Side 1/4

AMAX-4800 Startup Manual 1

Before installation, please check that the following items are

included in the shipment:

1. 1 x AMAX-4800 module

2. 2 x Terminal blocks (see Specications for more details)

3. 1 x AMAX-4800 startup manual

If any of these items are missing or damaged, contact your

distributor or sales representative immediately.

For more detailed information about this product, download

the latest user manual from the Advantech website.

The AMAX-4800 EtherCAT SubDevice informa-

tion (ESI) le can be downloaded from the Ad-

vantech website at http://www.advantech.com.

Every ESI le contains the conguration data of an Ether-

CAT SubDevice module. Various EtherCAT communica-

tion settings can be dened from the ESI les of con-

nected SubDevice units as well the network connection

information. ESI les are saved to the conguration tool to

provide network conguration data. Subsequently, the net-

work conguration data can be downloaded to an Ether-

CAT MainDevice unit for conguring an EtherCAT network.

AMAX-4800 Series

Industrial EtherCAT SubDevice Modules

Startup Manual

The AMAX-4800 series comprises industrial EtherCAT Sub-

Device modules equipped with the EtherCAT protocol. The

modules’ compact size and integrated DIN-rail mount kit en-

sure easy installation in a variety of cabinets. The modules

also feature euro-type pluggable terminal blocks and LED

indicators that facilitate system setup and maintenance. All

modules are equipped with an isolation circuit that ensures

current protection for demanding industrial applications.

General

• Connectors

- 10-pin terminal block (3.81 mm) * N

(AMAX-4830/30SO/33/34/50: N = 4,

AMAX-4855/56: N = 8,

AMAX-4860: N = 3,

AMAX-4862: N = 6)

- 3-pin screw terminal block (3.81 mm) * 2 (power)

- RJ-45 * 2 (EtherCAT)

• Dimensions

AMAX-4830/30SO/33/34/50/60: 120 x 120 x 40 mm

AMAX-4855/56/62: 168 x 120 x 40 mm

• OperatingTemperature: -20 ~ 60 °C (32 ~ 140 °F)

• StorageTemperature:-40 ~ 70 °C (-40 ~ 158 °F)

• StorageHumidity:5 ~ 95% RH (non-condensing)

• PowerSupply:10 ~ 30 V

Communications

• Interface:EtherCAT

• DataTransferMedium:Ethernet/EtherCAT cable (CAT5

min.), shielded

• DistanceBetweenModules:100 m max.(100BASE-TX)

• CommunicationCycleTime:100 us

• DataTransferRate:100 Mbps

• Conguration:Not required

DigitalInput

• Channels

- AMAX-4830/4830SO/4850/4862: 16 channels

- AMAX-4833/4855/4856: 32 channels

- AMAX-4860: 8 channels

• InputVoltage

- Logic 0: 3 V max.

- Logic 1: 10 V min. (30 V max.)

• IsolationProtection: 2,500 V

PackingList

For more information about this or other Advantech

products, please visit our website at

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at

http://support.advantech.com

This manual is for the AMAX-4800 series modules.

Part No. 2001483004 Edition 5

June 2024

Specications

Overview

UserManual

EtherCATSubDeviceInformationFile

2 AMAX-4800 Startup Manual

FCCClassA

This equipment has been tested and found to comply with

the limits for a Class A digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide rea-

sonable protection against harmful interference when the

equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in residential

areas is likely to cause interference. In such cases, users

are required to correct the interference at their own expense.

This product has passed the CE test for environmen-

tal specications when shielded cables are used for

external wiring. We recommend the use of shield-

ed cables. Advantech does provide shielded cables.

Contact your local supplier for ordering information.

AMAX-4800 modules use two hexadecimal rotary switches

to represent the SubDevice ID (range: 0 ~ 255).

For example, if a user arranges the rotary switches follow-

ing the sequence “4, F”, the SubDevice ID will be set as “4

x 16 + F x 1= 79”.

AMAX-4830SO

AMAX-4830SO provides separated COM connections

in groups of eight digital input/output channels. As a de-

fault, EC0, EC1, PC0, and PC1 are isolated from each

other. However, for cases where EC0 and EC1, or PC0

and PC1, need to be connected together, this can be

achieved using SW2 and SW3. EC0 and EC1 are con-

nected together when the SW2 switch is in the up (open)

position. Similarly, PC0 and PC1 are connected to-

gether when the SW3 switch is in the up (open) position.

SW2/SW3SwitchintheUpPosition

EC0 & EC1 Open

PC0 & PC1 Open

SW2/SW3SwitchintheDownPosition

EC0 & EC1 Close

PC0 & PC1 Close

DigitalOutput

• Channels

- AMAX-4830/4830SO: 16 channels

- AMAX-4834/4856: 32 channels

• LoadVoltage:5 ~ 40 V

• LoadCurrent

- 350mA/channel (sink)@25 °C

- 250mA/channel (sink)@60 °C

AMAX-4830SO:

- 250mA/channel (source)@25 °C

- 200mA/channel (source)@60 °C

• IsolationProtection:2,500 V

• Opto-IsolatorResponseTime: 100 us

PhotoMOSRelayOutput

• Channels

AMAX-4850: 8 channels

AMAX-4855: 16 channels

• RelayType: PhotoMOS SPST (Form A)

• LoadVoltage:60 V (AC peak or DC)

• LoadCurrent: 1.2A

• PeakLoadCurrent:4A @100 ms (1 pulse)

• IsolationProtection: 1,500 V

• Turn-OnTime:1 ms typical

• Turn-O󰀨Time: 0.6 ms typical

RelayOutput

• Channels

AMAX-4860: 8 channels

AMAX-4862: 16 channels

• Relaytype:Form A

• ContactRating(Resistive): 2A@250 V

, 2A@30 V

• Max.SwitchingPower:500 VA , 60W

• Max.SwitchingVoltage:270 V

, 125 V

• Resistance:30 mΩ max.

• OperatingTime:10 ms max.

• ReleasingTime: 5 ms max.

• LifeExpectancy

- Mechanical: 2 x 10

ops. at no load

- Electrical: 3 x 10

ops. @2A/250 V

1. Download the AMAX-4800 user manual and ESI le.

https://www.advantech.com/zh-tw/search/?q=AMAX-

4856&st=support.

2. Import the ESI le to create an EtherCAT network

information (ENI) le using either

(1) Advantech Common Motion Utility

(with a PCI-1203 EtherCAT MainDevice card)

(2) Other EtherCAT MainDevice software, such as

TwinCAT or Acontis

3. Use the MainDevice utility to test the AMAX-4800

modules.

AMAX-4800 modules feature two power input terminals,

an input power range of 10 ~ 30 V

, and power redun-

dancy support. For modules connected to two power input

sources, if one source is inactive or interrupted, the other

power source can take over immediately. The AMAX-4800

modules can operate with only a single power source.

RotarySwitch

DeclarationofConformitySpecications(Cont.)

Power

Installation

DipSwitch
