Protect PV - Solar Inverters
User Manual
AEG Power Solutions GmbH
Revision: 01
Date: 2011-05-25
User Manual
8000038784_00_BAL_en
Contents
1. Introduction 2
Introduction 2
Operation Mode Definition 2
2. Display 4
Display 4
View 5
View 2 5
Status 6
Production Log 8
Setup 10
3. Web Server Quick Guide 12
Introduction 12
Supported Characters 12
Access and Initial Setup 12
Setup Wizard 13
Operation 17
Web Server Structure 17
Plant, Group and Inverter Views 19
Additional Information 20
4. Troubleshooting 21
Troubleshooting 21
5. Maintenance 22
Maintenance 22
Cleaning the Cabinet 22
Cleaning the Heatsink 22
Contents
8000038784_00_BAL_en / L00410565-01_02 1
1. Introduction
1.1. Introduction
This manual provides information on functionality and maintenance of the Protect PV solar in-
verter.
Illustration 1.1: Protect PV 10 kW, Protect PV 12.5 kW, Protect PV 15 kW
CE marking - This certifies the conformity of the equipment with the regula-
tions which apply in accordance with the directives 2004/108/EC and
2006/95/EC.
The Protect PV inverter series comprises:
Protect PV
Protect PV easy
1.2. Operation Mode Definition
Off grid (LEDs off)
When no power has been delivered to the AC grid for more than 10 minutes, the inverter dis-
connects from the grid and shuts down. This is the normal night mode. The user and communi-
cation interfaces are still powered for communication purposes.
Connecting (Green LED flashing)
The inverter starts up when the PV input voltage reaches 250 V. The inverter performs a series
of internal self-tests, including PV auto detection and measurement of the resistance between
the PV arrays and earth. Meanwhile, it also monitors the grid parameters. When the grid pa-
rameters have been within the specifications for the required amount of time (depends on
country settings), the inverter starts to energise the grid.
1. Introduction
2 8000038784_00_BAL_en / L00410565-01_02
1
On grid (Green LED on)
The inverter is connected to the grid and energises the grid. The inverter disconnects if: It de-
tects abnormal grid conditions (depending on country settings), if an internal event occurs or if
no PV power is available (no power is supplied to the grid for 10 minutes). It then goes into
connecting mode or off grid mode.
Fail Safe (Red LED flashing)
If the inverter detects an error in its circuits during the self-test (in connecting mode) or during
operation, the inverter goes into fail safe mode. The inverter will remain in fail safe mode until
PV power has been absent for a minimum of 10 minutes, or the inverter has been shut down
completely (AC + PV).
Refer to the section on
Troubleshooting
for further information.
1. Introduction
8000038784_00_BAL_en / L00410565-01_02 3
1
