BHV SERIES

Background Speakers

User Manual

Introduction

Thank you for choosing the Adastra BHV series speakers for your sound installation.

These durable cabinets deliver reliable, high quality sound output for music and

announcements. Please read the following guidance notes for correct installation.

Contents

BH series background speaker

2 x cross-head screws

Steel speaker bracket

2 x speaker screw caps

Plastic wall plate

Specifications

White stock ref.

952.612 UK

952.614 UK

952.616UK

952.618UK

Black stock ref.

952.613 UK

952.615 UK

952.617UK

952.619UK

Model

BH4V

BH5V

BH6V

BH8V

Impedance

16Ω

IP rating

IP44

Dispersion

120°

100V tappings

2.5 5 20W , , , 10

5 , 30W , , 10 20

10, , , 20 30 40W

20, 30, 40, 50W

Power max

60W

100W

140W

160W

Power rms

30W

50W

70W

80W

Freq. response

100Hz - 20kHz

80Hz - 20kHz

50Hz - 20kHz

30Hz - 20kHz

LF driver

100mmØ (4“)

135mmØ (5.25")

165mmØ (6.5")

200mmØ (8")

HF driver

13mmØ (0.5“)

25mmØ (1")

Sensitivity

88 dB

89 dB

90dB

Dimensions

195*127*126mm

25 635*1 *1 60mm

2 *1 *190 90 95 mm

378*244*240mm

Weight

1.63kg

2.38kg

3.28kg

4.82 kg

BHV Series User Manual

Installation

1. Unscrew the plastic wall plate from the speaker bracket and mark

out, drill and fix to the wall as required.

2. Line up the steel speaker bracket against the plastic wall plate at

the required tilt angle and secure using the 2 screws provided

through 2 of the punched holes.

3. Locate the speaker into the speaker bracket and secure using the

screw caps provided on the top and bottom. (Do not over-tighten)

4. Adjust the horizontal angle (pan) of the speaker by loosening the screw caps, turning the

speaker and re-tightening the screw caps.

5. Remove the cover on the rear of each speaker to reveal the spring terminals.

6. If the amplifier is 100V type, select the required wattage

output on the rotary switch inside the rear speaker

compartment.

7. If the amplifier is

not

a 100V type, ensure that the total

speaker load on each output is no lower tha that stated n

for the amplifier.

Select the 16 tion on the rotary switch and connect Ωop

1 x V speaker for a 16 load, BH Ω

2 x BHV speakers in parallel for an 8 load or Ω

4 x BHV speakers in parallel for a 4 load. Ω

8. Use good quality 2-core speaker wire capable of carrying the rated power and connect to

the speaker terminals. Strip back the insulation, press down the terminal, thread the wire

through the terminal post and release to grip the bare wire.

9. If installing in sheltered outdoor areas, fit the cover over the rear terminal cavity to protect

the wiring from moisture.

10.

Connect the + and - terminals on the speaker to the relative outputs on the amplifier.

Disposal: The “Crossed Wheelie Bin” symbol on the product means that the product is classed as

Electrical or Electronic equipment and should not be disposed with other household or commercial waste

at the end of its useful life. The goods must be disposed of according to your local council guidelines.

AVSL Group Ltd. Unit 2-4 Bridgewater Park, Taylor Rd. Manchester. M41 7JQ

AVSL (EUROPE) Ltd, Unit 3D North Point House, North Point Business Park, New Mallow Road, Cork, Ireland.
