PCE-3B06-03 Startup Manual 1

Before you begin installing your card, please make sure that

the following items have been shipped:

• PCE-3B06-03A1E User Manual 2

Ed. p/n: 20023B0621

• 2-year quality warranty card p/n: 2190000902

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

PCE-3B06-03 Backplane: 6 Slot PICMG 1.3 Half-size

BP, 1 x PCIe x16, 1 x PCIe x1, 3 x PCI

Startup Manual

Standard functions

• PICMG 1.3 slots:

PCE-3B06-03 supports PICMG1.3 half-sized SHB

• PCIe slots:

PCE-3B06-03 Supports one PCIe x16 slot, one PCIe x1

• PCI slots:

PCE-3B06-03 Supports 3 PCI Slots

Mechanical and Environment

• Dimensions: 176 x 142.17 mm

• Power supply voltage: +12 V, +5 V, -12 V, +3.3 V +5

VSBY

• Power requirements: Refer to the CPU Board, add-on

card & peripherals

• Operating temperature: 0 ~ 60 °C

• Weight: 0.2 kg (weight of board)

Specications Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://www.advantech.com.tw/support

This manual is for the PCE-3B06-03A1E series.

Part No. 20023B0621

Printed in China

Edition

June 2013

2 PCE-3B06-03 Startup Manual

Connectors

Label Function

SHBA1 ~ SHBB1 PICMG1.3 CPU board slot

PCIEX16_1 PCIe x16 slot

PCIEX1_1 PCIe p2-x1 slot

PPCI1, PPCI2, PPCI3 PCI 32-bit / 33-Mhz slot

EATXPWR1 ATX2.0 24-pin power connector

PWR1 Big 4 pin power connector

VOLT1

Alarm board/CMM power con-

nector

FAN1 FAN connector

FAN2 FAN connector

FAN3 FAN connector

SMBUS1

SMBus connector for chasis

monitor

JFP1

Power and Reset button con-

nector

Jumpers

Label Function

PSON1 ATX/AT Mode Selection

JANFAN_CTRL1 System Smart Fan Control

JM66EN1 PCI Bus Frequency Selection

EATXPWR1

Pin Name

1 3.3 V

2 3.3 V

3 GND

4 5 V

5 GND

6 5 V

7 GND

8 Power OK

9 5 V SB

10 12 V

11 12 V

12 3.3 V

13 3.3 V

14 -12 V

15 GND

16 PSON#

17 GND

18 GND

19 GND

20 -5 V

21 5 V

22 5 V

23 5 V

24 GND

Jumpers
