transmit
channels. (page 83)
[FILE]
Save recorded songs and
manage song files. (page 50)
MAIN voice gruop buttons
Select voices from 25 internal sounds
including Grand Piano 1. (page 30)
You can also combine two voices at a
time. (page 35)
[DEMO]
Demonstration playback
is available for each
voice. (page 24)
[METRONOME]
Use the
metronome
functions.
(page 40)
[CONTRAST]
Adjust the
brightness of
the display
using this
control.
(page 20)
[REVERB]/
[CHORUS]
Add reverb
(reverberation) and
spread (chorus) to
the sound.
(page 33)
[MASTER
VOLUME]
Adjust the
volume level
using this
slider.
(page 20)
[SONG SETTING]
Make detailed
settings for song
recording and
playback. (page 74)
[EXIT]
The screen returns to
its main display when
you press this button.
(page 23)
TRANSPOSE [ ] [ ]
You can shift the pitch
of the entire keyboard
up or down so that the
pitch will match that of
another instrument or
singer, while you play
the same keys.
(page 34)
TEMPO [DOWN]
[UP]
You can change the
song tempo
(speed).
(page 27, 40, 42, 58)
[VOICE
SETTING]
You can make
detailed settings
for tone and
effects.
(page 78)
BRILLIANCE
[ ] [ ]
Adjust the
brightness of
the tone using
these buttons.
(page 32)
LEFT voice group buttons/
[SPLIT POINT]
You can play different voices on
the left- and right-hand sections of
the keyboard. (page 37)
MIDI
SETTING
OTHER
SETTING
EFFECT
BRILLIANCE
VOICE
SETTING
CHORUSREVERBSTRINGS/
CHOIR
ORGAN
BASS
MALLET
ORGAN/
STRINGS
VOICE
E. PIANO/
BASS
PIANO
MAIN
LEFT
PIANO/
E. PIANO
SPLIT
POINT
HARPSI-
CHORD
HARPSI/
MALLET
CONTRASTB
D
YES
EXIT
NO
A
C
TEMPO
METRONOME
UPDOWN
FILE
SONG
SETTING
SETTINGSTART/STOP
TRACK
1
SONG SELECTDEMO
TRANSPOSEMAX
MASTER VOLUME
MIN
CLP-970
SONG BALANCE
NEW SONG
TRACK
2EXTRA
TRACKS
STOP
SONG
SYNCHRO START
START/
PAUSE REC
CLP-970 19
Before Using the Clavinova
Turning the power on
1. Connect the power cable.
First insert the plug of the power cable into the AC connector on the Clavinova, then plug the other end of
the cable into the proper AC outlet on the wall.
In some areas a plug adaptor may be provided to match the pin conguration of the AC wall outlets in
your area.
WARNING!
Make sure your CLP-970 is rated for the AC voltage supplied in the area in which it is to be used (voltage rating appears on the
name plate on the bottom panel). In some areas, a voltage selector may be provided on the bottom panel of the main keyboard
unit near the power cord. Make sure that the voltage selector is set for the voltage in your area. Connecting the unit to the wrong
AC supply can cause serious damage to the internal circuitry and may even pose a shock hazard!
Use only the AC power cord supplied with the CLP-970. If the supplied cord is lost or damaged and needs to be replaced, con-
tact your Yamaha dealer. The use of an inappropriate replacement can pose a re and shock hazard!
The type of AC power cord provided with the CLP-970 may be different depending on the country in which it is purchased. (In
some areas a plug adaptor may be provided to match the pin conguration of the AC wall outlets in your area.) Do NOT modify
the plug provided with the CLP-970. If the plug will not t the outlet, have a proper outlet installed by a qualied electrician.
2. Turn on the power to the Clavinova.
Press the [POWER] switch located on the right of the keyboard to turn the power on.
• The screen located in the center of the front panel and the power indica-
tor located below the left end of the keyboard lights up.
Power indicator
If you close the key cover
without turning the power
off, the power indicator
remains lit, indicating that
the power is still on.
Press the [POWER] switch again to turn off the power to the Clavinova.
• The screen and the power indicator turn off.
1 2
The power connector is located on the bottom of the key-
board, set back deeply.
(The shape of plug differs
depending on locale.)
