Side 1/6

PCA-6105P3-5 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

3 pin ATX signal Cable p/n: 1700030500

PCA-6105P3-5 Startup Manual

M4*6*0.7 Round Screws (8 pcs) p/n: 1939000410

2 Year Quality Warranty Card p/n: 2190000902

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

•

PCA-6105P3-5 Backplane: 5 slot BP for 5-slot

Chassis, 1 PICMG 1.0, 1 ISA, 2 PCI, 1 ISA/PCI

Startup Manual

Standard Functions

PICMG 1.0 slots:

PCA-6105P3-5 supports PCA-xxxx CPU boards

ISA slots:

One ISA slots (ISA 2 may be conﬂicted)

32-bit PCI:

Two 32 Bit / 33 MHz PCI slots

ISA/PCI slot:

One ISA/PCI slot (ISA3 and PCI1 are alternative)

Mechanical and Environment

Dimensions: 106.5 mm x 327.66 mm

Power supply voltage: +12 V, +5 V, -12 V, -5 V, +3.3 V,

+5 V SBY

Power requirements: Refer to the CPU Board, add-on

Card & Peripherals

Operating temperature: 0 ~ 60° C

Weight: 0.2 KG (weight of board)

•

Specications Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/ePlatform

For technical support and service, please visit our

support website at:

http://service.advantech.com.tw/

This manual is for the PCA-6105-5 series Rev.A1

Part No. 200K610550

Printed in China

1st Edition

Dec. 2008

2 PCA-6105P3-5 Startup Manual

PWR1

Pin Name

1 12 V

2 GND

3 GND

4 5 V

VOLT1

Pin Name

1 5 V SBY

2 GND

3 GND

4 -5 V

5 5 V

6 3.3 V

7 -12 V

8 12 V

FAN1 ~ FAN3

Pin Name

1 GND

2 12 V

3 FANIO1 ~ FANIO3

FANDEC1

Pin Name

1 FANIO1

2 FANIO2

3 FANIO3

SMBUS1 ~ SMBUS2

Pin Name

1 5 V

2 C-SMBBUS

3 C-SMBDAT

4 GND

The table below lists the function of each of the jumpers and

connectors:

Connectors

Label Function

PICMG1 PICMG1.0 CPU board slot

ISA2 ISA slot

ISA3/PCI1 ISA/PCI slot

PCI2 ~ PCI3 32 Bit / 33 MHZ PCI Bus slot

EATXPWR1 ATX2.0 24-pin Power Connector

PWR1 ATX 12 V auxiliary 4-pin Power Con-

nector

VOLT1 Alarm board / CMM Power Connector

FAN1 ~ FAN3 FAN Connector

FANDEC1 FAN speed detector Connector

SMBUS1 SMBus Connector for chassis monitor

SMBUS2 SMBus Connector for chassis monitor

Jumpers

Label Function

PSON1 ATX / AT Mode Selection

1-2 closed pins

AT Mode

2-3 closed pins

ATX Mode (Default)

Connectors & Jumpers

Connector Pin Denition
