PCE-5B05V-30B1E Startup Manual 1

Before you begin installing your card, please make sure

that the following items have been shipped:

• One 2-port USB cable p/n: 1700002204

• PCE-5B05V-30B1E startup manual

• M4*6*0.7 round screws (5 pcs) p/n: 1939000410

• Warranty Card p/n: 2190000902

If any of these items are missing or damaged, please con-

tact your distributor or sales representative immediately.

PCE-5B05V-30B1E Backplane: 5-slot BP for 2U Chas-

sis, 1 x PICMIG 1.3, 1x PCIe, 3 x 64-bit PCI-X

Startup Manual

Standard Functions

• PICMIG 1.3 slots:

PCE-5B05V-30 supports PCE-5xxx CPU boards

• PCIe slots:

PCE-5B05V-30 supports one PCIe x16 slot

• 64-bit PCI-X:

Three 64 Bit / 100 MHz PCI-X slots

• USB (2.0) support:

Four Universal Serial Bus ports to backplane

Mechanical and Environment

• Dimensions: 80.01 x 325 mm

• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +5 V

SBY, +3.3 V

• Power requirements: Refer to the CPU board, add-on

card and peripherals

• Operating temperature: 0 ~ 60° C

Specications Packing List

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/Network/

For technical support and service, please visit our

support website at:

http://www.advantech.com/support

This manual is for the PCE-5B05V-30B1E series.

Part No. 200K5B0503 4th Edition

May 2016

2 PCE-5B05V-30B1E Startup Manual

Connectors & Jumpers

Connectors

Label Function

SHBA1 ~ SHBD1 PICMG1.3 CPU board slot

PPCIE1 PCIe x 8 Slot

PPCIE2 PCE-5B05V-30: PCIe x 8 slot

P1PCIX1 64-bit / 66 MHz PCI-X slot

P1PCIX2 64-bit / 66 MHz PCI-X slot

P1PCIX3 64-bit / 66 MHz PCI-X slot

EATXPWR1 ATX2.0 24-pin power connector

EATX12V1 ATX 12v auxiliary 8-pin power connector

ATX12V1 ATX 12 V 4-pin power connector

VOLT1 Alarm board / CMM power connector

FAN1 FAN connector (box header)

FAN2 FAN connector (box header)

FAN3 FAN connector (box header)

FAN4 FAN connector (box header)

FANDEC1 FAN speed detector connector

SMBUS1 SMBus connector for chassis monitor

SMBUS2 SMBus connector for chassis monitor

JFP1 Power and reset button connector

IPMB1 IPMB connector

USB12 Two USB port pin header

USB34 Two USB port pin header

Jumpers

Label Function

PSON1 ATX / AT mode selection

JP1VI01 P1PCIX1 and P1PCIX2 3.3V / 5V VIO

Selection

PCI-X jumper setting

Bus Rate/

Mode

JPCIXCAPA1 JSEL100A1 JM66ENA1

PCI 25MHz (1-2)GND (1-2)High (2-3)GND

PCI 33MHz (1-2)GND (2-3)GND (2-3)GND

PCI 50MHz (1-2)GND (1-2)High (1-2)High

PCI 66MHz (1-2)GND (2-3)GND (1-2)High

PCIX 50MHz (2-3)10K to

GND

(1-2)High X

PCIX 66MHz (2-3)10K to

GND

(2-3)GND X

PCIX 100MHz (open) (1-2)High X

PCIX 133MHz (open) (2-3)GND X

Note: *”X” means “don’t use this pin”

*”Open” means “doesn’t need a jumper”

P1PCIX1~3 PCI Bus rate indicator

Bus rate/Mode LED8 LED9 LED10 LED11

PCI 25MHz OFF OFF ON OFF

PCI 33MHz OFF OFF ON ON

PCI 50MHz OFF OFF OFF OFF

PCI 66MHz OFF OFF OFF ON

PCI 50MHz OFF ON X OFF

PCI 66MHz OFF ON X ON

PCI 100MHz ON ON X OFF

PCI 133MHz ON ON X ON