TIP
Power indicator
[POWER] switch
A B
C D
NO YES
When you turn on the power to the Clavinova, a voice name
appears on the screen.
20 CLP-970
Before Using the Clavinova
Adjusting the display contrast
You can adjust the contrast of the display by turning the [CONTRAST] knob located to the right of the LCD.
CONTRAST:
difference between bright-
ness and darkness
Setting the volume
While playing the keyboard, adjust the volume level by moving the [MASTER VOLUME] slider on the left of
the front panel to the left or right.
MASTER VOLUME:
The volume level of the
entire keyboard sound
You can also adjust the
[PHONES] output level and
the AUX IN input level using
the [MASTER VOLUME]
slider.
Using headphones
Connect a pair of headphones to
one of the [PHONES] jacks. When
the headphones are plugged into
either of the [PHONES] jacks, the
internal speaker system is automat-
ically shut off.
Two [PHONES] jacks are provided.
Two sets of standard stereo head-
phones can be plugged in. (If you
are using only one pair of head-
phones, you can plug them into
either of these jacks.)
TERMINOLOGY
A B
C D
NO YES
CONTRAST
EXIT
Use this knob.
TERMINOLOGY
TIP
The level decreases. The level increases.
MASTER VOLUME
MIN MAX
Do not use the Clavinova at
a high volume level for a
long period of time, or your
hearing may be damaged.
PHONES
standard stereo phone plug
bottom surface
Optional headphones
HPE-160 Yamaha head-
phones.
TIP
21 CLP-970
Basic Operation
CLP-970 21
22 CLP-970
Part Names
Center “C”
POWER
MIDI
SETTING
OTHER
SETTING
EFFECT
BRILLIANCEVOICE
SETTING
CHORUSREVERBSTRINGS/
CHOIR
ORGAN
BASS
MALLET
ORGAN/
STRINGS
VOICE
E. PIANO/
BASS
PIANO
MAIN
LEFT
PIANO/
E. PIANO
SPLIT
POINT
HARPSI-
CHORD
HARPSI/
MALLET
CONTRASTB
D
YES
EXIT
NO
A
C
TEMPO
METRONOME
UPDOWN
FILE
SONG
SETTING
SETTINGSTART/STOP
TRACK
1
SONG SELECTDEMO
TRANSPOSEMAX
MASTER VOLUME
MIN
CLP-970
SONG BALANCE
NEW SONG
TRACK
2
EXTRA
TRACKS
STOP
SONG
SYNCHRO START
START/
PAUSE
REC
MIDI
SETTING
OTHER
SETTING
EFFECT
BRILLIANCEVOICE
SETTING
CHORUSREVERBSTRINGS/
CHOIR
ORGAN
BASS
MALLET
ORGAN/
STRINGS
VOICE
E. PIANO/
BASS
PIANO
MAIN
LEFT
PIANO/
E. PIANO
SPLIT
POINT
HARPSI-
CHORD
HARPSI/
MALLET
CONTRASTB
D
YES
EXIT
NO
A
C
TEMPO
METRONOME
UPDOWN
FILE
SONG
SETTING
SETTINGSTART/STOP
TRACK
1
SONG SELECTDEMO
TRANSPOSEMAX
MASTER VOLUME
MIN
CLP-970
SONG BALANCE
NEW SONG
TRACK
2EXTRA
TRACKS
STOP
SONG
SYNCHRO START
START/
PAUSE REC
PHONES
C0 D0 E0 F0 G0 A0 B0 C1 D1 E1 F1 G1 A1 B1 C2 D2 E2 F2 G2 A2 B2 C3 D3 E3 F3 G3 A3 B3 C4 D4 E4 F4 G4 A4 B4 C5 D5 E5 F5 G5 A5 B5 C6 D6 E6 F6 G6 A6 B6 C7B-1A-1
]
1
2
3 5
D
E
FHL M O
G I J K N P
7 B
8
4 6 0 A
9 C
RQ
ST
Top panel
1[POWER]..............................................P19
2[MASTER VOLUME].............................P20
3[DEMO] ...............................................P24
4TRANSPOSE [ ] [ ] ..........................P34
5SONG SELECT [ ] [ ]..........P26, 41, 57
6SONG BALANCE [ ] [ ]....................P48
7[TRACK1] [TRACK2] /
[EXTRA TRACKS] ............... P28, 41–46, 59
8[FILE] ...................................................P50
9SONG [STOP] /
[START/PAUSE] .......................P26, 42, 58
0[REC]....................................................P42
A[SONG SETTING] ................................P74
BMETRONOME [START/STOP] /
[SETTING]......................................P40, 77
CTEMPO [DOWN] [UP] .......P27, 40, 42, 58
DLCD buttons A [–] [+] / B [– (NO)] [+ (YES)] /
C [–] [+] / D [–] [+]...............................P23
