Installation
It is mandatory that all operations required for the
installation are carried out by a qualified or competent
person, in accordance with existing rules and
regulations.
It is dangerous to alter the specification in any way.
Using a gas cooking appliance will produce heat
and moisture in the room which it has been
installed in. Ensure a continuous air supply,
keeping the air vents in good conditions or
installing a cooker hood with discharge tube.
In case of intensive or long time use of the
appliance, make the ventilation more efficient,
by opening a window or increasing the electric
exhaust fan power.
Once you removed all packaging from the appliance,
ensure that it is not damaged and the electric cable is
in perfect conditions. Otherwise, contact your dealer
before proceeding with the installation.
Ensure that the gas supply complies with the gas type
stated on the identification label, placed near the gas
supply pipe.
Ensure a good ventilation around the appliance. A
poor air supply could cause lack of oxygen.
The manufacturer disclaims any responsability
should all the safety measures not be carried out.
During Operation
This appliance has been designed for cooking edible
foodstuff and to be used for domestic non-professional
purposes only. It must not be used for any other
purpose.
Ensure that all control knobs are in the OFF position
when not in use.
Should you connect any electrical tool to a plug near
this cooking appliance, ensure that electric cables are
not in contact with it and keep them far enough from
the heated parts of this appliance.
If the appliance is out of order, disconnect it from the
electric supply.
Child safety
This appliance has been designed to be operated by
adults and children under supervision. Young children
MUST NOT be allowed to tamper with the controls or play
near or with the oven.
Accessible parts of this appliance may become hot
when it is in use. Children should be kept away until
it has cooled.
MANUFACTURER:
ELECTROLUX ZANUSSI S.p.A.
Viale Bologna 298 - 47100 FORLI(Italy)
These warnings are provided in the interest of safety. You MUST read them carefully before installing
or using the appliance. It is most important that this instruction book should be retained with the
appliance for future reference. Should the appliance be sold or transferred, always ensure that the book
is left with the appliance in order that the new owner can get to know the functions of the appliance and
the relevant warnings.
For Your Safety
Cleaning and Manteinance
For hygiene and safety reasons, this appliance should
be kept clean at all times. A build-up of fats or other
foodstuff could result in a fire.
Disconnect the appliance from the electrical supply,
before carrying out any cleaning or manteinance work.
Technical assistance
Under no circumstances should you attempt to repair
the appliance yourself. Repairs carried out by
unexperienced persons may cause injury or serious
malfunctioning. Refer to your local Service Centre.
Always insist on genuine spare parts.
Environmental Information
After installation, please dispose of the packaging
with due regard to safety and the environment.
When disposing of an old appliance, make it unusable,
by cutting off the cable.
These instructions are only for the countries
stated by the symbol printed on the front cover
of this instruction book.
Guide to Use the instructions
The following symbols will be found in the text to guide you
throughout the Instructions:
Safety Instructions
Step by step instructions for an operation
Hints and Tips
Environmental information
F
ENGLISH
13
Instruction for the User
Hob burners control knobs
The hob burners control knobs are situated on the hob
lateral panel. The symbols on the knobs mean that :
l there is no gas supply
there is maximum gas supply
there is minimum gas supply
Lighting the burners
For easier lighting, proceed before putting a pan on
the pan support.
l To light a burner, push in the relevant control
knob and turn it anti-clockwise to "maximum"
position.
l Upon ignition, keep the knob pushed down for
about 5 seconds. This will allow the
"thermocouple" (Fig. 1 lett. D) to be heated and
the safety device to be switched off, otherwise
the gas supply would be interrupted.Then,
check the flame is regular and adjust it as
required.
l If you cannot light the flame even after several
attempts, check the "cap" (Fig. 1 lett. A) and
the "crown" (Fig. 1 lett. B) are in the correct
position.
l To put the flame out, turn the knob to the
symbol l.
Always turn the flame down or put it out
before taking the pans off the burner.
Using the hob correctly
To ensure maximum burner efficiency, it is strongly
recommended that you use only pots and pans with a flat
bottom fitting the size of the burner used, so that flame will
not spread beyond the bottom of the vessel (see the table
beside).
It is also advisable, as soon as a liquid starts boiling, to
turn down the flame so that it will barely keep the liquid
simmering.
Carefully supervise cookings with fats or oil,
since these types of foodstuff can result in a
fire, if over-heated.
Burner minimum maximum
diameter diameter
Big (rapid) 180 mm. 260 mm.
Medium (semirapid) 120 mm. 220 mm.
Small (Auxiliary) 80 mm. 160 mm.
Fig. 1 FO 0204
F
A - Burner cap
B - Burner crown
C - Ignition candle
D - Thermocouple
For the user
For Your Safety 12
Instruction for the User 13
Cleaning and Maintenance 14
Contents
For the installer
Technical Data 15
Gas connection 15
Electrical Connection 16
Adaptation to different types of gas 17
Building in 18
