Installation Guide
2
Table of Contents
Mounting Solutions ............................................................ 3
Pole Mount with Pendant Mount Installation
Procedures ......................................................................... 4
Step 1: Unpack the Camera ...................................................................... 4
Step 2: Attach the Pole Mount Kit ............................................................ 6
Step 3: Install the Straight Tube ............................................................... 7
Optional: Add Extension Tube(s) ............................................................. 7
Step 4: Install the Camera ......................................................................... 8
Step 5: Connect the Cables .................................................................... 10
How to Waterproof the Cable Using the Cable Gland ............................ 11
How to Waterproof the Cable Using the Conduit Gland ........................ 15
Pole Mount with Pendant Mount and Junction Box
Installation Procedures ................................................... 19
Step 1: Unpack the Camera .................................................................... 20
Step 2: Prepare the Junction Box .......................................................... 21
Step 3: Prepare for Waterproof Installation ........................................... 22
Step 4: Prepare the Pole Mount Kit ........................................................ 23
Step 5: Install the Straight Tube ............................................................. 26
Optional: Add Extension Tube(s) ........................................................... 26
Step 6: Install the Camera ....................................................................... 27
Step 7: Connect the Cables .................................................................... 29
Appendices ....................................................................... 31
How to Install Extension Tubes .............................................................. 31
How to Use the Power Adapter (For I9x Models) .................................. 32
How to Attach the Safety Wire Strap (For I9x Models) ......................... 33
Safety Information ............................................................ 35