ELCD screen ..........................................P23
F[CONTRAST] knob...............................P20
G[EXIT]...................................................P23
HVoice group buttons for the MAIN
section .................................................P30
I[SPLIT POINT] .....................................P38
JVoice group buttons for the LEFT
section .................................................P37
K[VOICE SETTING] ................................P78
L[REVERB]..............................................P33
M[CHORUS]............................................P33
NBRILLIANCE [ ] [ ] ...........................P32
O[MIDI SETTING]...................................P83
P[OTHER SETTING] ...............................P87
Q[PHONES] ............................................P20
RSoft pedal............................................P31
SSostenuto pedal ..................................P31
TDamper pedal .....................................P31
CLP-970 23
Part Names
Connectors
DLCD buttons
ELCD
Use the LCD button A, B, C, or D to select the contents displayed on the LCD.
Check the screen located in the center of the top panel after every operation. A
voice name appears on the screen when you turn on the power to the unit.
G[EXIT] button
When you press this button, the unit returns to the default screen (the
screen that indicates a voice name(s) and is displayed when the power is
turned on).
MIDI
HOST SELECT
PC-1 PC-2
Mac MIDI
TO HOST
AUX PEDAL
PEDAL
OUT INTHRU
L/ L+RR
AUX IN
L/ L+RR
AUX OUT
[
U V W X Y Z
UAUX OUT [R] [L/L+R]..........................P61
VAUX IN [R] [L/L+R] .............................P62
W[AUX PEDAL] ......................................P62
X[TO HOST] ..........................................P62
YHOST SELECT..................................... P62
ZMIDI [IN] [OUT] [THRU] .................... P63
[[PEDAL] .............................................. P63
\
\
Floppy disk drive................................. P13
]
Panel logos
GM System Level 1
“GM System Level 1” is an addition to the MIDI
standard which guarantees that any data conform-
ing to the standard will play accurately on any
GM-compatible tone generator or synthesizer
from any manufacturer.
XG Format
XG is a new Yamaha MIDI specication which sig-
nicantly expands and improves on the “GM Sys-
tem Level 1” standard with greater voice handling
capacity, expressive control, and effect capability
while retaining full compatibility with GM.
bottom surface
A B
C D
NO YES
24 CLP-970
Listening to the Demonstration
Tunes
The Clavinova provides demonstration tunes that effectively demonstrate each of the MAIN voice groups.
Refer to the table below for voice names and corresponding demo songs.
Demonstration tunes
Procedure
Mode:
A mode is a status under
which you can execute a
certain function. In demo
mode, you can play back
demonstration tunes.
1. Engage the demo mode.
Press the [DEMO] button to engage the demo mode.
The MAIN voice group (upper row) button indicators light up in
sequence.
To adjust the volume level of
the demo songs, use the
[MASTER VOLUME] slider.
2. Select a tune and start playback.
Press the voice group button (upper row) of the desired
demonstration tune.
The corresponding voice button indicator lights up and playback
starts. Until you stop playback, the selected tune will be played
repeatedly using different voices (in the following order: PIANO
→
E. PIANO/BASS → HARPSICHORD MALLET → → ORGAN →
STRINGS/CHOIR).
