EKI-2708G/2710G Series Startup Manual 1

EKI-2708G-PI&EKI-2710G-2FPI

Industrial Unmanaged PoE Switch

Startup Manual

Specications

Overview

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

For technical support and service, please visit our

support website at:

http://www.advantech.com/support

This manual is for EKI-2708G-PI & EKI-2710G-2FPI.

Part No. 2049270800

Printed in Taiwan

1st Edition

Feb 2024

General

• Compatibility: IEEE 802.3, 802.3u, 802.3z, 802.3ab,

802.3x, 802.3at/af

• LAN:

EKI-2708G-PI:

- 8 x 10/100/1000BASE-T/TX RJ-45 PoE Ports

EKI-2710G-2FPI:

- 8 x 10/100/1000BASE-T/TX RJ-45 PoE Ports

- 2 x SFP (mini-GBIC) 100/1000Mbps port

• Ethernet RJ-45: Up to 100 m

• SFP: Up to 110 Km (depends on SFP)

• Connectors:

- EKI-2708G-PI: 8 x RJ-45

- EKI-2710G-2GPI: 8 xRJ45, 2 x SFP

• Switch Architecture: Store and Forward

• Power Input: 12~48VDC, redundant power

• Power Consumption: Max 5.28W (system)

• Power Budget:

- 240W@48VDC

- 120W@24VDC

- 80W@12VDC

• Dimensions (W x H x D): 54 x 140 x 120 mm

• Enclosure: IP30

• Operating Temperature: -40 ~ 75°C (-40 ~ 167°F)

• Storage Temperature: -40 ~ 85°C (-40°F ~ 185°F)

• Operating Humidity: 5 ~ 95% (non-condensing)

• Storage Humidity: 5 ~ 95% (non-condensing)

• Safety: LVD EN62368

• EMC: FCC Class A, CE

• Warranty: 5 year

The EKI-2708G and EKI-2710G PoE Switch: These

unmanaged Ethernet switches support 8 PoE+ (Power over

Ethernet) ports and comply with IEEE 802.3at/af standards.

Each port provides up to 30 watts of power, with a total

power budget of 240 watts for the system. The switch

includes a relay output for event alarms, notifying adminis-

trators when activated. Designed for harsh environments, it

features robust construction, din rail mounting, and a quick

startup with plug-and-play functionality.

The EKI-2708G and EKI-2710G support IEEE

802.3/802.3u/802.3z/802.3ab/802.3x with 10/100/1000

Mbps, full/half-duplex, auto-negotiation and MDI/MDI-X

auto-sensing to provide an economical solution for your

industrial Ethernet network.

Packing List

Before installation, please make sure that you have re-

ceived the following:

• 1 x EKI-2708G/EKI-2710G Ethernet Switch

• 1 x DlN-rail mounting brackets with screws

• 1 x EKI-2708G/EKI-2710G Startup Manual

If anything is missing or damaged, contact your distributor

or sales representative immediately.

User Manual

For more detailed information, please refer to the full

manual which can be found on the Advantech’s website.

2 EKI-2708G/2710G Series Startup Manual

EKI-2708G-PI EKI-2710G-2FPI

E KI-2525/I

LED Denition

EKI-2708G-PI

LED Color Description

P1 Green

On P1 is being supplied to

power input.

O󰀨 P1 is not being supplied to

power input.

P2 Green

On P2 is being supplied to

power input.

O󰀨 P2 is not being supplied to

power input.

ALM Green

On When P1 or P2 is discon-

nected, the LED lights

O󰀨 When P1 or P2 is con-

nected,theLEDiso󰀨

PoE

(1~8) Green

On PoE activated

O󰀨 PoE non-working

Copper

Ports

(1~8)

Green

(top)

On When the port’s data is being

transmitted at 1000Mbps

O󰀨 When the port’s data is being

transmitted at 10/100Mbps

Green

(bottom)

On Ethernet port link

Blinking Ethernet port active

O󰀨 No link

EKI-2710G-2FPI

LED Color Description

P1 Green

On P1 is being supplied to

power input.

O󰀨 P1 is not being supplied to

power input.

P2 Green

On P2 is being supplied to

power input.

O󰀨 P2 is not being supplied to

power input.

ALM Green

On When P1 or P2 is discon-

nected, the LED lights

O󰀨 When P1 or P2 is con-

nected,theLEDiso󰀨

PoE

(1~8) Green

On PoE activated

O󰀨 PoE non-working

Copper

Ports

(1~8)

Green

(top)

On When the port’s data is being

transmitted at 1000Mbps

O󰀨 When the port’s data is being

transmitted at 10/100Mbps

Green

(bottom)

On Ethernet port link

Blinking Ethernet port active

O󰀨 No link

SFP

Port

(9~10)

Green

On The port has established

a link

Blinking

When Fiber port’s data

is being transmitted at

100M/1000Mbps

O󰀨 When Fiber port linked

down/inactive

Overview

LED Denition (Cont.)
