Side 1/6
STARTUP MANUAL
1 Startup Manual
ADAM-4541
Fiber Optic to RS-232/422/485 Converter
Packing List
Before you begin installing your module, please make sure
that the following materials have been shipped:
1 x ADAM-4541 Module with DIN-rail mounting
bracket
1 x Panel Mounting Bracket
1 x Cable for DB-9 to 3-wired
(Red:RX, White:TX, Black:GND)
If any of these items are missing/damaged, contact your
distributor or sales representative immediately.
Notes
For more information on this and other Advantech
products, please visit our websites at:
http://www.advantech.com
http://www.advantech.com/eAutomation
For technical support and service:
http://www.advantech.com.tw/eservice
This startup manual is for the ADAM-4541
Part No: 2003454101 3rd Edition
June 2014
Overview
Fiber optic transmission offers the benefits of wide
bandwidth, immunity to EMI/RFI interference, and secure
data transmission. The ADAM-4541 can be used as an
RS-232/422/485 point-to-point or ring connection for
transmitting and converting full/half-duplex signals and
their equivalents within a ber optic environment. Fiber
optics are the perfect solution for applications where the
transmission medium must be protected from electrical
exposure, lightning, atmospheric conditions or chemical
corrosion.
The ADAM-4541 is specifically designed to link
various machinery equipped with RS-232/422/485
communication ports (such as computer systems or
manufacturing machines). Using standard ST connectors,
the module's ber optic ports can accommodate a wide
range of ber optic cable sizes, including 62.5/125 µm.
Features
Direct plug-and-play
Easily mounted on a DIN-rail, panel, or piggybacked
Transmission speeds of up to 115.2 kbps
Optical bers enable transmission of up to 2.5 km
Half/Full-duplex, bidirectional transmission mode
Support for ring-mode
Avoid lightning strikes and EMI/RFI
Prevents damage from electrostatic discharge
Stable and error-free data transmission
Automatic internal RS-485 bus supervision
No external ow control signals required for RS-485
Transient suppression and over-current protection on
RS-232/422/485 data lines
LED for power and data ow indication
Specifications
Fiber Optic : Multimode
Wavelength : 820 nm
Transmission Distance : 2.5 km
Optical Power Budget (attenuation) : 15 dB
Casing : ABS with captive mounting hardware
Communication Mode : Asynchronous
Connector : Plug-in screw terminal
Fiber port : ST
Transmission Mode : Full/Half-duplex, bidirectional
Transmission Rate : Up to 115.2 kbps
Power Requirement : Unregulated +10 ~ +30 V
DC
Operating Temperature : -10 ~ 70°C (14 ~ 158°F)
Operating Humidity : 5 ~ 95% (non-condensing)
Accessories : DIN-rail mounting adapter, panel
mounting bracket
Two Year Warranty
Advantech warrants to you, the original purchaser, that
this product will be free from defects in materials and
workmanship for two years from the date of purchase.
This warranty does not apply to any products which
have been repaired or altered by persons other than repair
personnel authorized by Advantech, or which have been
subject to misuse, abuse, accident or improper installation.
Advantech assumes no liability under the terms of this
warranty as a consequence of such events.
If your product is defective, it will be repaired or replaced
at no charge during the warranty period. package and ship
it prepaid to your dealer.