Voice group Tunes Composer
PIANO
E.PIANO/BASS
HARPSICHORD
MALLET
ORGAN
STRINGS/CHOIR
Chanson de l’adieu
Original
Le Coucou
Original
Organ Concerto Op.4 No.2
Original
F.F. Chopin
–
L.C. Daguin
–
G.F. Händel
–
DEMO SONG SELECT
TRANSPOSE
MASTER VOLUME TEMPO VOICE EFFECTSONG
CLP-970
MIN MAX
NEW SONG
SONG BALANCE UPDOWN
BRILLIANCE
TRACK
1
TRACK
2
EXTRA
TRACKS
FILE METRONOME CONTRAST
SONG
SETTING
START/ STOP SETTING
SPLIT
POINT
VOICE
SETTING
REVERB CHORUS MIDI
SETTING
OTHER
SETTING
REC
PIANO
MAIN
LEFT
E. PIANO/
BASS
HARPSI-
CHORD
MALLET ORGAN STRINGS/
CHOIR
STOP START/
PAUSE
SYNCHRO START
EXIT
PIANO/
E. PIANO
HARPSI/
MALLET
ORGAN/
STRINGS
BASS
A B
C D
NO YES
1 4
34
2 3 MAIN voice
group buttons
TERMINOLOGY
A B
C D
NO YES
NOTE
CLP-970 25
Listening to the Demonstration Tunes
3. Stop the playback.
Press the button of the voice group being played or the
[STOP] button.
4. Exit from demo mode.
Press the [DEMO] or [EXIT] button to exit from demo
mode.
26 CLP-970
Listening to 50 Piano Preset
Songs
The Clavinova provides performance data of 50 piano songs. You can just listen to these songs (page 26) or
use them for practice (page 28). You can also refer to the included “50 greats for the Clavinova” that contains
the scores for 50 piano preset songs.
Playing the 50 piano preset songs
Procedure
Song:
On the Clavinova, perfor-
mance data is called a
“Song.” This includes dem-
onstration tunes and piano
preset tunes.
1. Select a song.
Press one of the [SONG SELECT] buttons repeatedly to
select the desired piano song from P-001 to P-050.
You can play the keyboard
along with the preset song
playback. You can change the
voice playing on the keyboard.
2. Play a preset song.
Press the [START/PAUSE] button to start playback.
DEMO SONG SELECT
TRANSPOSE
MASTER VOLUME TEMPO VOICE EFFECTSONG
CLP-970
MIN MAX
NEW SONG
SONG BALANCE UPDOWN
BRILLIANCE
TRACK
1TRACK
2EXTRA
TRACKS FILE METRONOME CONTRAST
SONG
SETTING
START/ STOP SETTING
SPLIT
POINT VOICE
SETTING
REVERB CHORUS MIDI
SETTING
OTHER
SETTING
REC
PIANO
MAIN
LEFT
E. PIANO/
BASS HARPSI-
CHORD MALLET ORGAN STRINGS/
CHOIR
STOP START/
PAUSE
SYNCHRO START
EXIT
PIANO/
E. PIANO HARPSI/
MALLET ORGAN/
STRINGS BASS
A B
C D
NO YES
1
23 4
METRONOME [START/STOP]
TEMPO [DOWN] [UP]
TERMINOLOGY
A B
C D
NO YES
The song number appears on the display.
Song select screen
TIP
• You can also use the C
[–]/[+] buttons to select a
song after pressing the
[SONG SELECT] button.
• [P-000: NewSong] is a
blank song provided for
you to record your perfor-
mance. (See page 41.)
• Use the SongRepeat
parameter in the “SONG
SETTING” menu to
select repeat playback of
all songs or repeat play-
back of a single song.
(See page 76.)
TIP
A B
C D
NO YES
the number of measures
CLP-970 31
Selecting and Playing Voices
Using the pedals
The Clavinova has three foot pedals: damper pedal (right), sostenuto
pedal (center), and soft pedal (left) that produce a range of expressive
effects similar to those produced by the pedals on an acoustic piano.
If the damper pedal doesn’t
work, or notes are sustained
even when the pedal is not
pressed, make sure that the
pedal cord is properly
plugged into the PEDAL jack
on the unit (see step 5 on
page 107). Also, make sure
that the RPedal parameter
in the “VOICE SETTING”
menu is set to ON (see page
81).
Damper (right) pedal
When you press the damper pedal, the notes
you play have a longer sustain.
When you select Grand Piano 1, pressing the
damper pedal activates the instrument’s special
“Sustain Samples” to accurately recreate the
unique resonance of an acoustic grand piano’s
soundboard and strings.
You can adjust the depth of
the resonance produced by
the “Sustain Samples” using
the Sustain Sampling Depth
parameter in the “OTHER
SETTING” menu. (See page
88.)
Sostenuto (center) pedal
If you play a note or chord on the keyboard
and press the sostenuto pedal while holding
the note(s), the notes will sustain as long as
the pedal is held. All subsequent notes will
not sustain.
