Side 1/2

*Dimension does not c de 3/8” de f ge nd er.in lu wi lan arou lin

**The inside depth shown in the t le above ass es a ab um minimum c net back rd thickness of 3/8”.abi boa

17 ” - 20 ”17 ” - 20 ”1/2 1/2 1/8 1/8

1/2 1/2 1/8 1/8” - 23 ”20 ” - 23 ”

Without Backboard **With Backboard

*Inside Depth ( )B

*Inside

Width ( )A

Liner

Model

Custom Hood

Exterior Width

Power Pack

Model

AK0800AS

AK0836AS

AK0806AS

AK0842AS

AK0848AS

AK0854AS

AK0860AS

30 inches

36 inches

42 inches

48 inches

54 inches

60 inches

AK8000AS

and

AK8100AS

AK8200AS

AK8300ASX

28 ”1/2

1/2”

21/16''

3/4''

Plywood base thickness: 3/4”

thickness:

FIG 1

Installation -

Recommended

WARNING:

When building a custom hood for a power pack, always f w all aollo pplicable construct n codes and standards.io

See the illustrations and table below to locate your liner choice and use corresponding custom hood

base dimensions. For the liner installation, only the bottom of the custom hood is needed. Do not

finalize the entire custom hood yet, because an opening is needed for the power pack.

Zephyr recommends the base of the custom hood to be 3/4” thick plywood. The sides,

front and backboard (if included) of the custom hood to be 3/4” thick, assuming standard

cabinet widths.

FIG 1:

Consider the shape and size of the power pack to determine the configuration of the custom hood.

For more details, refer to the installation manual of the power pack.

FEB15.0301

AK08xxxS Adjustable Depth Liners

www.zephyronline.com

Zephyr Ventilation

2277 Harbor Bay Pkwy, Alameda, CA 94502

Tel: 1.888.880.8368 Fax: 1.888.990.8368 e-mail: productsupport@zeph onli comyr ne.

17 ” - 20 ”17 ” - 20 ”1/2 1/2 1/8 1/8

AK0840AS

AK0846AS

30 inches

36 inches

AK8400AS

28 ”1/2

1/2”

20 ” - 23 ”20 ” - 23 ”1/2 1/2 1/8 1/8

AK0886AS

AK0882AS

AK0888AS

36 inches

42 inches

48 inches

34 ”1/2

1/2”

AK0884AS

AK0880AS

54 inches

60 inches

AK8800AG

and

AK8800AS

52 ”1/2

1/2”

26 ” - 29 ”26 ” - 29 ”1/2 1/2 1/8 1/8

AK0886BS

AK0882BS

AK0888BS

36 inches

42 inches

48 inches

34 ”1/2

1/2”

AK0884BS

AK0880BS

54 inches

60 inches

52 ”1/2

1/2”

CAUTION:

Before sta in lling, remove any protective film from all parts.

The custom hood liner must be installed before the power pack unit. For installation into shallow

cabinets (20-

1/2

” to 21-

1/2

“ inside depth) the power pack must be installed before the liner front

panel section. This must be done because the power pack flange must fit under the liner front

panel section when an overlap occurs.

Refer to power pack instructions for mounting height details.

Install 1 small pad ( ), included in the A

hardware package, to each side of the main

liner plate. (See figures 1 and 2)

Temporarily install the main liner plate ( ) to B

the external base of the custom hood ( ).C

When inserting the main liner plate, push

slightly on the pads ( ) to prevent damage. A

Main liner plate should be positioned as far

back as possible.

Using a pen, mark the outline of the future

opening for the power pack. Remove the

main liner plate ( ) from the custom hood.B

Cut out an opening in the bottom of the

custom hood.

Reinstall the main liner plate to the base of

the custom hood and secure it with (5) 3/4”

screws for 30”/36”/42” custom hood exterior

width and (6) for 48”/54”/60” custom hood

exterior width.

Slide the front panel section ( ) into the nose D

of the custom hood base. Take care not to

scratch the main liner plate when installing

the front panel section of the liner. Assemble

it to the cabinet using (3) 1/2” screws for 30”/

36”/42” custom hood exterior width and (4) for

48”/54”/60” custom hood exterior width.

Note: When installing the power pack it will need to be secured to a wood surface and not only to

the liner. See power pack installation manuals for more detailed mounting instructions.

www.zephyronline.com

3 4

Installation -

ower Pack Liner

AK08xxxS Adjustable Depth Liners
