Side 1/6
STARTUP MANUAL
1 Startup Manual
ADAM-4541
Fiber Optic to RS-232/422/485 Converter
Packing List
Before you begin installing your module, please make sure
that the following materials have been shipped:
1 x ADAM-4541 Module with DIN-rail mounting
bracket
1 x Panel Mounting Bracket
1 x Cable for DB-9 to 3-wired
(Red:RX, White:TX, Black:GND)
If any of these items are missing/damaged, contact your
distributor or sales representative immediately.
Notes
For more information on this and other Advantech
products, please visit our websites at:
http://www.advantech.com
http://www.advantech.com/eAutomation
For technical support and service:
http://www.advantech.com.tw/eservice
This startup manual is for the ADAM-4541
Part No: 2003454101 3rd Edition
June 2014
Overview
Fiber optic transmission offers the benefits of wide
bandwidth, immunity to EMI/RFI interference, and secure
data transmission. The ADAM-4541 can be used as an
RS-232/422/485 point-to-point or ring connection for
transmitting and converting full/half-duplex signals and
their equivalents within a ber optic environment. Fiber
optics are the perfect solution for applications where the
transmission medium must be protected from electrical
exposure, lightning, atmospheric conditions or chemical
corrosion.
The ADAM-4541 is specifically designed to link
various machinery equipped with RS-232/422/485
communication ports (such as computer systems or
manufacturing machines). Using standard ST connectors,
the module's ber optic ports can accommodate a wide
range of ber optic cable sizes, including 62.5/125 µm.
Features
Direct plug-and-play
Easily mounted on a DIN-rail, panel, or piggybacked
Transmission speeds of up to 115.2 kbps
Optical bers enable transmission of up to 2.5 km
Half/Full-duplex, bidirectional transmission mode
Support for ring-mode
Avoid lightning strikes and EMI/RFI
Prevents damage from electrostatic discharge
Stable and error-free data transmission
Automatic internal RS-485 bus supervision
No external ow control signals required for RS-485
Transient suppression and over-current protection on
RS-232/422/485 data lines
LED for power and data ow indication
Specifications
Fiber Optic : Multimode
Wavelength : 820 nm
Transmission Distance : 2.5 km
Optical Power Budget (attenuation) : 15 dB
Casing : ABS with captive mounting hardware
Communication Mode : Asynchronous
Connector : Plug-in screw terminal
Fiber port : ST
Transmission Mode : Full/Half-duplex, bidirectional
Transmission Rate : Up to 115.2 kbps
Power Requirement : Unregulated +10 ~ +30 V
DC
Operating Temperature : -10 ~ 70°C (14 ~ 158°F)
Operating Humidity : 5 ~ 95% (non-condensing)
Accessories : DIN-rail mounting adapter, panel
mounting bracket
Two Year Warranty
Advantech warrants to you, the original purchaser, that
this product will be free from defects in materials and
workmanship for two years from the date of purchase.
This warranty does not apply to any products which
have been repaired or altered by persons other than repair
personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation.
Advantech assumes no liability under the terms of this
warranty as a consequence of such events.
If your product is defective, it will be repaired or replaced
at no charge during the warranty period. package and ship
it prepaid to your dealer.
Startup Manual 2
Switch and Jumper Settings
ADAM-4541 provides three DIP switches that users
can congure the settings for their applications. SW1
and SW2 set the data format and baud rate of serial
communication. SW3 sets the Transmission mode.
SW1
Switch 1 controls the data format. Data can be 9, 10, 11 or
12 bits. The factory default is 10 bits : one start bit, eight
data bits, one stop bit and no parity bit.
*Default setting
When using the converter in combination with other
ADAM modules, do not change the default setting of the
converter, since ADAM modules have a xed data format
of ten data bits. The option of changing to 9, 11 or 12 bits
is for use with other modules (other than ADAM modules)
that have different data formats. Should you change the
ADAM module’s data format, be aware that you will also
have to change the data format on all the other modules
in the network.
SW2
Switch 2 sets the baud rate for RS-485 auto ow control.
The options range from 1200 bps to 115.2 kbps. The
factory default is 9600 bps. Be aware that when you
change the baud rate, you also have to change the baud rate
for all of the connected modules accordingly. You can refer
to the table below to make sure when you need to set SW2.
Baud Rate
SW2 123456789
1200 bps
ON OFF OFF OFF OFF OFF OFF OFF OFF
2400 bps
OFF ON OFF OFF OFF OFF OFF OFF OFF
4800 bps
OFF OFF ON OFF OFF OFF OFF OFF OFF
9600 bps*
OFF OFF OFF ON OFF OFF OFF OFF OFF
19.2 kbps
OFF OFF OFF OFF ON OFF OFF OFF OFF
38.4 kbps
OFF OFF OFF OFF OFF ON OFF OFF OFF
57.6 kbps
OFF OFF OFF OFF OFF OFF ON OFF OFF
115.2 kbps
OFF OFF OFF OFF OFF OFF OFF ON OFF
RS-232/422
OFF OFF OFF OFF OFF OFF OFF OFF ON
*Default setting
Data Format
SW1 1 2
9 bits OFF OFF
10 bits* ON
OFF
11 bits
OFF
ON
12 bits ON ON
SW3
The ADAM-4541 can support ring operation. By setting
the DIP2 of SW3, the ADAM-4541 can be set as "Ring"
or "Normal" mode. We will introduce more about ring
operation in the later chapter.
*Default setting
Reserved
SW3 1
Operation Mode
SW3 2
Normal Mode* OFF
Ring Mode ON
To Set to SW2
Operation Mode RS-232 RS-422 RS-485
Normal No No Yes
Ring Yes
Yes Yes
Note: When using RS-232/422 in ring mode, both position
9 of SW2 and the baud rate need to be congured. And
the device MUST be connected to prevent the possibility
of communications failure. For example, using RS-232
with a baud rate of 9600 kps in ring mode, both position 4
and position 9 need to be switched ON. But only position
9 needs to be switched on in normal mode.