You can assign a function to
each pedal via the “R
Pedal”, “M Pedal”, and “L
Pedal” parameters in the
“VOICE SETTING” menu.
(See page 81, 82.)
The center and left pedals
can also be assigned to
song start/stop operation
(START/PAUSE function) via
the “PedalStart/Pause”
parameter in the “OTHER
SETTING” menu (on page
89).
Soft pedal (left)
The soft pedal reduces the volume and slightly changes the timbre of notes
played while the pedal is pressed. (The soft pedal will not affect notes that are
already playing when it is pressed. Press the pedal immediately before you
play the target notes.)
With the Vibraphone and Jazz Organ voices, this pedal turns vibrato on and
off or toggles the speed of vibrato. (See page 82.)
TIP
q
h.q
.q
.
When you press the damper
pedal here, the notes you
play before you release the
pedal have a longer sustain.
TIP
q
h.q
.q
.
When you press the sostenuto
pedal here while holding the
note(s), the notes will sustain
as long as you hold the pedal.
TIP
TIP
32 CLP-970
Selecting and Playing Voices
Adding variation to the sound
[BRILLIANCE]/[REVERB]/[CHORUS]
The Effect function enables you to add expression to the sound. The Clavinova effects include Brilliance,
Reverb, and Chorus.
[BRILLIANCE]
You can use this control to adjust the brilliance of the tone and change the tonality to suit your preference.
Procedure
You can also use the D [–]/
[+] buttons after you press
one of the [BRILLIANCE]
buttons to select the desired
option.
Normal setting = Normal
Normal setting:
The “Normal setting” refers
to the default setting (factory
setting) obtained when you
first turn on the power to the
Clavinova.
If you select [Bright] or
[Metallic] as the type of bril-
liance, the volume level will
increase slightly. Under this
condition, if you raise the
[MASTER VOLUME] slider
setting, the sound may
become distorted. In this
case, lower the volume
accordingly.
Press one of the BRILLIANCE [ ]/ [ ] buttons to select the
desired tonality.
Dark.................... Dark tone
Mellow................ Soft and mellow tone
Normal ............... Standard tone
Bright ................. Bright tone
Metallic............... Sharp metallic tone
Press the [EXIT] button to return to the main screen.
DEMO SONG SELECT
TRANSPOSE
MASTER VOLUME TEMPO VOICE EFFECTSONG
CLP-970
MIN MAX
NEW SONG
SONG BALANCE UPDOWN
BRILLIANCE
TRACK
1
TRACK
2
EXTRA
TRACKS
FILE METRONOME CONTRAST
SONG
SETTING
START/ STOP SETTING
SPLIT
POINT
VOICE
SETTING
REVERB CHORUS MIDI
SETTING
OTHER
SETTING
REC
PIANO
MAIN
LEFT
E. PIANO/
BASS
HARPSI-
CHORD
MALLET ORGAN STRINGS/
CHOIR
STOP START/
PAUSE
SYNCHRO START
EXIT
PIANO/
E. PIANO
HARPSI/
MALLET
ORGAN/
STRINGS
BASS
A B
C D
NO YES
[REVERB] [CHORUS]
BRILLIANCE [ ] [ ]
TIP
TIP
TERMINOLOGY
NOTE
A B
C D
NO YES
CLP-970 33
Selecting and Playing Voices
[REVERB]
This control adds reverberation to the sound by simulating the natural reverberation of a concert hall.
Procedure
You can select a reverb type
via the Reverb Type param-
eter in the “VOICE SET-
TING” menu, and adjust the
reverb depth for the selected
voice via the Reverb Send
parameter. (See page 79.)
Normal setting = ON
Pressing the [REVERB] button repeatedly toggles the reverb
on and off.
Even if the reverb effect is turned off, a “soundboard reverb” effect
will be applied when the GrandPiano1 or GrandPiano2 voice is
selected.
[CHORUS]
This control adds spread and spaciousness to the sound.
Procedure
You can select a chorus type
via the Chorus Type param-
eter in the “VOICE SET-
TING” menu, and adjust the
chorus depth for the
selected voice via the
Reverb Send parameter. You
can also turn chorus on or
off via the Chorus On Off
parameter. (See page 80.)
