Side 1/4

READ AND SAVE THESE INSTRUCTIONS

READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT

DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPLY

WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE!

RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.

2084007

Rev. P 6/07

20" DELUXE PIVOT FAN

MODEL 4CH68G/9500G

OPERATING INSTRUCTIONS & PARTS MANUAL

2084007

Rev. P 6/07

SPECIFICATIONS

Motor .................................120V, 60 Hz

Blade diameter ...................20" ( 50.8 cm)

Speeds ...............................3

Control................................Rotary Switch

Air ow distribution .............120°

Approvals............................UL Listed. Close mesh fan guard

meets OSHA requirements.

DESCRIPTION

The Air King 20" (50.8 cm) Deluxe Pivot Fan features 3 speed whis-

per-quiet operation, a 5-paddle fan blade, and 120° adjustable tilt.

The fan has a permanently lubricated motor with a 6 ft. (1.8 m) 18/3

cord set.

MODEL

4CH68G/9500G

SPEED

HIGH MED LOW

CFM 2470 2055 1570

/s 1.17 0.97 0.74

RPM 1137 1018 777

Amps 1.05 0.82 0.62

Watts 129 106 79

dB A 64 60 52

GENERAL SAFETY INFORMATION

When using electrical appliances, basic

precautions should always be followed to

reduce the risk of re, electric shock and injury

to person, including the following:

1. Read all instructions before using Fan.

2. Make certain that the power source conforms to the electrical

requirements of the Fan.

3. Use this Fan only as described in this manual. Any other use

not recommended by the manufacturer may cause re, electrical

shock, or injury to persons.

4. Unplug power cord before installing, servicing, or moving the Fan.

WARNING: DO NOT DEPEND UPON THE ON-OFF SWITCH AS

THE SOLE MEANS OF DISCONNECTING POWER WHEN

INSTALLING OR SERVICING THE FAN. ALWAYS UNPLUG THE

POWER CORD.

5. This Fan must NOT be used in potentially dangerous

locations such as ammable, explosive, chemical-laden

or wet atmospheres.

6. DO NOT use Fan in or near a window. Rain may create an

electrical hazard.

7. The power cord is equipped with a three-prong grounded plug

that must be inserted into a matching receptacle. Under no

circumstances must the grounding prong be cut off the plug.

Where a two-prong wall receptacle is encountered, it must be

replaced with a properly grounded three-prong receptacle installed

in accordance with the National Electrical Code (NEC) and all

applicable local codes and ordinances. This work must be done

only by a qualied electrician, using copper wire only.

WARNING: USE OF A THREE-PRONG TO TWO-PRONG

ADAPTER IS NOT RECOMMENDED. IMPROPER

CONNECTION MAY CREATE THE RISK OF ELECTRO-

CUTION. USE OF SUCH ADAPTERS IS NOT PERMITTED

IN CANADA.

WARNING: THIS PLUG IS A SAFETY FEATURE. TO

REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND

PERSONAL INJURY, DO NOT REMOVE, REPLACE, REPAIR

OR TAMPER WITH THE ORIGINALLY SUPPLIED PLUG. IF

THE FAN DOES NOT FUNCTION PROPERLY, IT MAY BE

DUE TO THE SAFETY DEVICE INCORPORATED IN THIS

PLUG. CONTACT YOUR GRAINGER DISTRIBUTOR.

8. Where possible, avoid the use of extension cords. If they must

be used, minimize the risk of overheating by ensuring that they

are UL listed. Never use a single extension cord to operate more

than one Fan.

9. Do not operate any Fan with a damaged cord or plug or after the

Fan malfunctions, has been dropped or damaged in any manner.

Return Fan to authorized service facility for examination, electrical

or mechanical adjustment or repair.

10.Do not insert or allow ngers or foreign objects to enter any

ventilation or exhaust opening as it may cause an electric shock

or re, or damage the Fan. Do not block or tamper with the Fan

in any manner while it is in operation.

11.Always place the Fan on a stable, at, level surface when operating,

to avoid the chance of the Fan overturning. Locate the Power Cord

so the Fan or other objects are not resting on it. Do not run Power

Cord under carpeting. Do not cover Power Cord with throw rugs,

runners, or the like. Arrange Power Cord away from room trafc

and where it will not be tripped over.

12.This Fan is not intended for use in wet or damp locations. Never

locate a Fan where it may fall into a bathtub or other water container.

13. Do not use Fan outdoors.

14.This Fan is not suitable for use in agricultural facilities including

areas where livestock, poultry or other animals are conned.

Please refer to National Electric Code (NEC) Article 547-7 (2002),

or applicable state or local codes or standards relating to electrical

requirements for Agricultural Buildings. THIS FAN DOES NOT

MEET THE REQUIRMENTS OF NEC ARTICLE 547-7 (2002).

15.This Fan is not suitable for use in hazardous locations. Please refer to

National Electric Code (NEC) Article 500 or applicable state or local

codes or standards relating to electrical requirements for Hazardous

locations. THIS FAN DOES NOT MEET THE REQUIRMENTS OF

NEC ARTICLES 500 (2002)

WARNING: REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK

– DO NOT USE THIS FAN WITH ANY SOLID STATE SPEED

CONTROL DEVICES.

SAVE THESE

INSTRUCTIONS

This Fan is not intended to be used in

commercial, industrial or agricultural settings.

MODEL /MODELO/ MODÉLE 4CH68G/9500G
