AIMC-3202 Startup Manual 1

Before you begin installing your card, please make sure

that the following items have been shipped:

1. AIMC-3202 Bare System x 1

P/N: AIMC-3202-00A1E

(AIMC-3202-01A1E)

2. Driver CD x 1 P/N: 2061302900

3. USB 2.0 Cable x 1 P/N: 1700014398

4. USB 3.0 Cable x 1 P/N: 1700020277-01

5. Four-port USB Cable x 1 P/N: 1700014398

6. LPT Cable x 1 P/N: 1700002223

7. Mounting Brackets x 2 P/N: 1960014487T00C

8. Rubber Foot x 4 P/N: 1990012452S000

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

Note 1: For detailed contents of AIMC-3202, please refer

to information on the enclosed CD-ROM (in PDF

format).

Note 2: Acrobat Reader is required to view any PDF ﬁle.

Acrobat Reader can be downloaded at: get.

adobe.com/reader (Acrobat is a trademark of

Adobe)

AIMC-3202

Micro Computer, Intel

Core™ i7/i5/i3 CPU,

H110, 2 Expansions, 250W 80Plus PSU

Startup Manual

Processor System

Processor

System

(0 ~ 40° C for

65W CPU)

(0 ~ 45° C for

35W CPU)

CPU

i7-

6700

i7-

6700TE

i5-

6500

i5-

6500TE

i3-

6100

i3-

6100TE

4400

4400TE

3900

3900TE

Core 4 4 4 4 2 2 2 2 2 2

Base

Frequency

3.4

GHz

2.4

GHz

3.2

GHz

2.3

GHz

3.7

GHz

2.7

GHz

3.3

GHz

2.9

GHz

2.8

GHz

2.6 GHz

L3 Cache 8M 8M 6M 6M 4M 4M 3M 3M 2M 2M

Chipset H110

BIOS AMI 128Mb SPI Flash

* Part Number iX-XXXXTX & GXXXXXX can use 1U CPU

Cooler for 2 Expansion slots. Other CPUs have to use 1.5U

Cooler for 1 Expansion slot.

BIOS

• AMI 128 Mbit SPI Flash

Chipset

• Intel H110

Memory

• Supports Dual Channel DDR4 1866/2133 16 GB per

DIMM, Max capacity is 32 GB

Graphic

• Chipset: Intel

HD Graphics

Expansion Slot

• AIMC-3202-00:

- One PCIe p1-x16 (Upper-layer slot)

- One PCIe p1-x4 (Lower-layer slot)

• AIMC-3202-01:

- One PCI (Upper-layer slot)

- One PCIe p1-x16 (Lower-layer slot)

Ethernet

• Chipset support:

- LAN 1: Intel

I219V

- LAN 2: Intel

I211AT

• Connection: 2 x on-board RJ-45 connector with LED

indicators

SATA

• Max Data Transfer Rate: 600 MB/s (SATA 3.0)

• HDD Bay: 2 internal 2.5”

I/O Interface

• Display: VGA + DVI-D

• USB: 3 USB3.0

• PS/2: 1

Watchdog Timer

• Programmable 1~255 sec/min

Specications

Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://support.advantech.com.tw/support/default.

aspx

This manual is for the AIMC-3202 Series Rev. A1.

Part No. 2001320200

Printed in China

1st Edition

October 2016

2 AIMC-3202 Startup Manual

Power Supply

• Output Rating: AC 250W, ATX

• Input Voltage: 100 VAC ~ 240 VAC

Cooling

• System Fan: 2 (6cm / 27.7 CFM)

• Air Filter: Yes

Environment

• Operating Temperature: 0 ~ 40°C (32 ~ 104°F)

• Non-operating Temperature: -20 ~ 60°C (-4 ~ 140°F)

• Operating Humidity: 10 ~ 85% @ 40°C, non-condensing

• Non-operating Humidity: 10 ~ 95% @ 40°C, non-

condensing

Physical Characteristics

• Dimension (WxHxD): 232 x 90 x 232 mm

The board has a number of jumpers that allow you to con-

ﬁgure your system to suit your application. The table below

lists the function of each of the jumpers and connectors.

Connectors

Label Function

LPT1 Parallel port, supports SPP/EPP/ECP mode

LAN1 Intel I219V

LAN2 Intel I211AT

VGA1 VGA connector

KBMS1 External keyboard/mouse connector

COM12 Box header for RS-232*2

FP1

HDD LED, power LED, SNMP SM_Bus,

reset, power on/off

JCASE1 Case open

CPUFAN1 CPU FAN connector (4-pin)

LANLED1 LAN1/2 LED connector

HDAUD1 HD audio extension module connector

USB1 USB port 1 (USB 3.0 port)

USB23 USB port 2, 3 (USB 3.0 port)

USB45 USB port 4, 5 (USB 2.0)

USB67 USB port 6, 7 (USB 2.0)

USB89 USB port 8, 9 (USB 2.0)

USB11 Type A connector on board (USB 2.0)

SATA0 Serial ATA1 (SATA 3.0)

SATA1 Serial ATA2 (SATA 3.0)

SATA2 Serial ATA3 (SATA 3.0)

SATA3 Serial ATA4 (SATA 3.0)

CPU1 CPU Socket

DIMMA1 Memory connector channel A

DIMMB1 Memory connector channel B

GPIO1 GPIO pin header

LPC1 Low pin count module expansion pin-header

PWR1 12 V, 5 V power connector

DVI1

DVI connector

DP1

Display pin header to stack board (Display

type depends on optional stack board)

EXPCIE1 mini PCIe pin header to stack board

MINIPCIE

MSATA

M-SATA (default) or mini-PCIe connector

(optional for PCE-4129)

Jumpers

Label Function

JCMOS1 CMOS clear

JOBS1+JWDT1

Hardware monitor alarm+watchdog

timer output selection

JME1 Enable ME

JCMOS1: Clear CMOS

Closed Pins Result

1-2 Keep CMOS (Default)

2-3 Clear CMOS

JOBS1+JWDT1: Hardware monitor alarm+watchdog

timer output selection

Function Jumper Setting

2-3 Enable watchdog timer (Default)

4-5 Enable Hardware monitor alarm (Default)

JME1: Enable ME

Closed Pins Result

1-2

Enable ME

(Default)

2-3 Disable ME

Jumpers and Connectors

(Cont.)

Specications (Cont.)