Normal Setting
The normal chorus on/off
setting is different for each
voice.
Pressing the [CHORUS] button repeatedly toggles the cho-
rus on and off.
You can turn the chorus effect on and off by pressing the [CHORUS]
ON/OFF buttons on the panel and by setting the Chorus On Off
parameter in the VOICE SETTING menu (see page 80). The [CHO-
RUS] ON/OFF button setting on the panel is temporary. That is, if
you select another voice, the chorus setting for the previous voice is
cancelled. The Chorus On Off parameter setting is saved for each
voice. That is, if you select a given voice, the chorus setting is auto-
matically turned on or off according to the saved chorus setting.
TIP
TIP
TIP
TIP
34 CLP-970
Selecting and Playing Voices
Transposition ... [TRANSPOSE]
The Clavinova’s Transpose function makes it possible to shift the pitch of the entire keyboard up or down in
semitone intervals to facilitate playing in difficult key signatures, and to let you easily match the pitch of the
keyboard to the range of a singer or other instruments. For example, if you set the transposition amount to
“5,” playing key C produces pitch F. In this way, you can play the song as if it were in C major, and the Clavi-
nova will transpose it to the key of F.
You can also change the key signature of playback songs, in addition to your own performance.
Procedure
Transpose:
Changing the key signature
of a song. On the Clavinova,
transposing shifts the pitch
of the entire keyboard.
1. Display the Transpose screen.
Press one of the TRANSPOSE [ ] and [ ] buttons.
2. Select a type of transposition from Manual or Song.
Use the C [–] and [+] buttons to select Manual or Song.
Manual ............... Your manual performance
Song .................... Playback song
The transposition range is
from “–12 semitones” (down
one octave) through “0” (nor-
mal pitch) to “12 semitones”
(up one octave).
3. Set the transposition amount.
Use the D [–] and [+] or TRANSPOSE [ ] and [ ] buttons
to set the transposition amount.
To set the amount of transposition to “0,” press the D [–] and [+] but-
tons or the TRANSPOSE [ ] and [ ] buttons simultaneously.
4. Return to the main screen.
Press the [EXIT] button.
DEMO SONG SELECT
TRANSPOSE
MASTER VOLUME TEMPO VOICE EFFECT
SONG
CLP-970
MIN MAX
NEW SONG
SONG BALANCE UPDOWN
BRILLIANCE
TRACK
1
TRACK
2
EXTRA
TRACKS
FILE METRONOME CONTRAST
SONG
SETTING
START/ STOP SETTING
SPLIT
POINT
VOICE
SETTING
REVERB CHORUS MIDI
SETTING
OTHER
SETTING
REC
PIANO
MAIN
LEFT
E. PIANO/
BASS
HARPSI-
CHORD
MALLET ORGAN STRINGS/
CHOIR
STOP START/
PAUSE
SYNCHRO START
EXIT
PIANO/
E. PIANO
HARPSI/
MALLET
ORGAN/
STRINGS
BASS
A B
C D
NO YES
21 3 3 4
TERMINOLOGY
A B
C D
NO YES
TIP
CLP-970 35
Selecting and Playing Voices
Combining two voices (Dual mode)
You can play two voices simultaneously across the entire range of the keyboard. In this way, you can simulate
a melody duet or combine two similar voices to create a thicker sound. Refer to “Voice Combination Exam-
ples (Dual and Split)” on page 105 for examples of effective voice combinations.
Dual mode using voices in different voice groups
Procedure
1. Enter Dual mode.
Press two MAIN voice group buttons (upper row) simulta-
neously.
2. Select a voice.
Use the A [–]/[+] buttons and B [–]/[+] buttons to select a
voice.
The voices listed in the upper row in “Preset Voice List” on page 103
are called 1st voices, and those listed in the bottom row are called 2nd
voices.
3. Exit Dual mode and return to normal play mode.
Press any MAIN voice group button.
