Side 1/4

AMAX-4817/4820 Startup Manual 1

Before installation, please check that the following items are

included in the shipment:

1. AMAX-4817/4820 module

2. Terminal blocks (see Specications for more details)

3. Startup Manual

If any of these items are missing or damaged, contact your

distributor or sales representative immediately.

For more detailed information about this product, download

the latest user manual from the Advantech website.

The AMAX-4817/4820 ESI le can be downloaded from

the Advantech website at http://www.advantech.com.

Every EtherCAT SubDevice information (ESI) le con-

tains the conguration data of an EtherCAT SubDevice

module. Various EtherCAT communication settings can

be dened from the ESI les of connected SubDevice

units as well as the network connection information. ESI

les are saved to the conguration tool to provide net-

work conguration data. Subsequently, the network

conguration data can be downloaded to the EtherCAT

MainDevice unit for conguring an EtherCAT network.

AMAX-4817/4820

Industrial EtherCAT SubDevice Modules

Startup Manual

The AMAX-4817/4820 series comprises industrial EtherCAT

SubDevice modules equipped with the EtherCAT protocol.

The modules’ compact size and integrated DIN-rail mount

kit ensure easy installation in cabinets. The modules also

feature euro-type pluggable terminal blocks and LED in-

dicators that facilitate system setup and maintenance. All

modules are equipped with an isolation circuit that ensures

current protection for demanding industrial applications.

General

• Connectors

- N x 10-pin terminal block (3.81 mm)

(AMAX-4817 N = 2, AMAX-4820 N = 1)

- 2 x 3-pin screw terminal blocks (3.81 mm)

- 2 x RJ-45 (EtherCAT)

• Dimensions:120 x 120 x 40 mm

• OperatingTemperature: -20 ~ 60 °C (32 ~ 140 °F)

• StorageTemperature:-40 ~ 70 °C (-40 ~ 158 °F)

• StorageHumidity:5 ~ 95% RH (non-condensing)

• PowerSupply:10 ~ 30 V

Communications

• Interface:EtherCAT

• DataTransferMedium:Ethernet/EtherCAT cable (CAT5

min.), shielded

• DistanceBetweenModules:100 m max. (100BASE-TX)

• CommunicationCycleTime100 μs

• DataTransferRates:100 Mbps

• Conguration:Not required

AnalogInput(AMAX-4817)

• Channels: 8 channels

• Resolution: 16-bit

• InputVoltageRange:0 ~ 10 V, ±10 V, 0~20 mA, ±20 mA

• Common-ModeInputVoltageRange:±275 V

• MeasuringError: < ±0.1%

• IsolationProtection: 2,500 V

• Bandwidth(-3dB):1.375 kHz/ch

PackingList

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://support.advantech.com

This manual is for the AMAX-4817 and 4820 modules.

Part No. 2001481702

Printed in China

Edition 3

May 2023

Specications

Overview

UserManual

EtherCATSubDeviceInformationFile
