Side 1/12

Installation Manual

To installers:

• After installation is completed, be sure to hand the

accessories to the customer.

NOTE:

• The illustrations and images used in this manual may

differ from the actual ones.

HTML manual

https://www.aip-info.net/file/manual/j/JV-1MD/JV-

1MD_INS/JV-1MD_INS_EN/content/

Table of contents

Package contents ............................................. 2

Precautions ....................................................... 2

Part names and functions ............................... 3

Wiri ng ................................................................ 5

Precautions for wiring .......................................... 5

Wiring diagram and specifications ....................... 6

Before installation ............................................ 7

Precautions for installation ................................... 7

Door station mounting positions and image view

area 8.....................................................................

Mounting ........................................................... 8

JV-1MD ................................................................ 8

JV- DV ................................................................ 10

JV-DVF .............................................................. 11

After installation ............................................. 11

Check after installation ....................................... 11

Installer settings ................................................. 12

Privacy notice ................................................. 12

Issue date: Dec. 2023 FK2966 1223 (H1.00) DL GZ 65292 Ⓐ

JVS-1V (A set including JV-1MD, JV-DV and power supply)

JVS-1F (A set including JV-1MD, JV-DVF and power supply)

JV-1MD (Hands free color video intercom master monitor station)

-2-

Package contents

No.

Content

JVS-

JV-

1MD

JV-1MD (master monitor

station)

✔

JV-DV (door station)

 Special screwdriver

✔

JV-DVF (door station)

 Flush mount back box

 Special screw (×4)

 Hexagonal wrench

✔

Power supply

(PS-2420UL, PS-2420-O,

PS-2420DM, PS-2420S or

PS-2420BF) (*)

✔

Nameplate (×2)

✔

Installation manual

✔

Information sheet

✔

Chinese RoHS declaration (*)

✔

(*): This may not be included depending on the country in

which the product is sold.

NOTE

 Mounting screws and wood screws are not included.

Filling in the nameplate

1 Peel off the protective seal (both sides).

2 Fill in the resident's name.

 Use a permanent pen.

 Keep the text within the dashed line.

Precautions

Indicates that users may require caution

(including warning / caution).

Alerts users to prohibited actions.

Restricts user actions / provides instructions.

WARNING

Negligence could result in death or serious injury.

This product is not designed to explosion-proof

specifications. Do not install or use in locations

that can contain flammable gases.

This may result in fire or explosion.

Do not disassemble or modify the station.