DEMO SONG SELECT
TRANSPOSE
MASTER VOLUME TEMPO VOICE EFFECTSONG
CLP-970
MIN MAX
NEW SONG
SONG BALANCE UPDOWN
BRILLIANCE
TRACK
1
TRACK
2
EXTRA
TRACKS
FILE METRONOME CONTRAST
SONG
SETTING
START/ STOP SETTING
SPLIT
POINT
VOICE
SETTING
REVERB CHORUS MIDI
SETTING
OTHER
SETTING
REC
PIANO
MAIN
LEFT
E. PIANO/
BASS
HARPSI-
CHORD
MALLET ORGAN STRINGS/
CHOIR
STOP START/
PAUSE
SYNCHRO START
EXIT
PIANO/
E. PIANO
HARPSI/
MALLET
ORGAN/
STRINGS
BASS
A B
C D
NO YES
1 32
2 3 1 4
2MAIN voice
The numbers on the upper row indicate the steps
The numbers on the bottom row indicate the steps
group buttons
in Dual mode using voices from different groups.
in Dual mode using voices from the same group.
MAIN voice
group buttons
A B
C D
NO YES
1st voice 2nd voice
36 CLP-970
Selecting and Playing Voices
Dual mode using voices in the same voice group
Procedure
1. Select a voice group.
In normal play mode, press the desired MAIN voice group
button.
2. Select a voice.
Use the A [–]/[+] buttons to select a voice.
3. Select another voice.
Use the B [–]/[+] buttons to select another voice in the
same voice group.
To use the identical voices, press the B [–]/[+] buttons once. To use
different voices within the same voice group, press the B [–]/[+] but-
tons repeatedly.
4. Exit Dual mode and return to normal play mode.
Press any MAIN voice group button.
A B
C D
NO YES
CLP-970 37
Selecting and Playing Voices
Splitting the keyboard range and playing two differ-
ent voices (Split mode)
Split mode enables you to play two different voices on the keyboard — one with the left hand and another
with the right hand. For example, you can play a bass part using the Wood Bass or Electric Bass voice with the
left hand, and a melody with the right hand. Refer to “Voice Combination Examples (Dual and Split)” on
page 105 for examples of effective voice combinations.
Procedure
1. Enter Split mode.
Press one of the LEFT voice group buttons (bottom row).
2. Select a voice for the right hand.
Use the MAIN voice group buttons (upper row) and the A
[–]/[+] buttons.
3. Select a voice for the left hand.
Use the LEFT voice group buttons (bottom row) and the C
[–]/[+] buttons.
DEMO SONG SELECT
TRANSPOSE
MASTER VOLUME TEMPO VOICE EFFECTSONG
CLP-970
MIN MAX
NEW SONG
SONG BALANCE UPDOWN
BRILLIANCE
TRACK
1TRACK
2EXTRA
TRACKS FILE METRONOME CONTRAST
SONG
SETTING
START/ STOP SETTING
SPLIT
POINT VOICE
SETTING
REVERB CHORUS MIDI
SETTING
OTHER
SETTING
REC
PIANO
MAIN
LEFT
E. PIANO/
BASS HARPSI-
CHORD MALLET ORGAN STRINGS/
CHOIR
STOP START/
PAUSE
SYNCHRO START
EXIT
PIANO/
E. PIANO HARPSI/
MALLET ORGAN/
STRINGS BASS
A B
C D
NO YES
2
1 3 5
2
3 4 4
MAIN voice
LEFT voice
group buttons
group buttons
A B
C D
NO YES
Produkt Specifikationer
| Mærke: | Yamaha |
| Kategori: | Klaver |
| Model: | Clavinova CLP-970 |
Har du brug for hjælp?
Hvis du har brug for hjælp til Yamaha Clavinova CLP-970 stil et spørgsmål nedenfor, og andre brugere vil svare dig
Klaver Yamaha Manualer
4 Juni 2025
3 Juni 2025
3 Juni 2025
3 Juni 2025
3 Juni 2025
4 Marts 2025
21 Februar 2025
9 Januar 2025
31 December 2025
31 December 2025
Klaver Manualer
- Klaver Viscount
- Klaver Alesis
- Klaver Crumar
- Klaver CLXmusic
- Klaver Technics
- Klaver Dexibell
- Klaver Thomann
- Klaver Nord
- Klaver Orla
- Klaver Suzuki
- Klaver Korg
- Klaver Kurzweil
- Klaver Max
- Klaver IDance
- Klaver Casio
Nyeste Klaver Manualer
8 Februar 2025
13 Januar 2025
19 December 2024
13 December 2024
11 December 2024
11 December 2024
11 December 2024
11 December 2024
22 November 2024
22 November 2024
