Side 1/21
JAEN
FR
ES
MBC9600
MSC9600
MTC9600
MARCHING DRUM CARRIER
HARNAIS POUR PERCUSSIONS DE DÉFILÉ
ARNÉS DE PERCUSIÓN DE MARCHA
マーチングドラムキャリア
Owner's Manual
Mode d'emploi
Manual de instrucciones
取扱説明書
EnglishFrançaisEspañol
日本語
2 • MSC9600 MTC9600 MBC9600
Owner's Manual
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
Please keep this manual in a safe and handy place for future reference.
WARNING
Always follow the basic precautions listed below to avoid the possibility of serious injury or even death.
These precautions include but are not limited to the following:
Handling
•
Do not modify or disassemble this product. Otherwise,
injuries or damage may result.
DMI-11 1/2
CAUTION
Always follow the basic precautions listed below to avoid the possibility of physical injury to you or
others, or damage to the instrument or other property. These precautions include but are not limited to
the following:
Assembly
•
Check your surroundings before setting up the
instrument. Not checking your surroundings before
setting up the instrument can lead to the instrument
hitting others or other instruments close by, or you hitting
other instruments causing injury or property damage.
•
Tighten all screws securely once adjustments have
been made. If any screw is loose there is a danger that
the drum may slip during performances or extraneous
noises may be produced.
•
To adjust the carrier use the provided tools only. If the
wrong size tool is used, parts may be damaged or
insufficient tightening may cause the instrument attached
to the carrier to fall, resulting in injuries.
Handling
•
Always use the carrier with all bolts securely tightened.
If the carrier is used with loose parts, the instrument
attached to the carrier may fall, resulting in injuries or
damage. In addition, parts may fall off and get lost.
•
When tilting up the instrument always hold the
instrument with your hand as it might flip back and injure
bystanders.
•
Do not insert your hands between moving parts.
Otherwise, your hands may get caught, resulting in
injuries.
•
Pay attention to the ends and inner surfaces of pipes
and the tips of screws. Otherwise, the sharp parts may
cause injuries.
•
Do not use other screws than those that are included.
Otherwise, the carrier may lose holding strength and
parts may fall off, resulting in damage or injuries.
•
Do not use the carrier in any way other than its intended
purpose. Otherwise, injuries may result. Unintended
uses may result in unexpected injuries.
•
Keep this product out of reach of children. This product
is not suitable for use in locations where children are
likely to be present.
MSC9600 MTC9600 MBC9600
Owner's Manual
• 3
DMI-11 2/2
Yamaha cannot be held responsible for damage caused by improper use or modifications to the product.
•
Take care not to pinch your fingers when putting the
carrier away or when adjusting carrier height. Fingers
may become pinched resulting in injury.
•
Move the instrument slowly when mounting it onto the
carrier or when removing it from the carrier. Otherwise,
injuries may result, for example, if your hand gets
caught.
•
When taking off and putting down the carrier or the
carrier with the instrument mounted, do so gently. Do
not drop or throw the carrier or the carrier with the
instrument mounted.
•
Always take suitable breaks when using the carrier for a
long period of time. Using the carrier when fatigued can
cause injury.
•
If some of the parts are broken and/or lost, immediately
stop using the carrier. Using a defective carrier can
cause injury.
Location
•
Do not place the product in an unstable position or
a location with excessive vibration, where it might
accidentally fall over and cause injury.
MSC9600 MTC9600 MBC9600
Owner's Manual
• 5
Thank you for purchasing this Yamaha product.
This product is a high-end marching drum carrier that can be worn over the shoulders, allowing you to play an attached marching drum
during your performance.
Playing in unison with your instrument is made easier thanks to the carrier body, which can be precisely adjusted to fit your body, and
the attachment mechanism, which securely holds the instrument in place while allowing it to be easily mounted and removed.
In order to take full advantage of the various features of this product, we recommend that you read this Owner’s Manual thoroughly
before use. After reading this manual, keep it in a safe, accessible place, and refer to it to better understand the features.
Included Items
The following items are included in the package.
Before assembly, make sure that all items are included.
* If any item is missing, contact the store where you purchased the product.
● Items to prepare: Drum key
Introduction
MSC9600
MTC9600
MBC9600
● Rods
(with memory clamps)
● Carrier body
● Rods
(with memory clamps)
● Snare drum
attachment
● Snare drum
receiver
● Owner’s Manual
(this document)
● Service location information
● Owner’s Manual
(this document)
● Service location information
● Carrier body
● Multi-tom receiver
● Hexagonal wrench
(6 mm)
(4 mm)
● Hexagonal wrench
(6 mm)
(4 mm)
● Carrier body
● Rods
(with memory clamps)
● Hexagonal wrench (4 mm)
● Owner’s Manual
(this document)
● Service location information
MSC9600 MTC9600 MBC9600
Owner's Manual
• 9
Preparations Before Mounting the Instrument
Installing the Rods
CAUTION
When the carrier is shipped from the manufacturer, the memory clamps are
attached to the rods.
The memory clamps are designed to prevent the instrument from falling if the rod
become loose. After mounting of the instrument is finished, be sure to securely
tighten the memory clamps.
■ Rod Installation Procedure
Although the rod shapes are different for snare drums/multi-toms and bass drums, the installation procedure
is the same.
1.
Loosen bolt
D
with a drum key, and then remove the memory clamp from the rod.
2.
Loosen bolt
E
so that the rod can be inserted into the rod holder.
3.
Insert the rod into the rod holder from below, and then roughly set the rod
installation position (height) and angle.
NOTE
: There is no difference between the left and right rods included with the
carrier.
Memory
clamp
Rod
Bolt
D
Memory
clamp
Rod holder
Bolt
E
