Before installation, please make sure that you have
If anything is missing or damaged, contact your
distributor or sales representative immediately.
For more detailed information on this product, please
refer to the PCI-1730_1733_1734 User Manual on the
CD:\Documents\Hardware Manuals\PCI\PCI-1730
Number of Channels 32 (bi-directional)
Optical Isolation 2,500 VDC
Opto-isolator response time 100 μs
Over-voltage Protection 70 VDC
I/O Connector Type 37-pin D-Sub female
Dimensions 175 mm x 100 mm ( 6.9" x 3.9" )
Operation 0 ~ +60°C (32~ 140°F )
(refer to IEC 68 -2 - 1 ,2)
Storage -20 ~ +70°C (-4 ~158°F)
5 ~ 95% RH non-condensing
Declaration of Conformity
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications. Operation
of this equipment in a residential area is likely to cause
interference in which case the user is required to correct
interference at his own expense.
This product has passed the CE test for environmental
specications when shielded cables are used for external
wiring. We recommend the use of shielded cables. This
kind of cable is available from Advantech. Please contact
your local supplier for ordering information.
For more information on this and other Advantech
products, please visit our websites at:
For technical support and service:
http://www.advantech.com/support/
This startup manual is for PCI-1733.
Part No: 2003173301 2nd Edition
32-channel Isolated Digital Input Card
The Advantech PCI-1733 is a 32-channel isolated digital
input card for the PCI bus. For easy monitoring, each
isolated digital input channel is equipped with one red
LED, and each isolated digital output channel is equipped
with one green LED to show its ON/OFF status. The PCI-
1733’s isolated digital input channels are ideal for digital
input in noisy environments or with oating potentials.
The PCI- 1733 provides specic functions for different
