PCE-3B03-01 Startup Manual 1

Before installing your card, please ensure that the following

items have been shipped:

• PCE-3B03-01 User Manual 1st edition p/n: 20063B0310

• Two-year quality warranty card p/n: 2190000902

If either of the above items are missing or damaged, please

contact your distributor or sales representative immediately.

PCE-3B03-01 Backplane: 3 Slot PICMG1.3 BP, PCI*1,

PCIe x16*1

Startup Manual

Standard Functions

• PICMIG 1.3 slots: PCE-3B03-01 supports PICMG1.3

half-sized SHB

• PCIe slots: PCE-3B03-01 supports one PCIe x16 and

one PCI

Mechanical and Environmental

• Dimensions: 173 x 86.3 mm

• Power supply voltage: +12 V, +5 V, -12 V, +3.3 V, and

+5VSBY

• Power requirements: Refer to the CPU board, add-

on card, and peripherals

• Operating temperature: 0 ~ 60 °C

• Weight: 0.104 kg (weight of board)

Specications

Packing List

For more information about this or other Advantech

products, please visit our website at

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at

http://support.advantech.com/

This manual is for the

PCE-3B03-01

series, Revision A1.

Part No. 20063B0310

Printed in China

1st Edition

September 2014

2 PCE-3B03-01 Startup Manual

The backplane features several connectors and jumpers

that allow the system to be conﬁgured for speciﬁc

applications. The function of each jumper and connector

is listed in the table below.

Connectors

Label Function

SHBA1~SHBB1 PICMG1.3 CPU board slot

PPCIEX16_1

PCIe x16 slot

PPCI1

PCI slot

EATXPWR1 ATX2.0 24-pin power connector

ATX12V1 ATX 12 V 4-pin power connector

FAN1 FAN connector

FAN2 FAN connector

FAN3 Reserved

SMBUS1

SMBus connector for chassis

monitoring

JFP1 Power and reset button connector

Jumpers

Label Function

PSON1 ATX / AT mode selection

JFAN_CTRL1 System smart fan selection

JM66EN1 33 MHz / 66 MHz selection

ATX12V1

Pin Name

1 GND

2 GND

3 12 V

4 12 V

EATXPWR1

Pin Name

1 3.3 V

2 3.3 V

3 GND

4 5 V

5 GND

6 5 V

7 GND

8 Power OK

9 5 V SB

10 12 V

11 12 V

12 3.3 V

13 3.3 V

14 -12 V

15 GND

16 PSON#

17 GND

18 GND

19 GND

20 -5 V

21 5 V

22 5 V

23 5 V

24 GND

Connectors and Jumpers Connectors and Jumpers (Cont.)
