PCE-5B06V(7B06V)-04A1E Startup Manual 1

PCE-5B06V-04A1E (PCE-7B06V-04A1E) Backplane: 6-slot BP for 2U Chassis,

1PICMIG 1.3, 1 PCIe, 4 32-bit PCI

PCE-5B06V-04A1E (PCE-7B06V-04A1E) Backplane:

6-slot BP for 2U Chassis, 1 PICMIG 1.3, 1 PCIe, 4

32-bit PCI

Startup Manual

Before you begin installing your card, please make sure

that the following materials have been shipped:

If any of these items are missing or damaged, contact your

distributor or sales representative immediately.

Standard Functions

• PICMIG 1.3 slots:

PCE-7B06V-04 supports PCE-7xxx CPU boards

PCE-5B06V-04 supports PCE-5xxx CPU boards

• PCIe slots:

PCE-7B06V-04 supports one PCIe p1-x8 slot

PCE-5B06V-04 supports one PCIe x16 slot

• 32-bit PCI:

Four 32-bit / 33 MHz PCI slot

• USB (2.0) support: Four Universal Serial Bus ports to

Backplane

Mechanical and Environment

• Dimensions: 80.01 x 325 mm

• Power supply voltage: +12 V, +5 V, -12 V, -5 V, +5 V

SBY, +3.3 V

• Power requirements: Refer to the CPU Board, add-on

Card & Peripherals

• Operating temperature: 0 ~ 60° C

• Weight: 0.211 kg (weight of board)

Packing list Specifications

• One 2 Ports USB Cable p/n: 1700002204

• PCE-5B06V-04A1E (PCE-

7B06V-04A1E) Startup Manual

• M4*6*0.7 Round Screws (5 pcs)

p/n: 1939000410

• 2 years quality warranty card p/n: 2190000902

For more information on this and other Advantech

products, please visit our website at:

http://www.advantech.com

http://www.advantech.com/eplatform

For technical support and service, please visit our

support website at:

http://www.advantech.com/support

This manual is for the PCE-5B06V-04A1E (PCE-

7B06V-04A1E) series Rev. A1

Part No. 200K5B0621

Printed in China

2nd Edition

August 2012

2 PCE-5B06V(7B06V)-04A1E Startup Manual

The table below lists the function of each of the jumpers and

connectors:

Connectors and Jumpers

Connectors

Label Function

SHBA1~SHBD1 PICMG1.3 CPU board slot

PPCIE1 PCE-5B06V-04: PCIe x 16 slot

PCE-7B06V-04: PCIe x 8 slot

PPCI1~PPCI4 32 Bit / 33 MHz PCI Bus slot

EATXPWR1 ATX2.0 24-pin Power Connector

EATX12V1 ATX 12V Auxiliary 8-pin Power Connector

ATX12V1 ATX 12V 4-pin Power Connector

VOLT1 Alarm board / CMM Power Connector

FAN1 FAN Connector

FAN2 FAN Connector

FAN3 FAN Connector

FAN4 FAN Connector

FANDEC1 FAN speed detector Connector

SMBUS1 SMBus Connector for chassis monitor

SMBUS2 SMBus Connector for chassis monitor

KBMS1 External Keyboard/Mouse Connector

KBMS2 External Keyboard/Mouse Connector

JFP1 Power and Reset button Connector

IPMB1 IPMB Connector

USB12 Two USB port pin header

USB34 Two USB port pin header

Jumpers

Label Function

PSON1 ATX / AT Mode Selection

EATXPWER1

Pin Name

1 3.3 V

2 3.3 V

3 GND

4 5 V

5 GND

6 5 V

7 GND

8 Power OK

9 5 V SBY

10 12 V

11 12 V

12 3.3 V

13 3.3 V

14 -12 V

15 GND

16 PSON#

17 GND

18 GND

19 GND

20 -5 V

21 -5 V

22 5 V

23 5 V

24 GND

ATX12V1

Pin Name

1 GND

2 GND

3 12 V

4 12 V

EATX12V1

Pin Name

1 GND

2 GND

3 GND

4 GND

5 12 V

6 12 V

7 12 V

8 12 V

VOLT1

Pin Name

1 5 V SBY

2 GND

3 GND

4 -5 V

5 5 V

6 3.3 V

7 -12 V

8 12 V

FAN1~FAN4

Pin Name

1 GND

2 12 V

3 FANIO1~FANIO4

FANDEC1

Pin Name

1 FANIO1

2 FANIO2

3 FANIO3

4 FANIO4

SMBUS1~SMBUS2

Pin Name

1 5 V

2 C-SMBBUS

3 C-SMBDAT

4 GND

KBMS1~KBMS2

Pin Name

1 KBCLK

2 KBDAT

3 MSDAT

4 GND

5 5 V

6 MS_CLK
